R-410A
ZW SERIES
15 - 25 Ton
60 Hertz
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Rigging And Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Ductwork . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Compressors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power And Control Wiring. . . . . . . . . . . . . . . . . . . . . . . . . 14
Optional Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Optional Gas Heat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Options/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Air Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
1 ZW-15 thru -25 Unit Limitations . . . . . . . . . . . . . . . . . . . . 7
2 Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 ZW-15 thru -25 Unit Accessory Weights . . . . . . . . . . . . . . 9
4 Utilities Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 ZW-15 thru -25 Unit Clearances . . . . . . . . . . . . . . . . . . . 11
6 Control Wire Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
8 ZW-15 thru -25 Physical Data . . . . . . . . . . . . . . . . . . . . . 20
9 Electric Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . 21
10 Gas Application Data . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
11 Gas Pipe Sizing - CapacIty of Pipe . . . . . . . . . . . . . . . . . 22
12 Gas Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . . . 22
13 Altitude/Temperature Correction Factors . . . . . . . . . . . . 27
1 ZW-15 thru -25 Component Location . . . . . . . . . . . . . . . . 6
2 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Unit 6 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 Center of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 ZW-15 thru -25 Unit Dimensions Front View . . . . . . . . . . 9
6 ZW-15 thru -25 Unit Dimensions Rear View . . . . . . . . . 10
7 ZW-15 thru -25 Unit Dimensions Rain Hood . . . . . . . . . 11
8 ZW-15 thru -25 Roof Curb . . . . . . . . . . . . . . . . . . . . . . . 12
9 Fixed Outdoor Air Damper . . . . . . . . . . . . . . . . . . . . . . . 13
10 Condensate Drain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Electric Heat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
12 Field Wiring 24 Volt Thermostat . . . . . . . . . . . . . . . . . . . 15
13 External Supply Connection External Shut-Off . . . . . . . 22
14 Bottom Supply Connection External Shut-Off . . . . . . . . 22
15 Vent and Combustion Air Hood . . . . . . . . . . . . . . . . . . . 24
TABLE OF CONTENTS
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Cooling Sequence Of Operation . . . . . . . . . . . . . . . . . . . . 41
No Outdoor Air Options . . . . . . . . . . . . . . . . . . . . . . . . . 41
Cooling Operation Errors . . . . . . . . . . . . . . . . . . . . . . . . 42
Electric Heating Sequence Of Operations . . . . . . . . . . . . 43
Electric Heat Operation Errors . . . . . . . . . . . . . . . . . . . . 43
Gas Heating Sequence Of Operations . . . . . . . . . . . . . . . 44
Gas Heating Operation Errors . . . . . . . . . . . . . . . . . . . . 45
Start-Up (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Start-Up (Gas Heat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Checking Gas Heat Input . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Charging The Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Unit Control Board Option Setup . . . . . . . . . . . . . . . . . . . . . . 56
Option Byte Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Heat Delay Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
LIST OF TABLES
15 ZW Gas Heat Bottom Duct Blower Performance . . . . . . 33
16 Indoor Blower Specifications . . . . . . . . . . . . . . . . . . . . . . 40
17 Power Exhaust Specifications . . . . . . . . . . . . . . . . . . . . 40
18 Additional Static Resistance . . . . . . . . . . . . . . . . . . . . . . 41
19 Limit Control Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
20 Electric Heat Anticipator Setpoint . . . . . . . . . . . . . . . . . . 44
21 Gas Heat Limit Control Setting . . . . . . . . . . . . . . . . . . . . 46
22 Gas Heat Anticipator Setpoints . . . . . . . . . . . . . . . . . . . . 46
23 Gas Rate Cubic Feet Per Hour . . . . . . . . . . . . . . . . . . . . 47
24 Unit Control Board Flash Codes . . . . . . . . . . . . . . . . . . . 55
25 Heat Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
LIST OF FIGURES
16 Enthalpy Set Point Chart . . . . . . . . . . . . . . . . . . . . . . . . 25
17 Honeywell Economizer Control W7212 . . . . . . . . . . . . . 25
18 Belt Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
19 Altitude/Temperature Correction Factors . . . . . . . . . . . . 27
Air CFM For All Unit Tonnages . . . . . . . . . . . . . . . . . . . 40
21 Gas Valve Piping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
22 Gas Valve and Controls . . . . . . . . . . . . . . . . . . . . . . . . . 46
23 Proper Pilot Flame Adjustment . . . . . . . . . . . . . . . . . . . 48
24 Typical Flame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
25 Typical Gas Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
26 ZW-15 (15 Ton) Charging Chart . . . . . . . . . . . . . . . . . . 49
27 ZW-18 (17.5 Ton) Charging Chart . . . . . . . . . . . . . . . . . 49
28 ZW-20 (20 Ton) Charging Chart . . . . . . . . . . . . . . . . . . 49
29 ZW-25 (25 Ton) Charging Chart . . . . . . . . . . . . . . . . . . 49
30 Unit Control Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
178113-BIM-D-0906
Advertisement
Table of Contents
Related Manuals for Coleman ZW Series
Summary of Contents for Coleman ZW Series
-
Page 1: Table Of Contents
R-410A ZW SERIES 15 - 25 Ton 60 Hertz TABLE OF CONTENTS General ......... . 2 Operation . -
