2) Rear port
The iWall 360 device back side, the interfaces as following:
12V power connector with lock
Reset button, after 5s pf push, device IP will reset as 192.168.1.25;
each individual window would be reset as full window display;
LAN1, RJ-45 connector, controls device by connect PC or router;
LAN2 used for cascading of additional devices;
When power on, POWER lights on;
When device is working normally, RUN light on;
When signal input connected, INPUT lights on;
5
HDMI input;
Status light:
