- Main menu 1
• Press [MODE/ENTER] to enter the main menu (display flashing).
• Press [UP] or [DN] to select "SET".
rpan
- Pan Reverse
With this function you can reverse the Pan-movement.
• Select "RPAN" by pressing [UP] or [DN].
• Press [MODE/ENTER], the display shows "ON" or "OFF".
• Press [UP] to select "ON" if you wish to enable this function or [DN] to select "OFF" if you don't.
• Press [MODE/ENTER] to confirm.
• Press [EXIT] in order to return to the main menu.
rtil
- Tilt Reverse
With this function you can reverse the Tilt-movement.
• Select "RTIL" by pressing [UP] or [DN].
• Press [MODE/ENTER], the display shows "ON" or "OFF".
• Press [UP] to select "ON" if you wish to enable this function or [DN] to select "OFF" if you don't.
• Press [MODE/ENTER] to confirm.
• Press [EXIT] in order to return to the main menu.
- Switch 16 bit/8 bit
With this function you can switch the device from 16 bit to 8 bit resolution.
• Select "16BI" by pressing [UP] or [DN].
• Press [MODE/ENTER], the display shows "ON" or "OFF".
• Press [UP] or [DN] to select "ON" in order to set 16 bit, or "OFF" in order to set 8 bit. The channels
PAN Fine and TILT Fine will be disabled.
• Press [MODE/ENTER] to confirm.
• Press [EXIT] in order to return to the main menu.
- Select PAN-degree
With this function you can switch the PAN-angle from 630 to 540 degree.
• Select "DEGR" by pressing [UP] or [DN].
• Press [MODE/ENTER] to confirm; the display shows "630".
• Press [[UP] or [DN] to select the desired delgree between "630" and "540".
• Press [MODE/ENTER] to confirm.
• Press [EXIT] in order to return to the main menu.
- Mic sensitivity
With this function, you can select the desired microphone sensitivity between 0 % and 99 %.
• Select "MIC" by pressing [UP] or [DN].
• Press [MODE/ENTER] to confirm.
• Press [UP] to select the desired sensitivity.
• Press [MODE/ENTER] to confirm.
• Press [EXIT] in order to return to the main menu.
