Adventure 2.0
Electric Bike.
A guide for your ride.
IMPORTANT: READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE.
MODEL: JADV11-BLK
Designed in Brooklyn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Adventure 2.0 2022 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jetson Adventure 2.0 2022

Summary of Contents for Jetson Adventure 2.0 2022

  • Page 1 Adventure 2.0 Electric Bike. A guide for your ride. IMPORTANT: READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE. MODEL: JADV11-BLK Designed in Brooklyn...
  • Page 3 Jetson's top two riding rules: Be safe. Have fun!

  • Page 4: Table Of Contents

    Contents Safety Warnings ........................4 Safety Checklist .
  • Page 5 Charging the Battery .......................4 2 Checking & Inflating the Tires ....................4 4 3. Features & Functions Powering On & Off ......................4 6 Understanding &...

  • Page 6: Safety Warnings

    Safety Warnings • Before use, please read the user manual and safety warnings carefully, and make sure you understand and accept all the safety instructions. The user will be responsible for any loss or damage caused by improper use. • Please check the drive system and frame before riding to ensure safety. •...
  • Page 7 • Applying brakes too hard or too suddenly can lock up a wheel, which could cause you to lose control and fall. Sudden or excessive application of the brake may result in injury or death. • If the brake loosens, please adjust with the hexagon wrench, or please contact the Jetson Care Team. • Replace worn or broken parts immediately.
  • Page 8 For all maintenance repairs and needs beyond the capability of the consumer, which may include but not be limited to: such as proper maintenance of brakes, control cables, bearing adjustments, wheel adjustments, lubrication, reflectors, tires and handlebar and seat adjustments, please contact the Jetson Care Team for assistance at: ridejetson.com/support ridejetson.com/chat...

  • Page 10: Safety Checklist

    Safety Checklist INSTRUCTIONS PERTAINING TO RISK OF FIRE OR ELECTRIC SHOCK. IMPORTANT SAFETY INSTRUCTIONS A) READ ALL THE INSTRUCTIONS BEFORE USING THE PRODUCT. B) TO REDUCE THE RISK OF INJURY, CLOSE SUPERVISION IS NECESSARY WHEN THE PRODUCT IS USED NEAR CHILDREN. C) DO NOT PUT FINGERS OR HANDS INTO THE PRODUCT.

  • Page 11: Warranty Coverage

    ONE-YEAR GENERAL LIMITED WARRANTY All new Jetson products are warranted against defects in materials and workmanship for a period of one year from the date of original retail purchase when used in accordance with Jetson's user manuals (refer to ridejetson.com/support).

  • Page 12: Product Overview

    Product Overview HANDLEBAR* REAR LIGHT FRONT DISC BRAKE HEADLIGHT REAR REFLECTOR* FRONT WHEEL* CHARGING PORT WITH COVER PEDALS * FRONT FORK SUSPENSION BIKE FRAME (X2, LEFT AND RIGHT) CHARGER SEAT CLAMP KICKSTAND CHARGING CABLE SEAT REAR DISC BRAKE * NOT PRE-ATTACHED. REQURIES ASSEMBLY HARDWARE &...
  • Page 13 NOTE: IMAGES MAY NOT REFLECT EXACT APPEARANCE OF ACTUAL PRODUCT.
  • Page 14 LCD SCREEN LEFT/LARGE GEAR DISPLAY FRONT REFLECTOR RIGHT/SMALL GEAR DISPLAY LEFT BRAKE LEVER (FRONT BRAKE) CHAINRING SHIFTERS (3 CHAINRINGS) RIGHT BRAKE LEVER (REAR BRAKE) GEAR SHIFTERS (7 GEARS) HANDLEBAR CLAMP CONTROL BUTTONS (POWER, + , - ) BELL * 21 GEARS IN TOTAL...

  • Page 15: Specs & Features

    Specs & Features • PRODUCT DIMENSIONS: 73.5" (L) X 24.75" (W) X 42" (H) • MOTOR: 250W • PRODUCT WEIGHT: 41 LBS • MAX SPEED USING PEDAL ASSIST: 20 MPH • TIRE SIZE: 27.5" • MAX RANGE USING PEDAL ASSIST: 22 MILES •...

  • Page 16: Online Resources

    Online Resources Scan for our most updated Adventure onboarding materials and support resources. WARNING FAILURE TO COMPLY WITH THE FOLLOWING INSTRUCTIONS MAY RESULT IN INJURY TO THE CHILD OR OTHERS. • KEEP SMALL PARTS AWAY FROM CHILDREN DURING ASSEMBLY. • ACCESSORY MUST BE ASSEMBLED AND REMOVED BY AN ADULT. •...

