Wiring of Multi-clusters battery in parallel
Note: 1.Supports up to 8 clusters in parallel.
2.The power combiner box needs to be prepared by the user.
To PCS
Battery HUB
Cluster 1
Cluster 2
Cluster 3
To PCS CAN
Cluster 1
Cluster 2
Cluster 3
8.Key operation
Power button
Situstion
Touch
Definition
Press(＜2S)
No reaction
System off
Press(≥2S)
Power on
System on
Press once
Shut down
Note: When multiple battery syetem are used in parallel connection, you only need to press one key of any
module to start the system.and also press one key to shut down the battery system.
9.Service and contact
Shenzhen Growatt New Energy CO.,Ltd
4-13/F,Building A,Sino-German,Europe,Industrial Park,
Hangcheng Ave,Guxing Community,Xixiang Subdistrict,
Bao'an District,shenzhen,China.
service@ginverter.com
86 0755 2747 1942
W:www.ginverter.com
. . .
Cluster 8
...
Cluster 8
Press
Growatt New Energy
5
Quick Installation Manual
1.Installation environment
Max. +50℃
Min. 0℃
RH.+5%~+85%
2.Installation tools
3.Battery size
650mm
350mm
4.Check
4-1
Check AXE 5.0L packing list
Quick installation Manual * 1
AXE 5.0L *1
Warranty card *1
Certificate of conformity *1
AXE 5.0L
Indoor installation
User Mannual *1
