- Page 1 DT-E DT-E TECHNICAL AND OPERATIONAL DOCUMENTATION INSTALLATION AND OPERATING MANUAL AND INSTRUCTIONS FOR SAFE USE Sun protection screen Venetian Blind 1.1. Venetian Blind C50 Slim...
- Page 2 PRODUCT NAME: SUN PROTECTION SCREEN VENETIAN BLIND C50 Slim PRODUCT MANUFACTURER’S MARKING: Manufacturer’s name: SELT Sp. z o. o. Manufacturer’s head office: 45- 449 Opole, ul. Wschodnia 23A POLAND Plant address: Façade and External Textile Roller Blind Department 45- 449 Opole, ul.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ............................... 4 1.1. Product safety tips ..........................4 1.2. Notes on symbols and marks ......................... 4 1.3. Definitions ............................. 5 1.4. Subject, designation and contents of the documentation ..............5 Product technical information ........................6 2.1. Technical parameters: ........................... -
Page 4: Introduction
INTRODUCTION 1.1. PRODUCT SAFETY TIPS The product was manufactured in accordance with the latest know-how in the area of constructing and manufacturing and is delivered in condition allowing for its safe use. Safe construction of the product is achieved by: Subject European legal basis Polish legal basis... -
Page 5: Definitions
SELT Sp. z o. o. with a head office in Opole shall hold the copyrights to this documentation. The documentation cannot be used without permission, either partially or as a whole, for any concurrent business activity nor can it be made available to third parties. -
Page 6: Product Technical Information
PRODUCT TECHNICAL IN FORMATION Product technical specification is available at www.selt.com after log in. 2.1. TECHNICAL PARAMETERS : Dimensions: Width Height Thickness Electric drive 4000 mm 3500 mm Manual drive (up to 8m 4000 mm / 2200 mm 2200 mm / 3500 mm... -
Page 7: Product Characteristics
2.2. PRODUCT CHARACTERIST ICS Types of products: Installed in the inside of the building, operated by a electromechanical drive connected with the operating system, The products are characterised by the following qualities: they are designed for installation in the window area, ... -
Page 8: Product Transport And Storage
COMPLETENESS AND QUALITATIVE STATE OF DE LIVERY Selt Sp. z o. o. makes every effort to ensure that the goods are produced in accordance with the order. To check the completeness of the product is purchaser’s duty and it should be conducted at the time of delivery. Any discrepancies of the product with the order should be reported immediately to the driver/warehouseman/installers and noted in the proof of delivery at the risk of losing warranty. -
Page 9: Product Installation
PRODUCT INSTALLATION The following part covers general requirements of the product installation. Proper installation is necessary for efficient operation of the product. SELT Sp. z o. o. recommends to use services of skilled installation crews what guarantees the Purchaser proper installation. -
Page 10: General Guidelines For Installation
4.5. INSTALLATION Installation and operating manual and instructions for safe use is available after log in on www.selt.com. Internal mechanisms in the head rail can move during incorrect transport of the product (in vertical position). Therefore one should check the placement if mechanisms in the head rail before commencing the installation. - Page 11 Img. 2 Drill holes for fixing system. Img. 3. Img. 3 Fix the first bracket to the wall/ceiling so that further adjustment is possible. Img. 4 Fix second brackets to wall/ceiling. Img. 5 Img. 5 DT-E 1.1: SUN PROTECTION SCREEN – VENETIAN BLINDS C50 Slim Issue 2 / April 2017 / EN page 11 / 25...
-
Page 12: 4.5.2. C50 Slim Installation - Cable Guides
Check the vertical level of installed brackets. Correct if necessary. Img. 6 Img. 6 Install head rail with bundle in the brackets (Img. 7), and close the brackets (Img. 8). Img. 7 Close the bracket. Img. 8 4.5.2. C50 SLIM INSTALLATION – CABLE GUIDES Follow first points 1 to 5 from part 4.5.1. - Page 13 Install head rail with bundle in the brackets (Img. 2), and close the brackets (Img. 3). Img. 2 Close the bracket. Img. 3 With spirit level mark installation spot for angular cable guide brackets. Img. 4 Install angular cable guide brackets. Img.