  • Page 17: Getting Started

    1. Getting Started IMPORTANT: THE DIRECTIONS GIVEN IN THIS MANUAL—RIGHT, LEFT, FRONT, REAR—ARE ORIENTED AS THE RIDER WOULD SEE THEM WHEN SITTING ON THE BICYCLE. THE “RIGHT SIDE” OF THE BIKE, FOR EXAMPLE, IS THE SIDE WHERE THE RIDER’S RIGHT HAND AND RIGHT FOOT WILL BE.
  • Page 18 3. ROTATE THE CLAMP SO THAT IT AND THE FRONT FORK ARE FACING FORWARD.
  • Page 19 4. LIFT THE HANDLEBAR ONTO THE CLAMP BASE AND POSITION IT SUCH THAT IT IS: • NESTLED INTO THE CURVED BOTTOM OF THE CLAMP. • ORIENTED WITH THE LCD SCREEN ON THE LEFT-HAND SIDE OF THE HANDLEBAR. • CENTERED AND BALANCED IN THE CLAMP. HANDLEBAR CLAMP BASE...
  • Page 20 5. PLACE THE CLAMP COVER ONTO THE CENTER OF THE HANDLEBAR SUCH THAT: • THE 4 HOLES IN THE COVER ARE ALIGNED WITH THE FOUR HOLES IN THE CLAMP BASE. • THE COVER IS SNUG OVER THE CURVE OF THE HANDLEBAR. 6.
  • Page 21 7. CHECK THAT THE HANDLEBAR IS SECURE.

  • Page 22: Attaching The Front Wheel

    Attaching the Front Wheel 1. GENTLY FLIP THE BIKE OVER SO THAT IT IS UPSIDE DOWN AND RESTING ON THE HANDLEBAR AND SEAT. 2. CHECK THAT ALL PLASTIC PACKAGING PROTECTIONS ARE REMOVED FROM THE WHEEL AND FRONT FORK. FRONT FORK...
  • Page 23 3. TWIST THE KNOB ON THE QUICK RELEASE SKEWER COUNTERCLOCKWISE TO LOOSEN AND REMOVE IT. REMOVE SPRING "A" FROM THE SKEWER, AND OPEN THE LATCH. SPRING "A" SPRING "B" LATCH KNOB...
  • Page 24 4. LOCATE THE SIDE OF THE FRONT WHEEL WITH THE DISC. INSERT THE END OF THE QUICK RELEASE SKEWER THROUGH THE HOLE IN THE CENTER OF THE WHEEL ON THE SIDE OPPOSITE THE DISC, AND PUSH IT THROUGH TO THE DISC SIDE. 5.
  • Page 25 DISC DISC BRAKE PAD FRONT FORK 7. POSITION THE FRONT WHEEL IN BETWEEN THE FRONT FORK SUCH THAT THE DISC SIDE OF THE WHEEL IS ON THE SIDE OF THE FORK WITH THE BRAKE COMPONENTS. 8. SLIDE THE WHEEL DOWN INTO PLACE, WITH THE DISC IN BETWEEN THE BRAKE PADS AND THE TWO SPRINGS ON THE SKEWER SITUATED IN THE NOTCHES AT THE END OF THE FORK.
  • Page 26 9. WHEN THE WHEEL IS CENTERED AND IN PLACE, TIGHTEN THE KNOB ON THE SKEWER BY TURNING IT CLOCKWISE. CLOSE THE LATCH ON THE QUICK RELEASE SKEWER. IMPORTANT: ENSURE THAT THE WHEEL IS SECURELY CLAMPED ONTO THE FRONT FORK WITH THE SKEWER. IF THE SKEWER IS PROPERLY TIGHTENED, CLOSING THE SKEWER LATCH SHOULD BE MET WITH SOME RESISTANCE AT THE BEGINNING AND THEN REQUIRE FORCEFUL EFFORT TO FULLY CLOSE.
  • Page 27 10. CHECK THAT THE WHEEL SPINS FREELY AND IS SECURED IN PLACE IN THE FORK. TROUBLESHOOTING: IF YOU CANNOT OPEN OR CLOSE THE LATCH ON THE QUICK-RELEASE SKEWER, LOOSEN THE KNOB LITTLE BY LITTLE UNTIL YOU CAN DO SO. DO NOT OVER-LOOSEN: YOU SHOULD FEEL SOME TENSION WHEN OPENING AND CLOSING THE LATCH.

