- Page 1 11.11.1 PRODUCT TECHNICAL AND OPERATIONAL DOCUMENTATION INSTALLATION MANUAL Awnings 11.11 Balcony awning ITALIA BALCONY 11.11.1 Installation manual Documentation no. 11.11.1 – EN...
- Page 2 PRODUCT TECHNICAL AND OPERATIONAL DOCUMENTATION Installation manual 11.11.1 DT-E PRODUCT NAME BALCONY AWNING ITALIA BALCONY PRODUCT MANUFACTURER’S MARKING: Manufacturer’s name: SELT Sp. z o.o. Manufacturer’s head office: 45- 449 Opole, ul. Wschodnia 23A Website www.selt.com Plant address : ...
-
Page 3: Table Of Contents
Table of contents Introduction ............................4 Product safety tips........................4 Notes on symbols and marks ..................... 4 Definitions ..........................5 Subject, designation and contents of the documentation ............5 Product technical information ......................6 Technical parameters ......................... 6 Italia awning construction......................7 Product installation ........................... -
Page 4: Introduction
Introduction Product safety tips The product was manufactured in accordance with the latest know-how in the area of constructing and manufacturing technology and is delivered in condition assuring operational safety. Safe product construction was achieved thanks to: Subject European legal basis Polish legal basis External blinds. -
Page 5: Definitions
SELT SP. Z O.O. shall not bear responsibility for damage resulting from failure to follow recommendations included in the documentation. In order to further improve the product, SELT SP. Z O.O. reserves the right to introduce changes which, while maintaining the essential technical parameters, shall be deemed purposeful for improving product operation quality and safety of use. -
Page 6: Product Technical Information
Product technical information Product technical specification is available at www.selt.com after log in. Technical parameters Projection: 0,7m Minimum width 30 cm Maximum width 5,0 m Roller tube diameter 70 mm Arms Lowered, aluminum Tilt angle 0° - 160° Manual drive... -
Page 7: Italia Awning Construction
Italia awning construction DT-E 11.11.1 BALCONY AWNING ITALIA BALCONY Edition: March 2017, Issue 2 English page 7 / 19... -
Page 8: Product Installation
Product installation The following part covers general requirements of the product installation. Proper installation is necessary for efficient operation of the product. SELT SP. Z O.O. recommends to use services of skilled installation crews what guarantees the Purchaser proper installation. -
Page 9: Preparation To Installation
Preparation to installation unpack product and check if it contains all necessary elements for installation, make sure that the base where product will be mounted provides sufficient bearing capacity for safe installation and operation of the product, prepare set of tools necessary for installation. -
Page 10: Installation Tools
Awning installation, adjustment and test its testing can be carried out by service crew or trained persons only. Person conducting the installation and first run is responsible for appropriate fixing of the awning including fixing elements, allowing for its correct operation and parameters. Improper installation may cause hazardous situation for the user. - Page 11 1) Prepare 2) Start the installation with marking installation spots for brackets. Level the installation tools bracket vertically with spirit level and mark places for installation holes. according to the list. 3) Drill in marked places. 4) Fix installation anchors. 5) Install wall bracket (from the drive side).
- Page 12 8) Put the second bracket on the round pin with 9) Level the awning horizontally with spirit level. slide bearing. 10) Mark the installation spot for the second bracket. Pay particular attention so that brackets are installed at the same horizontal level and in the same plane. 11) Take off the awning and drill holes in marked places.
- Page 13 12) Fix installation 13) Screw on the bracket. anchors. 14) Set up the awning with plug and square pin 15) Put the awning with the round pin and slide on the bracket from the drive side. bearing into the second bracket. Block the bearing with Allen screw.
- Page 14 17) Start the arms installation with marking the fixing spots for arm brackets on the balustrade. 18) Drill holes in marked spots. 19) Fix the arm to the balustrade. 20) Fix the second arm in the same manner. 21) Slide eyelets to the groove in the front bar. 22) Release the arms blocade with a handwheel.
- Page 15 23) Secure the eyelets with screws. 24) Fix the front bar side covers with screws. 25) The eyelets can be also fix to the arm hook (as shown in the picture). DT-E 11.11.1 BALCONY AWNING ITALIA BALCONY Edition: March 2017, Issue 2 English page 15 / 19...
-
Page 16: Manual Drive
Manual drive Setting the awning tilt angle is performed: by unlocking the arm blocade with a handwheel with the use of a crank by blocking the arms with a handwheel After setting the tilt angle, proper fabric tension is provided by slightly rolling up the excess of fabric. ... -
Page 17: Final Remarks
Awning is delivered with installed arms, fabric and wall brackets, with accompanying additional packages. Selt SP. Z O.O. makes every effort to ensure that the goods are produced in accordance with the order. To check the completeness of the product is purchaser’s duty and it should be conducted at the time of delivery. -
Page 18: Marking And Labelling The Product With Ce Mark
6 Marking and labelling the product with CE mark Product compliance with the CE standard Products manufactured by SELT company meet the essential requirements of the standard introduced by the Polish Committee for Standardization as PN-EN 13561, which is confirmed by the manufacturer’s declaration of performance and marking the product with the CE mark. - Page 19 Marking on accompanying documents SELT Sp. z o.o. OPOLE, ul. Wschodnia 23A POLAND EN 13561 Balcony awning ITALIA BALCONY 500x70 For external use. Wind load resistance: 1 class Total solar energy transmittance g tot: 0,01-0,90* DWU 24 / M / 2017 DT-E 11.11.1 BALCONY AWNING ITALIA BALCONY...