- Page 14 Check the level of angular cable guide brackets. Img. 6 Put the bushes on cable guides. Img. 7 Secure the bushes on angular cable guide brackets. Img. 8 Tighten and lock the guides in bushes. Check the vertical level on guides. If correction is necessary, change the position of bush in the bracket appropriately.
-
Page 15: C50 Slim Installation - Manual Drive
Electrical connection and setup of the motors must be done in accordance with the manual of motor manufacturer. Manuals are added to the product as well as are available on motor manufacturer’s website and: www.selt.com → PRODUCTS → AUTOMATION Environmental conditions of increased threat: bathrooms and showers, kitchens, garages, cellars, saunas, rooms for domestic animals, operating theatres in hospitals, pump rooms, heat exchange rooms, spaces limited by conducing areas, campsites, open spaces, etc. - Page 16 When the product starts working attention should be paid to: correct opening and closing of the product correct activation of limit switches Incorrect connection of the motor can lead to product damage or create a hazardous situation. The engine has a thermal switch, which turns off the drive after about 4 minutes of continuous work to protect against overheating.
-
Page 17: System Operation And Product Safety
SYSTEM OPERATION AND PRODUCT SAFETY 5.1. GENERAL SAFETY REQUI REMENTS During product transport, assembly and disassembly, operation, care and maintenance, suitable regulations of industrial safety and environmental protection should be observed, The product should be maintained and repaired solely by the trained and suitably qualified personnel, ... -
Page 18: Operation Safety
Centrally controlled products can activate automatically. Make sure no dangerous situation arises. SELT Sp. z o. o. shall not be responsible for damage due to improper use. Operating the system out of one’s sight can result in heavy injuries as well as system damage. -
Page 19: Supervision Of Safe Product Use
5.4. SUPERVISION OF SAFE PRODUCT USE The Buyer should: in case safe product use depends on the conditions in which it is installed, submit the product to: preliminary check (after it has been assembled and before handing it over to operation), ... - Page 20 Possibly adjusting and improving the mounting of the changed sub-assembly. Products manufactured by SELT Sp. z o. o. do not require special maintenance treatment. Using the product in accordance with the manufacturer’s recommendations assures the user log-term and fault-free operation. Routine maintenance activities should be carried out on a maximally opened system.
-
Page 21: General Warranty Conditions
GENERAL WARRANTY CON DITIONS http://www.selt.com/doc-en General warranty conditions are available on In case of no access to the SELT website, the warranty conditions can be obtained from the sales representative of SELT Sp. z o. o. 7.1. EXCLUSIONS FOR WARRA NTY Warranty does not cover: ... -
Page 22: Complaints / Technical Faults
notifications can be sent to the email address reklamacje@selt.com or directly to the sales representative Complaints / faults should be made on the ‘complaint notification form’ which can be found on the website: www.selt.com,... -
Page 23: Product Disassembly / Utilisation / Disposal
PRODUCT DISASSEMBLY / UTILISATION / DISPOSAL Improper system disassembly can result in severe injuries and system damage. System disassembly should be commissioned to a properly qualified assembly team or to a person suitably trained within industrial safety and with the knowledge concerning recovery. Disposal of worn electrical and electronic equipment After the end of product lifetime it must be disassembled and separate material must be segregated according to Regulation of the Minister of Environment of 9 December 2014 on waste catalogue –... -
Page 24: 10. Marking And Labelling The Product With The Ce Mark
PRODUCT COMPLIANCE W ITH THE CE STANDARD Venetian blinds manufactured by SELT company meet the essential requirements of the standard introduced by the Polish Committee for Standardization as PN-EN 13120. Products with electric drive have declaration of conformity and are marked with the CE mark. -
Page 25: 11. Information On Safet Y Elements Installation
11. INFORMATION ON SAFET Y ELEMENTS INSTALLATION Young children can be strangled when the safety device is not installed and adjusted. Read carefully the instructions and install accordingly. Elements preventing strangulation available at SELT Sp. z o.o. Cord ending SLIM cord bracket...
