H3C MSR 2600 Installation, Quick Start page 3

正确的安装方式 Correct Installation：
2
4
1
6
错误的安装方式 Incorrect Installation：
SIM2
8
Installing the 3G/4G Antenna 安装3G/4G天线
Two 4G antennas are provided with a 4G LM router. One 3G antenna is provided with a
3G GU/GT router. When you install a 3G antenna on a GU/GT router, attach the
antenna to the port marked "MAIN." If you need to install two 3G antennas on a GU/GT
router, purchase one separately.
LM是4G款型，随机提供两根4G天线。GU/GT是3G款型，随机仅提供一根3G天线，请将
天线安装在标有MAIN字样的接口上。当用户需要配置两根3G天线时，天线请单独购买。
5
3
5
7
9
This section is only applicable to the MSR 26-00-5 router.
本节内容仅适用于MSR 26-00-5款型。
1
Installing the 3G/4G Extender Cable 安装3G/4G天线延长线
The 3G/4G extender cable is not supplied with the router. Prepare it yourself.
3G/4G延长线不随机提供，用户可根据需要单独购买。
1
3
MAIN
2
This section is only applicable to the MSR 26-00-5 router.
本节内容仅适用于MSR 26-00-5款型。
M6
M3
M2.9 2
4
This section is only applicable to the MSR 26-00-5 router.
本节内容仅适用于MSR 26-00-5款型。
6
