U-Line UHBD524 User Manual & Service Manual

U-Line UHBD524 User Manual & Service Manual

5 class 24” dual zone beverage center
Hide thumbs Also See for UHBD524:
Table of Contents

Advertisement

Quick Links

USER GUIDE & SERVICE MANUAL
5 Class
UHBD524
24" Dual Zone Beverage Center
●
●

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UHBD524 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for U-Line UHBD524

Summary of Contents for U-Line UHBD524

  • Page 1 USER GUIDE & SERVICE MANUAL 5 Class UHBD524 24” Dual Zone Beverage Center ● ●...

  • Page 2: Table Of Contents

    USER GUIDE & SERVICE MANUAL u-line.com Table of Contents Intro Troubleshooting Wire Diagram Safety Product Liability Safety and Warning Warranty Claims Disposal And Recycling Warranty Installation Environmental Requirements Electrical Cutout & Product Dimensions Side by Side Installation Anti-Tip Bracket General Installation...
  • Page 3 ® to preserve the right product, in the right place, at the right temperature. Since 2014, U-Line has been part of the Middleby family of brands. All products are designed, engineered, and assembled in Milwaukee, Wisconsin, USA, and select products are available worldwide.

  • Page 4: Safety And Warning

    USER GUIDE u-line.com Safety and Warning DANGER NOTICE This unit contains R600a (Isobutane) which is a Please read all instructions before installing, flammable hydrocarbon. It is safe for regular operating, or servicing the appliance. use. Do not use sharp objects to expedite defrosting.

  • Page 5: Disposal And Recycling

    USER GUIDE u-line.com Disposal and Recycling DANGER RISK OF CHILD ENTRAPMENT. Before you throw away your old refrigerator or freezer, take off the doors and leave shelves in place so children may not easily climb inside. If the unit is being removed from service for disposal,...

  • Page 6: Environmental Requirements

    USER GUIDE u-line.com Environmental Requirements This model is intended for indoor/interior applications only and is not to be used in installations that are open/ exposed to natural elements. This unit is designed to operate between 50°F (10°C) and 100°F (38°C). Higher ambient temperatures may reduce the unit’s ability to reach low temperatures and/or reduce...

  • Page 7: Electrical

    USER GUIDE u-line.com Electrical WARNING SHOCK HAZARD — Electrical Grounding Required. Never attempt to repair or perform maintenance on the unit until the electricity has been disconnected. Never remove the round grounding prong from the plug and never use a two-prong grounding adapter.

  • Page 8: Cutout & Product Dimensions

    Cutout & Product Dimensions 23 ⁄ ” (600 mm) PREPARE SITE Your U-Line product has been designed for either free- standing or built-in installation. When built-in, your unit FRONT does not require additional air space for top, sides, or 33 ⁄ ”...

  • Page 9: Side By Side Installation

    USER GUIDE u-line.com Side-by-Side Installation Hinge-by-Hinge Installation (Mullion) When installing two units hinge-by-hinge, 13/16" (22 mm) OTHER SITE REQUIREMENTS is required for integrated models. Additional space may be Side-by-Side Installation needed for any knobs, pulls or handles installed. Units must operate from separate, properly grounded electrical receptacles placed according to each unit’s...

  • Page 10: Anti-Tip Bracket

    USER GUIDE u-line.com Anti-Tip Bracket Surrounding area (Top view) Use one of the methods below to secure the unit CABINET/COUNTER ANTI-TIP INSTALLATION (For built-in applications) Back of unit Back wall Slide unit out so screws on front of unit are easily accessible.

  • Page 11: General Installation

    USER GUIDE u-line.com General Installation INSTALLATION Plug in the power/electrical cord. LEVELING INFORMATION Gently push the unit into position. Be careful not Use a level to to entangle the cord or water and drain lines, if confirm the unit is applicable.

  • Page 12: Integrated Panel Dimensions

    USER GUIDE u-line.com Integrated Panel Dimensions Integrated Frame Dimensions Metric measurements rounded and optimized. 3/4" BACK SURFACE MUST HAVE AMPLE FLAT SURFACE (20 mm) INTEGRATED FRAME TO MOUNT OVERLAY FRAME FLAT AND WITHOUT INTERFERENCE NOTICE 23-1/2" (595 mm) Due to differences in surrounding cabinetry the panel may not perfectly align with door.
  • Page 13 USER GUIDE u-line.com HANDLELESS INTEGRATED FRAME 3. Prepare the insert(s) that will back up the handleless design. Wooden Insert – Cut 1/8" (3 mm) thick The following procedure is designed to provide a finished, wooden insert(s) to the dimensions below.
  • Page 14 USER GUIDE u-line.com Handleless Integrated Frame Dimensions 1/8" (3 mm) Top Design 1/4" (6 mm) 7/8" (22 mm) Ref. 2-3/8" R 5/8" (60 mm) (R 16 mm) 23-1/2" (595 mm) 2-3/4" (70 mm) Insert Notch 2-3/4" (70 mm) Wooden Insert Notch Depth: 1/8"...
  • Page 15 USER GUIDE u-line.com EXTENDED INTEGRATED FRAME 3. Optional: Install handles and hardware. NOTICE Due to differences in surrounding cabinetry the NOTICE panel may not perfectly align with door. The The door panel must not weigh more than 20 lbs procedure below is designed to provide a (10 kg).
  • Page 16 (20 mm) If you would like to cover the grille with an integrated TO MOUNT OVERLAY FRAME FLAT AND WITHOUT INTERFERENCE panel, purchase U-Line’s adjustable grille accessories. 23-1/2" (595 mm) 24” - Sales Accessory: ULAGRILLE24 Complete instructions, including dimensions of the inte- grated grille panel, are included with the accessory.