  • Page 28: Attaching The Rear Reflector

    Attaching the Rear Reflector YOU WILL NEED THE SCREWDRIVER. 1. FLIP THE BIKE OVER SO THAT IT IS UPRIGHT AND REST IT ON THE KICKSTAND (REFER TO PAGE 54 OF THIS MANUAL.) KICKSTAND...
  • Page 29 2. PULL OPEN THE LATCH ON THE SEAT CLAMP. 3. PULL THE SEAT UPWARDS UNTIL THE SEAT POST EMERGES FROM THE SEAT TUBE, AND SET THE SEAT ASIDE. SEAT POST SEAT TUBE SEAT CLAMP LATCH...
  • Page 30 4. SLIDE THE ROUNDED END OF THE TAB ON THE SEAT CLAMP INTO THE CHANNEL ON THE BACK SIDE OF THE REFLECTOR. CHECK THAT THE REFLECTOR IS SECURE ON THE CLAMP. REFLECTOR (BACKSIDE) SEAT CLAMP...
  • Page 31 PHILLIPS-HEAD SCREWDRIVER 5. LOOSEN THE SCREW ON THE REFLECTOR CLAMP BY TURNING IT COUNTERCLOCKWISE WITH THE PHILLIPS-HEAD SCREWDRIVER. REMOVE IT FROM THE NUT AND THE CLAMP, AND SET THE HARDWARE ASIDE. SCREW...
  • Page 32 6. SLIDE THE REFLECTOR CLAMP UP ONTO THE SEAT POST SO THAT THE REFLECTOR SIDE IS UNDERNEATH THE BACK (WIDEST PART) OF THE SEAT. 7. REINSERT THE SCREW INTO THE ROUNDED HOLE OF THE CLAMP. POSITION THE NUT IN THE HEXAGONAL HOLE OPPOSITE THE SCREW.
  • Page 33 8. LOWER THE SEAT POST BACK INTO THE SEAT TUBE AT LEAST UNTIL THE MINIMUM INSERTION MARK GOES BELOW THE CLAMP, AND THEN CLOSE THE CLAMP LATCH. MINIMUM INSERTION MARK SEAT CLAMP LATCH...

  • Page 34: Attaching The Pedals

    CRANK ARM SPINDLE RIGHT PEDAL Attaching the Pedals YOU WILL NEED THE WRENCH. 1. ALIGN THE SPINDLE ON PEDAL MARKED "R" WITH THE HOLE AT THE END OF THE CRANK ARM ON THE RIGHT SIDE OF THE BIKE. 2. HOLD THE PEDAL BASE STEADY AND, TAKING CARE THAT THE SPINDLE ENTERS THE HOLE STRAIGHT, USE YOUR OTHER HAND TO TWIST THE SPINDLE CLOCKWISE INTO THE HOLE FOR A FEW ROTATIONS.
  • Page 35 WRENCH 3. USE THE 15 MM WRENCH TO FINISH INSERTING AND THEN TIGHTENING THE SPINDLE INTO THE CRANK ARM BY TURNING THE WRENCH CLOCKWISE ON THE PEDAL.
  • Page 36 4. CHECK THAT THE RIGHT PEDAL IS SECURE. 5. REPEAT STEPS 2 – 5 WITH THE LEFT ("L") PEDAL. IMPORTANT: THE SPINDLE ON THE LEFT PEDAL IS REVERSE THREADED AND NEEDS TO BE INSERTED AND TIGHTENED WITH COUNTERCLOCKWISE TURNS. CAUTION: IF YOU FEEL RESISTANCE WHEN INSERTING THE PEDALS INTO THE HOLES ON THE CRANK ARM, THE SPINDLE COULD BE ENTERING AT AN ANGLE INSTEAD OF STRAIGHT ON.

  • Page 37: Securing The Bell

    Securing the Bell YOU WILL NEED THE SCREWDRIVER. 1. LOOSEN (BUT DO NOT REMOVE) THE SCREW ON THE BELL CLAMP BY TURNING IT COUNTERCLOCKWISE FOR 1 TO 2 ROTATIONS WITH THE SCREWDRIVER. 2. ROTATE THE BELL AROUND THE HANDLEBAR UNTIL IT IS IN A PLACE THAT CAN EASILY BE REACHED BY THE LEFT-HAND THUMB WHEN THE RIDER IS HOLDING ONTO THE HANDLEBAR.

