Parts
4
12
13
14
21
16
7
11
6
Parts
5
17
9
8
2
UCDE224DSS03A
Item
1 3" CASTERS (4)
2 COMPRESSOR ASSEMBLY
3 MAIN BOARD
4 ANTI TIP BRACKET W/SCREWS
5 BACK PANEL, 24"
6 CONDENSER ASSY 5 CLASS
7 CONDENSER FAN W/SCREWS
8 CONTROL ASSEMBLY
9 DOOR ASSY, 24" SOLID STAINLESS
10 DRAIN TROUGH 5 CLASS 24" *
11 DRIER
12 EVAP ASSY, 5 CLASS 24"
13
EVAPORATOR COVER, BLACK
14 EVAP FAN W/COVER, BLACK
15 GASKET, DOOR
16 GRILLE ASSEMBLY
17 HINGE ASSEMBLY
18 PACKAGING, 24" *
19 POWER CORD, EXTERNAL *
POWER CORD, INTERNAL *
20
21 THERMISTOR(1 PC)
22 WIRE HARNESS, OUTDR 1C *
*Not Pictured
15
1
3
36
Description U-Line P/N
ULACASTERS
80-55548-00
80-55507-00
80-54221-00
80-55350-03
80-55453-00
80-54014-00
80-55552-01
80-55421-01
80-55484-00
80-54055-00
80-55486-00
80-55554-00
80-54151-01
80-54213-01
80-55555-00
80-55556-00
80-55557-00
80-55278-00
80-55553-00
80-54006-00
80-55402-00