  • Page 17: Integrated Panel Installation

    11.Remove clamps from door. panel to door using Clamp clamps. A robust tape may also be NOTICE used. U-Line If panel requires additional adjustment after recommends the removing clamps, slightly loosen each screw and use of bar clamps Door/Drawer adjust panel as necessary. Tighten screws upon to secure the panel completion.

  • Page 18: Grille Installation

    USER GUIDE u-line.com Grille Installation REMOVING AND INSTALLING GRILLE WARNING Disconnect electric power to the unit before removing the grille. When using the unit, the grille must be installed. WARNING DO NOT touch the condenser fins. The condenser fins are SHARP and can be easily damaged.

  • Page 19: Door Swing

    USER GUIDE u-line.com Door Swing Wall For Integrated models that are installed adjacent to a wall, 1/2" (13 mm) 1/2" (13 mm) clearance is recommended from wall on hinge side to allow the door to open 90°. Allow for additional space for any knobs or pulls installed on the integrated panel/frame.

  • Page 20: Door Adjust

    USER GUIDE u-line.com Door Adjustments REVERSING THE DOOR Open door. DOOR ALIGNMENT AND ADJUSTMENT Using T-25 Torx bit loosen screw #1 and remove screw Align and adjust the door if it is not level or not sealing #2 on top and bottom hinge. Slide and remove the properly.
  • Page 21 If the temperature displayed is different than selected, the unit is progressing towards the selected temperature. Time to reach set point varies based upon ambient temperature, temperature of product loaded, door openings, etc. U-Line recommends allowing the unit to reach set points before loading.
  • Page 22 USER GUIDE u-line.com Control Operation CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES ON/OFF Press and release Unit will immediately turn On or OFF Interior light color indicates zone temperature being set; Blue = lower (38 - 65 White = upper (38...
  • Page 23 USER GUIDE u-line.com Dual Zone Temperature Table Beverage Dual Zone Lower: Upper: 38° - 65° 33° - 45° Minimum Maximum Control Operation...
  • Page 24 Typical Can Bottles and cans come in all shapes and sizes. When (135 mm) (123 mm) (12 oz) determining capacities U-Line uses the following sizes. Combinations of red and white bottles are used in Wine ® Captain Models and Beverage Centers.

  • Page 25: Interior Adjustments

    USER GUIDE u-line.com Interior Adjustments Once removed, retract the slides. Note: The slides on the rack have a thin coating which Dual Zone Beverage Centers feature side mounted rack is used to block moisture and provide lubrication. Use supports with 17 adjustment positions.
  • Page 26 USER GUIDE u-line.com Wine Storage Options Pull frame towards you until all pins are clear of the slots. If only repositioning the frame, do not remove WINE RACK BOTTLE POSITION completely - go to “Storage Bin Installation” Step 2. Specially designed horizontal wine racks properly position Slightly tilt one side.

  • Page 27: Cleaning

    USER GUIDE u-line.com Cleaning To clean integrated panels, use household cleaner per the cabinet manufacturer’s recommendation. Stainless Models Stainless door panels and handles can discolor when INTERIOR CLEANING exposed to chlorine gas, pool chemicals, saltwater or Disconnect power to the unit.
  • Page 28 USER GUIDE u-line.com NOTICE The drain pan was not designed to capture the water created when manually defrosting. To prevent water from overflowing the drain pan and possibly damaging water sensitive flooring, the unit must be removed from cabinetry. To defrost: 1.

  • Page 29: Cleaning Condenser

    USER GUIDE u-line.com Cleaning Condenser INTERVAL - EVERY SIX MONTHS To maintain operational efficiency, keep the front grille free of dust and lint, and clean the condenser when necessary. Depending on environmental conditions, more or less frequent cleaning may be necessary.

  • Page 30: Service

    If the unit will be exposed to temperatures of 40°F (5°C) or less, the steps above must be followed. For questions regarding winterization, please call U-Line at 800.779.2547. CAUTION Damage caused by freezing temperatures is not covered by the warranty.

  • Page 31: Troubleshooting

    BEFORE CALLING FOR SERVICE • Condenser Fan: Air moving through a condenser may be heard. If you think your U-Line product is malfunctioning, read the CONTROL OPERATION section to clearly understand the • Automatic Defrost Drain Pan: Water may be heard function of the control.
  • Page 32 USER GUIDE u-line.com u-line.com CHECKING PRODUCT TEMPERATURE Causes which affect the internal temperatures of the cabinet include: • Temperature setting. • Ambient temperature where installed. • Installation in direct sunlight or near a heat source. • The number of door openings and the time the door is open.

  • Page 33: Wire Diagram

    USER GUIDE u-line.com Wire Diagram Wire Diagram...

  • Page 34: Product Liability

    The part that caused the damage must be returned to U-Line in its entirety. The part must be clearly labeled with the serial number of the unit it was removed from, the date, and the servicer who removed the part.

  • Page 35: Warranty Claims

    Claims must be submitted online at • Final billing - Remodel www.U-LineService.com Warranty parts will be shipped at no charge after U-Line • 60 day submittal deadline from date of completed confirms warranty status. Please provide the model, serial service number, part number and part description.
  • Page 36 For products installed and used for normal residential use, material cosmetic defects are included in this warranty, with coverage limited to 60 days from the date of original purchase. All service provided by U-Line under the above warranty must be performed by a U-Line factory authorized servicer, unless otherwise specified by U-Line.

This manual is also suitable for:

Uhwd524 seriesUhwd524ig01a