  • Page 38: Securing The Front Reflector

    Securing the Front Reflector YOU MAY NEED THE SCREWDRIVER. 1. ROTATE THE FRONT REFLECTOR CLAMP AROUND THE HANDLEBAR UNTIL THE REFLECTOR IS FACING THE FRONT OF THE BIKE. 2. SLIDE THE REFLECTOR TOWARDS THE CENTER OF THE HANDLEBAR UNTIL THE REFLECTOR CLAMP FEELS SNUG ON THE THICKER PART OF THE HANDLEBAR.

  • Page 39: Preparing To Ride

    2. Preparing to Ride Setting the Seat Height WHEN A RIDER IS SITTING ON THE SADDLE AND HAS A FOOT ON THE PEDAL AT THE LOWEST PEDAL ROTATION POINT, THERE SHOULD BE A SMALL BEND IN THE KNEE. LEGS SHOULD NEVER BE FULLY EXTENDED DURING PEDALING. 1.
  • Page 40 2. RAISE OR LOWER THE SEAT TO THE DESIRED POSITION. IMPORTANT: DO NOT TO RAISE THE SEAT HIGH ENOUGH THAT THE“MINIMUM INSERTION” MARK COMES INTO VIEW ABOVE THE CLAMP. (IF THE SEAT CLAMP IS TOO TIGHT FOR THE POST TO SLIDE UP AND DOWN EASILY, WIDEN THE CLAMP OPENING BY TURNING THE CLAMP KNOB COUNTERCLOCKWISE.) 3.
  • Page 41 4. CHECK THAT THE SEAT IS SECURE: USE YOUR HAND TO PUT DOWNWARD PRESSURE ON THE SADDLE. IF THE SEAT POST SLIPS FURTHER DOWN INTO THE TUBE, BRING IT BACK TO POSITION AND TIGHTEN THE CLAMP BY TURNING THE KNOB CLOCKWISE.

  • Page 42: Adjusting The Angle Of The Seat

    Adjusting the Angle of the Seat YOU WILL NEED THE 6MM (LONGEST-LENGTH) ALLEN KEY. 1. USING THE 6MM ALLEN KEY, LOOSEN THE BOLT ON THE UNDERSIDE OF THE SEAT (WITHOUT REMOVING IT) BY TURNING IT CLOCKWISE FOR 1 TO 2 ROTATIONS. ALLEN KEY...
  • Page 43 2. ADJUST THE ANGLE OF THE SEAT BY TILTING IT FORWARDS OR BACKWARDS UNTIL IT IS IN THE DESIRED POSITION. 3. WHILE HOLDING THE SEAT IN PLACE, TIGHTEN THE BOLT BY TURNING IT COUNTERCLOCKWISE. 4. CHECK THAT THE SEAT IS SECURE. ALLEN KEY...

  • Page 44: Charging The Battery

    Charging the Battery IT CAN TAKE UP TO 6 HOURS TO BRING A BATTERY TO FULL CHARGE. 1. CONNECT THE CHARGING CABLE WITH THE CHARGER. 2. PULL OPEN THE CHARGING PORT COVER ON YOUR ADVENTURE. CHARGING PORT 3. PLUG THE CHARGING CABLE INTO THE WALL, AND THEN PLUG THE CHARGER INTO THE CHARGING PORT.
  • Page 45 IMPORTANT CHARGING NOTES: • FOR BEST BATTERY AND CHARGER HEALTH, CHARGE THE ADVENTURE IN TEMPERATURES BETWEEN 14° F AND 113° F (-10 - 45° C). • ONLY USE THE INCLUDED CHARGER. • ALWAYS KEEP THE CHARGING PORT CLOSED WHEN NOT ACTIVELY CHARGING THE ADVENTURE. •...

  • Page 46: Checking & Inflating The Tires

    DUST CAP VALVE Checking & Inflating the Tires BEFORE YOUR FIRST RIDE, YOU WILL NEED TO ADD AIR TO YOUR TIRES TO BRING THEM TO WITHIN THE RECOMMENDED PRESSURE OF 45 – 60 PSI (POUNDS PER SQUARE INCH). USE A GAUGE TO CHECK THAT YOUR TIRE PRESSURE FALLS WITHIN THIS RANGE PRIOR TO EVERY RIDE.
  • Page 47 AIR PUMP 2. FOLLOW THE MANUFACTURER’S INSTRUCTIONS ON YOUR AIR PUMP TO INSERT AIR INTO THE TIRE. CHECK PERIODICALLY WITH A GAUGE AND CONTINUE ADDING AIR UNTIL YOU REACH 45 – 60 PSI. 3. REMOVE THE AIR PUMP AND REPLACE THE DUST CAP BY TWISTING IT ON CLOCKWISE.

