TECHNICAL AND OPERATIONAL DOCUMENTATION
DT-E
INSTALLATION AND OPERATING MANUAL
AND INSTRUCTIONS FOR SAFE USE
1.
Sun protection screen Venetian Blind
1.3. Venetian Blinds C80 and C80 L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Venetian Blind C80 and is the answer not in the manual?

Questions and answers

Related Manuals for SELT Venetian Blind C80

Summary of Contents for SELT Venetian Blind C80

  • Page 1 DT-E TECHNICAL AND OPERATIONAL DOCUMENTATION DT-E INSTALLATION AND OPERATING MANUAL AND INSTRUCTIONS FOR SAFE USE Sun protection screen Venetian Blind 1.3. Venetian Blinds C80 and C80 L...
  • Page 2  SUN PROTECTION SCREEN VENETIAN BLINDS C80 and C80 L PRODUCT MANUFACTURER’S MARKING:  Manufacturer’s name: SELT Sp. z o. o.  Manufacturer’s head office: 45- 449 Opole, ul. Wschodnia 23A  Plant address: Wydział Żaluzji Fasadowych i Refleksoli [Façade and External Textile Roller Blind Department] 45- 449 Opole, ul.

  • Page 3: Table Of Contents

    Installation of Venetian blind C80 with cube and oval guide rails (self-supporting product) ..13 4.5.3. installation of venetian blind C80 with cube and oval guide rail – group installation ....21 4.5.4. installation of venetian blind C80 – motor and cable guide ............29 4.5.5.

  • Page 4: Introduction

    INTRODUCTION 1.1. PRODUCT SAFETY TIPS The product was manufactured in accordance with the latest know-how in the area of constructing and manufacturing and is delivered in condition allowing for its safe use. Safe construction of the external product is achieved by: Subject European legal basis Polish legal basis...

  • Page 5: Definitions

    SELT Sp. z o. o. with a head office in Opole shall hold the copyrights to this documentation. The documentation cannot be used without permission, either partially or as a whole, for any concurrent business activity nor can it be made available to third parties.

  • Page 6: Product Technical Information

    PRODUCT TECHNICAL IN FORMATION Product technical specification is available at www.selt.com after log in. 2.1. TECHNICAL PARAMETERS : Maximum dimensions : Width Height Max. area Electric drive 4500 mm 5000 mm Manual drive 4500 mm 5000 mm Electric drive (cable guide)

  • Page 7: Product Characteristics

    COMPLETENESS AND QUALITATIVE STATE OF DE LIVERY Selt Sp. z o. o. makes every effort to ensure that the goods are produced in accordance with the order. To check the completeness of the product is purchaser’s duty and it should be conducted at the time of delivery. Any discrepancies of the product with the order should be reported immediately to the driver/warehouseman/installers and noted in the proof of delivery at the risk of losing warranty.

  • Page 8: Descriptions That Have To Be Put Obligatory On The Product Packaging

    PRODUCT INSTALLATION The following part covers general requirements of the product installation. Proper installation is necessary for efficient operation of the product. SELT Sp. z o. o. recommends to use services of skilled installation crews what guarantees the Purchaser proper installation.

  • Page 9: General Guidelines For Installation

    4.5. INSTALLATION www.selt.com Installation and operating manual and instructions for safe use is available after log in on Internal mechanisms in the head rail can move during incorrect transport of the product (in vertical position). Therefore one should check the placement if mechanisms in the head rail before commencing the installation.
  • Page 10 Connect the head rail bracket with main cover panel bracket. Then match them to the cover panel, adjust to its height and secure tightly. Img. 1 Fasten the set of brackets along with the cover panels and side panels (if they occur) to the wall or niche with an adequate tool.
  • Page 11 Put the head rail with bundle into the brackets, so that the label „strona od okna” faces the window. 10. Tighten the screws of the head rail brackets (img. 4). 11. Install the cover panel with side panels (if they occur);...
  • Page 12 12. Slide the guide rails brackets to the guides. Then secure the brackets in the guides by tightening the cone shaped screw. Img. 8 Img. 14 13. Slide the guide rail on the slat pins. Img. 15 14. Measure precisely the placement of guide rail axis.

