Quick Reference Guide
Team3 USA
Fetal Monitor

Switching the unit ON

1 Touch and hold the On/Off button for 2 seconds. (On Team 3 Front Panel).
2 Check the printer: Is there sufficient paper for the monitoring session?
3 Connect transducers. Display shows transducer connection

Control Bar

Printer On/
Paper
Off
Feed
1 Touch any of the keys above to operate that function.

Entering Patient Details

1 Touch and hold the box in the top left corner of the screen and a Patient Details dialogue appears.
2 Enter Patient Name using the popup keyboard.
3 Touch the Patient ID field and type data as required.
4 Touch the Gestational Age field to bring up another dialogue. Use the up and down arrows to set the
correct gestational age.
5 Touch
to set Gestational Age.
6 Touch
to set Patient Data.
7 Ensure patient data is entered before you print. It cannot be changed afterwards.

Monitoring FHR

1
Determine fetal lie and position.
2
Apply Gel to the green transducer face.
Position on abdomen so as to get optimal heart sound. Secure with belt.
3 Make sure the FHR is clear, and different from the maternal pulse taken at the mother's wrist.
FHR signal quality is shown by the flashing heart symbol.
4 Adjust the volume for the audio channel.

Monitoring Uterine Activity

1 Position the pink transducer on the midline over the fundus of the uterus. Secure with belt.
2 Zero the Toco. Make sure the uterus is relaxed, and then touch and hold the screen in the pink TOCO
Clinical Region.
777852-1
10/2021
Numbers
Volume
or Graph
Down
Volume
Notes *
Up
Settings
Menu *
(* Depending on model / operating mode)