  • Page 48: Features & Functions

    AWAY FOR THE NIGHT. Understanding & Using the LCD Screen IMPORTANT: IF AN ERROR CODE (P04 – P09) POPS UP ON YOUR LCD SCREEN, CONTACT THE JETSON CARE TEAM AT RIDEJETSON.COM/CHAT FOR ASSISTANCE BEFORE RIDING YOUR ADVENTURE AGAIN. LCD SCREEN...
  • Page 49 CHECKING BATTERY CHARGE LEVEL YOU CAN KEEP TABS ON YOUR BATTERY’S CHARGE LEVEL BY LOOKING TO BATTERY INDICATOR ICON ON THE LCD SCREEN. NUMBER OF BARS DISPLAYED LESS THAN 25 % BATTERY CHARGE LEVEL 76 - 100% 51 - 75% 26 - 50% (CHARGE YOUR ADVENTURE NOW!) CHANGING DISPLAY SETTINGS...
  • Page 50 ADJUSTING THE BRIGHTNESS LEVEL 1. PRESS AND HOLD THE PLUS (+) AND MINUS (-) BUTTONS TOGETHER FOR THREE SECONDS TO ENTER THE SETTINGS MENU. “P00” WILL DISPLAY ON THE SCREEN. 2. USE THE (+) OR (-) BUTTON TO NAVIGATE TO “P01” (SCREEN BRIGHTNESS) 3.

  • Page 51: Using Walk Assist

    Using Walk Assist IN WALK ASSIST MODE, THE MOTOR WILL PROPEL THE BIKE FORWARD AT 3.7 MPH TO MAKE FOR EASIER TRANSPORT WHILE YOU ARE WALKING WITH IT. TO TURN ON WALK ASSIST: PRESS AND HOLD THE MINUS (-) BUTTON WHILE WALKING YOUR BIKE. TO TURN OFF WALK ASSIST: RELEASE THE MINUS (-) BUTTON.

  • Page 52: Using The Lights

    Using the Lights THE HEADLIGHT IF RIDING IN LOW LIGHT CONDITIONS, TURN ON THE HEADLIGHT SO YOU CAN BETTER SEE THE ROAD AHEAD AND ON- COMING RIDERS CAN BETTER SEE YOU. THE HEADLIGHT WILL ONLY POWER ON WHEN THE MOTOR IS ALSO TURNED ON. TO TURN ON OR OFF THE HEADLIGHT, HOLD DOWN THE PLUS (+) BUTTON.
  • Page 53 THE REAR LIGHT THE REAR LIGHT RUNS OFF OF 2 AAA BATTERIES (INCLUDED AND PRE-INSTALLED). TO PRESERVE BATTERY POWER, ALWAYS REMEMBER TO TURN OFF THE REAR LIGHT AFTER A RIDE. TO TURN ON OR OFF: QUICK-PRESS THE BUTTON ON THE BACK SIDE OF THE LIGHT. REAR LIGHT POWER BUTTON...
  • Page 54 TO CHANGE THE BATTERY: 1. REMOVE THE REAR LIGHT FROM THE SEAT POST BY UNFASTENING THE STRAP FROM THE HOOK. 2. USE YOUR FINGERS OR A SLIM TOOL TO REMOVE THE RED COVER OFF OF THE BASE. 3. REMOVE THE OLD AAA BATTERIES AND REPLACE WITH NEW ONES, INSERTING THEM FOLLOWING THE + AND –...

  • Page 55: Using The Bell

    Using the Bell USE THE BELL AS AN ALERT TO OTHER RIDERS AND PEDESTRIANS. TO SOUND THE BELL, FLICK DOWN ON THE BELL TAB QUICKLY AND FORCEFULLY WITH YOUR LEFT-HAND THUMB. BELL BELL TAB...

  • Page 56: Using The Kickstand

    Using the Kickstand TO USE THE KICKSTAND, PIVOT IT DOWN AND GENTLY TILT YOUR BIKE ONTO IT TO STAND. TO RAISE THE KICKSTAND, PIVOT IT BACK UP. IMPORTANT: ALWAYS RAISE THE KICKSTAND BEFORE RIDING.