  • Page 13: Installation Of Venetian Blind C80 With Cube And Oval Guide Rails (Self-Supporting Product)

    15. Screw the guide rails to the base. Img. 17 16. Measure precisely the placement of guide rails axis. Then tighten the elements of the bracket. Img. 18 17. Install guide rails end caps. Img. 19 After the installation is finished set the end positions and check the correct functioning of the blind. 4.5.2.
  • Page 14 Round guide rail bracket – cassette bracket Manner of installation  Place the fixing element into the guide rail groove.  Screw the set screw until the resistance is felt with allen wrench no. 4.  Screw tightening should be done with maximum half-turn (180°). NOTE: bigger turn will result in breaking the screw out from the bracket.
  • Page 15 Measure and mark the spots for guide rail brackets installation. Then install the brackets. Img. 1 According to previous measurements, install the brackets to the facade. Number of brackets depends on the product dimensions. During installation verify the dimensions and vertical and horizontal linearity of the brackets.
  • Page 16 Img. 7 Img. 8 Img. 9 Loosen cone shaped screws securing the bolts and pull the bolts out (img. 9 and 10). Img. 10 Slide the guide rails on brackets (img. 11-12). Img. 11 DT-E 1.3: SUN PROTECTION SCREEN – VENETIAN BLINDS C80P and C80L Issue 3 / April 2017 / EN page 16 / 62...
  • Page 17 Img. 12 Secure guide rails in brackets by tightening the cone shaped screw. Img. 13 Check the vertical level of the guide rail. Repeat points 4 and 5 to install the second guide rail. Img. 14 Check the level of the guides. Img.
  • Page 18 Connect head rail brackets to flat bars placed in the cassette. Img. 16 Loosen the installation flat bar on the cassette side. Img. 17 10. Connect the cassette with guide rails by sliding the installation flat bars into the guide rail channel, then tighten the screws with Allen wrench.
  • Page 19 11. Check the horizontal level of the cassette. It is necessary for correct functioning of the product. Img. 21 12. Install top end caps in the guide rails. Img. 22 13. Slide the head rail with slats bundle to the guide rails, remembering that the label „strona od okna”...
  • Page 20 14. Connect the installation cable and open about 30 cm of the blind to facilitate the installation of the bundle to the cassette. Img. 25 15. Install the head rail with bundle to open head rail brackets. Close the bracket and tighten the screws( img.

  • Page 21: Installation Of Venetian Blind C80 With Cube And Oval Guide Rail - Group Installation

    4.5.3. INSTALLATION OF VENE TIAN BLIND C80 WITH CUBE AND OVAL GUIDE RAIL – GROUP INSTALLATION Measure and mark the installation spot of the first guide rail bracket (img. 1-3). Img. 1 Img. 2 Img. 3 Install the bracket to facade with appropriate fixing system (img.
  • Page 22 Img. 6 Install the second bracket. Img. 7 Measure and mark the installation spot of the next bracket (img. 8), install the bracket (img. 7). Img. 8 Check the vertical level of the installed brackets, correct if necessary. Img. 9 DT-E 1.3: SUN PROTECTION SCREEN –...
  • Page 23 Measure and mark the installation place of the second guide rail (img. 10 and 11). Img. 10 Img. 11 Install the next bracket. Measurement and marking for the following brackets should be done similarly to the previous ones. Img. 12 Check the horizontal level of the installed brackets.
  • Page 24 10. Check the vertical level of installed brackets. Img. 14 11. Loosen cone shaped screws securing the bolts and pull the bolts out. Img. 15 Img. 16 12. Slide the guide rails on bracket bolts (img. 17), settle the guide rail (img. 18) and with Allen wrench tighten the cone shaped screws (img.
  • Page 25 Img. 18 Img. 19 13. Check the level of installed guide rails. Img. 20 14. Loosen the installation flat bar in the cassette so that it can be slide on the guide rails. Img. 21 15. Install to the cassette elastic head rail brackets and guide rail brackets.
  • Page 26 16. Put the cassette on guide rails. Img. 23 17. Check the vertical and horizontal level of the cassette (img.24-25). Img. 24 Img. 25 18. Tighten the installation screws. Img. 26 DT-E 1.3: SUN PROTECTION SCREEN – VENETIAN BLINDS C80P and C80L Issue 3 / April 2017 / EN page 26 / 62...
  • Page 27 19. Install the middle guide rail Img. 27 20. Insert the head rail with bundle to the guides. Img. 28 21. Put the head rail with bundle into the open bracket, so that the label „strona od okna” faces the window. Img.
  • Page 28 23. Install the consecutive bundles to brackets. Img. 31 24. Slide the cover profile to external guides (img. 32) and cut the excess at the level of the guides edges (img. 33). Img. 32 Img. 33 25. Put the guide rails end caps – (img. 34) and secure the locking screw with a triple square key (img.

