10. Components
Temperature sensors
All temperature sensor have the same measuring range:
Congelador y conservador
）
R(KΩ
T(ºC)
1kΩ
45 °C
1.5kΩ
35 °C
1.8kΩ
30 °C
2.2kΩ
25 °C
2.7kΩ
19 °C
3.3kΩ
14 °C
3.9kΩ
10 °C
4.7kΩ
5.5 °C
5.6kΩ
1.5 °C
6kΩ
0 °C
（
Tª(ºC)
R
KΩ
45 °C
2.15kΩ
35 °C
3.26kΩ
30 °C
4.02kΩ
25 °C
5kΩ
19 °C
6.53kΩ
14 °C
8.23kΩ
10 °C
9.95kΩ
5.5 °C
12.3kΩ
1.5 °C
15kΩ
0 °C
16.3kΩ
Important: To check the temperature sensors:
-
They must be disconected from the control board.
-
Real temperature must be measured in order to compare it with the sensor
measurement.
Service Manual:
MSFR19010 EN
Service Manual
RBF 78720/78630/74620
T(ºC)
-12 °C
-15 °C
-20 °C
-24 °C
-31.5 °C
-35.5 °C
Desescarche
）
Tª(ºC)
-12 °C
-15 °C
-20 °C
-24 °C
-31.5 °C
-35.5 °C
）
R(KΩ
-1 °C
6.2kΩ
-3 °C
6.8kΩ
-5 °C
7.5kΩ
-7 °C
8.2kΩ
10kΩ
12kΩ
15kΩ
18kΩ
27kΩ
33kΩ
（
）
R
KΩ
-1 °C
17.1kΩ
-3 °C
19kΩ
-5 °C
21.1kΩ
-7 °C
23.5kΩ
30.8kΩ
36.5kΩ
48.6kΩ
61.5kΩ
98kΩ
12.6kΩ
- 11 -
