Future light PHP-21 TCL LED-Head-Effect User Manual page 35

Control-channel 7 - Blue
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Control-channel 8 - Strobe
Decimal Hexad. Percentage S/F
0 0 00 00 0% 0%
1 95 01 5F 0% 37%
96 127 60 7F 38% 50%
128 159 80 9F 50% 62%
160 191 A0 BF 63% 75%
192 223 C0 DF 75% 87%
224 255 E0 FF 88% 100%
Control-channel 9 - Reset, internal programs
Decimal Hexad. Percentage S/F
0 19 00 13 0% 7%
20 79 14 4F 8% 31%
80 99 50 63 31% 39%
100 119 64 77 39% 47%
120 139 78 8B 47% 55%
140 159 8C 9F 55% 62%
160 179 A0 B3 63% 70%
180 199 B4 C7 71% 78%
200 219 C8 DB 78% 86%
220 239 DC EF 86% 94%
240 255 F0 FF 94% 100%
Control-channel 10 - Pan-movement with 16 Bit-resolution
Control-channel 11 - Tilt-movement with 16 Bit-resolution
Control-channel 12 - Dimmer
Decimal Hexad. Percentage S/F
0 0 00 00 0% 0%
1 255 01 FF 0% 100%
S Blue (0=off, 255=100% blue)
S No function (shutter open)
F Strobe-effect with increasing speed
S No function (shutter open)
S Pulse-effect in sequences
S No function (shutter open)
F Random strobe-effect with increasing speed
S No function (shutter open)
S Normal control
S No function
S Reset
S Internal program 1
S Internal program 2
S Internal program 3
S Internal program 4
S Internal program 5
S Internal program 6
S Internal program 7
S Internal program 8
S Blackout
S Gradual adjustment of the dimmer intensity from 0 to 100 %
35/44
Feature
Feature
Feature
Feature
00035683.DOC, Version 1.0
