VERSION # 20-01-09
1 / 9
MODEL #
CM3358SC-2PK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM3358SC-2PK
Summary of Contents for Furniture of America CM3358SC-2PK
- Page 1 MODEL # CM3358SC-2PK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X 9...
-
Page 5: Chair Back
DINING CHAIR CM3358SC-2PK #1 1pc x2 #2 1pc x2 #3 2pcs x2 Chair Back Cushion Seat Front Leg (L/R) #4 2pcs x2 Stretcher (L&R) #A 1pc x2 #B 4pcs x2 #C 4pcs x2 #D 2pcs x2 Bolt Allen Wrench M4... -
Page 6: Exploded View
Exploded View 6 / 9... - Page 7 ASSEMBLY INSTRUCTIONS Align chair back (#1) to seat cushion (#2). Prepare bolt assemblies by inserting lock washer (#E) to the bolts (#D), then insert flat washer (#F) to the same bolts (#D). Secure by using an Allen wrench (#A). Part #1 x1pc Part #2 x1pc...
- Page 8 ASSEMBLY INSTRUCTIONS Align the stretchers (#4) to the chair back leg and the front legs (#3) to the seat front. Insert screws (#G) and secure with screwdriver. Part #3 x2pcs Part #4 x2pcs Hardware #G x2pcs Prepare bolt assemblies by inserting lock washer (#E) to the bolts (#C), then insert flat washer (#F) to the same bolts (#C).
- Page 9 ASSEMBLY INSTRUCTIONS 9 / 9...