  • Page 57: Making Moves

    4. Making Moves Riding with Pedal Assist THE ADVENTURE FEATURES TORQUE PEDAL ASSISTANCE, IN WHICH THE AMOUNT OF ASSISTANCE PROVIDED BY THE MOTOR IS CORRELATED TO THE AMOUNT OF POWER THAT YOU PUT INTO YOUR PEDALING, NOT THE SPEED (CADENCE) AT WHICH YOU PEDAL.
  • Page 58 TO CHANGE PEDAL ASSIST MODES: USE THE PLUS (+) AND MINUS (-) BUTTONS. PEDAL ASSIST MODE PEDAL ASSISTANCE TO NO ENGAGEMENT 8 MPH 11 MPH 14 MPH 17 MPH 20 MPH FROM THE MOTOR. BRING THE SPEED TO TO RIDE YOUR ADVENTURE WITHOUT ANY PEDAL ASSISTANCE, SET THE PEDAL ASSIST MODE TO 0 AND THE MOTOR WILL DISENGAGE.

  • Page 59: Using The Gears

    Using the Gears REAR DERAILLEUR FRONT DERAILLEUR (7 GEARS) (3 CHAINRINGS) THE ADVENTURE IS A 21-SPEED BIKE, WITH 3 CHAINRINGS ON THE FRONT DERAILLEUR AND 7 GEARS ON THE REAR DERAILLEUR. LOWER GEARS MAKE FOR EASIER PEDALING BECAUSE THERE IS LESS RESISTANCE, BUT YOU’LL COVER LESS GROUND WITH EACH PEDAL STROKE.
  • Page 60 CHAINRING L (LOW) M (MEDIUM) H (HIGH) GEARS 1 - 7 8 - 14 15 - 21 CHAINRING DOWNSHIFT CHAINRING UPSHIFT THE 3 CHAINRINGS ON THE FRONT DERAILLEUR ARE CONTROLLED BY THE SHIFTERS ON THE LEFT SIDE OF THE HANDLEBAR. •...
  • Page 61 GEAR UPSHIFT GEAR DOWNSHIFT THE 7 GEAR SPROCKETS ON THE REAR DERAILLEUR ARE CONTROLLED BY THE SHIFTERS ON THE RIGHT SIDE OF THE HANDLEBAR. • TO UPSHIFT TO A HIGHER GEAR WITHIN THE SAME CHAINRING SET, PUSH THE LEFT OF THE TWO SHIFTERS WITH YOUR RIGHT-HAND THUMB.

  • Page 62: Using The Brakes

    Using the Brakes LEFT HANDBRAKE RIGHT HANDBRAKE SQUEEZE ONE OR BOTH HANDBRAKES TO SLOW DOWN; SQUEEZE MORE FORCEFULLY TO COME TO A COMPLETE STOP. TO AVOID ABRUPT MOVEMENTS, TRY TO SQUEEZE THE HANDBRAKE(S) GRADUALLY. • LEFT HANDBRAKE FRONT WHEEL BRAKE •...

  • Page 63: Helmet Safety

    Helmet Safety PROPER POSITIONING: IMPROPER POSITIONING: THE FOREHEAD IS COVERED THE FOREHEAD IS EXPOSED. BY THE HELMET. A FALL COULD RESULT IN SERIOUS INJURY. * WEAR A HELMET, APPROPRIATE CLOTHING, SHOES, AND SAFETY GEAR. AVOID CLOTHING THAT CAN GET CAUGHT INTO OR UNDER THE WHEELS.

  • Page 64: Care & Maintenance

    • Avoid intense physical impact and/or severe vibration. • Protect from water or moisture. • Do not disassemble. • If there are any issues with the battery, contact the Jetson Care Team. STORING THE ADVENTURE • Remove batteries from rear light before storing.
  • Page 66 Stay connected. Be sure to follow @ridejetson on social media to learn about fantastic offers, giveaways, and all the latest Jetson news. Loving your ride? Then be sure to leave a review at ridejetson.com/reviews. We can’t wait to hear from you!
  • Page 68 1-year limited warranty or inquire about warranty coverage, contact us directly. US/CANADA: 1-888-976-9904 Manufactured in Shenzhen, China Imported by Jetson Electric Bikes LLC. P.O. Box 320149, 775 4th Ave #2, Brooklyn, NY 11232 www.ridejetson.com Made in China Date Code: 10/2022...
