Coleman ECHELON Series Technical Manual

TECHNICAL GUIDE
TM
SERIES
ECHELON
SPLIT SYSTEM
AIR CONDITIONERS
19 SEER – R-410A – 1 PHASE
2 THRU 5 NOMINAL TONS
MODELS: AC19B24 THRU 60
Due to continuous product improvement, specifications
are subject to change without notice.
Visit us on the web at
www.simplygettingthejobdone.com and
www.colemanac.com
Additional rating information can be found at
www.ahridirectory.org
WARRANTY SUMMARY*
Extended 10-Years limited parts warranty.
Extended Lifetime limited compressor warranty.
Extended parts and compressor warranties require online
registration within 90 days of purchase for replacement or
closing for new home construction.
*Does not apply to 3-Phase models, or Internet sales.
See Limited Warranty certificate in User's Information Manual for details.
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
FOR INSTALLATION IN ALL US REGIONS AND CANADA
Installation Allowed

DESCRIPTION

The Echelon™ Series AC19 two-speed air conditioners are the
outdoor section of a high efficiency cooling system. They are
designed to be custom matched with one of our complete line of
indoor sections. Matching air handlers are available for upflow,
downflow and horizontal left or right applications to provide a
complete system. Alternately, add-on coils are available for use
with modular air handlers or multi-position furnaces. Electric
heaters and field installed accessories are also available as
needed.

FEATURES

• Superior Coil Protection – An easily removable two-piece
steel extruded louver coil guard protects the tube-in-fin coil
from debris and physical damage while making access for
coil cleaning quick and simple.
• Environmentally Friendly Refrigerant – The next genera-
tion refrigerant R-410A delivers environmentally friendly per-
formance with zero ozone depletion.
• Durable Finish – A high quality powder paint finish rated at
1000 hrs. salt spray provides the ultimate protection from
corrosion and harmful UV rays, ensuring a long-lasting, high
quality appearance.
• WhisperDrive™ System – Features a combination of engi-
neered, sound-neutralizing attributes such as a swept-wing
fan blade, composite base pan, multi-density compressor
cloak and variable capacity operation to reduce sound levels
to that of a mere conversation.
• ECM Fan Motor – Dynamically adjusts speed in sync with
the outdoor temperature stage to keep heat exchange in bal-
ance while minimizing power consumption and sound.
• Swept Wing Fan – A design adapted from aerospace engi-
neering provides whisper-quiet operation by allowing air to
flow smoothly and efficiently across the fan surface and
edges.
• Composite Base Pan – The strong and durable composite
base pan is corrosion resistant while adding strength,
absorbing sound, and reducing vibration.
• High-Efficiency Outdoor Coil – An aluminum fin and cop-
per tube outdoor coil provide easy cleaning, low restriction to
airflow and efficient heat exchange.
• Factory Installed Filter Drier – The liquid line filter drier
removes debris and moisture which can be harmful to the
system.
• Climate Connect™ – provides pre-configured operating
profiles the installing contractor can select during set-up to
fine tune the system's operation for either Humid, Dry, or
Normal climates. Additional fine-tune adjustments are
always available to provide a custom comfort solution. (Avail-
able when paired with a variable speed indoor air mover).
• Easy Service Access – A large electrical box cover and a
swing open electrical box provide superior full corner access
to the inside of the unit for maintenance or service.
• TXV Controls – All indoor coils, whether in the cased CF/
CM coil or in air handlers, may use dealer installed TXV's or
indoor equipment with factory installed TXV's.
5493752-CTG-F-0420