  • Page 29: Installation Of Venetian Blind C80 - Motor And Cable Guide

    Img. 35 26. Install the revision cover (img. 36 – 37). Img. 36 Img. 37 With the installation cable check the correct functioning of the product and setting of end positions. 4.5.4. INSTALLATION OF VENE TIAN BLIND C80 – MOTOR AND CABLE GUIDE Pre-install the cable bracket to head rail, so that further adjustment is possible (img.
  • Page 30 Put the bush on the cable guide (img. 2). Tighten the screw, first with fingers until a resistance is felt, then use a flat wrench (img. 3), performing two full turns. Exceeding this scope results in overtightening the screw head. Img.
  • Page 31 With the use of spirit level mark the place of cable guide bracket installation. Img. 6 Install the angle bracket to the base. Img. 7 Put the cable through facade tightener. Img. 8 Install façade tightener to the bracket. Img. 9 DT-E 1.3: SUN PROTECTION SCREEN –...
  • Page 32 Secure the cable tightener by tightening the conical screw until a resistance is felt. Then use a Allen key performing 1,25-1,5 full turn, bearing in mind to leave some clearance required for correct tightener functioning. Exceeding the scope mention above results in damaging the screw socket or the wrench ending.

  • Page 33: Concealed Guide Rail Installation

    13. With the use of spirit level set the installation spot of the second cable guide bracket. Other steps should be performed in the same order as when installing the first bracket. Img. 14 Check if the brackets are installed in a secure manner – their movement apart can cause threat to people.
  • Page 34 Guidelines for installation of mounting profile:  Length of mounting profile equals total height of venetian blind minus 50 mm.  Installation of the profile is shown in Fig. 2.  Profile must be secured firmly to the base (cannot be loose) and be in linear and perpendicular position in relation to the blind.
  • Page 35 Measurements are taken by the Ordering Party who is responsible for their correctness. In case of dimensional inconsistency of the ordered system that is caused by measurements quality, SELT Sp. z. o. o Company is not responsible for venetian blinds not being possible to be mounted correctly.
  • Page 36 Fig. 3. Measurements of venetian blinds with concealed side guides: a) Single system, b) – Two blind module, c) – Multi- blind module. Installation of venetian blind with concealed side guide. 18. Before installation you must determine and mark location of the cover panel’s main brackets, so they don’t interfere with lifting mechanisms and with the motor.
  • Page 37 Assembled cover panels with their brackets secure to the wall/ niche with proper bolts. Tighten bolts of main cover panels to the wall/ceiling. Picture 2 Check level of mounted covers with their brackets, adjust if necessary. Proper levelling of the assembled system is essential for its proper operation.
  • Page 38 Fig. 4 Put the bundle of slats with head rail within the mounting profiles (for convenience of installation put the bundle at slight angle, so the pins are not damaged) Lift the bundle to the top to install the head rail in its brackets.

  • Page 39: Window Frame Guide Rail Installation

    Guide rail profiles must be installed in parallel to each other in all planes. SELT Sp. z o.o. company is not responsible for incorrect operation of the blinds with guide rail if the substructure does not provide straight and parallel installation of guide rail profiles.
  • Page 40 Fig. 6. Window frame guide rail installation: a) – window installation b) – niche installation Installation of Venetian Blind with window frame guide rail. Before commencing the installation of Venetian Blind it is necessary to measure and mark the placement of main brackets for cover panel in such place so that they do not collide afterwards with rolling mechanisms and motor.
  • Page 41 NOTE: For installation on window frame in the rear part of cover panels type 2, 4 and 4a it is necessary to cut on the left and right side small piece to enable the installation of guide rail. The cut should be done according to scheme from fig.
  • Page 42 Install window frame guide rail to window or window niche. Img. 6 Slide head rail with bundle into guide rails, so that the label „strona od okna” faces the window. Incorrect installation of the bundle will cause incorrect operation of the blind. For easier installation the bundle can be tilted, so that the pins are not damaged.
  • Page 43 14. Place profile on whole length of the window frame guide rail. Img. 10 15. Immobilise the ends of guiding profile with silicone installation glue or silicone hot glue. Img. 11 16. Install cover panel to auxiliary brackets. 17. Check correct operation of the blind. Img.

  • Page 44: C80 With Under-Plaster Cassette Installation

    Fig. 10. Fig. 9. Guide rail for under-plaster cassette – elements Fig. 10. Venetian Blind C80 BOX – with under-plaster cassette. DT-E 1.3: SUN PROTECTION SCREEN – VENETIAN BLINDS C80P and C80L Issue 3 / April 2017 / EN...
  • Page 45 Fig. 11. Dimensions of Venetian Blind C80 BOX – with under-plaster cassette. * - Variable dimension, usually 30 mm. Guidelines for under-plaster cassette installation:  Length of the guiding profile installed in guide rails equals height of the system -50 mm.
  • Page 46 Fig. 12. Guide rail installation: a) – window frame installation b) – niche installation Instructions for under-plaster cassette installation:  Under-plaster cassette is delivered without installation holes. They have to be done individually according to the below guidelines (Fig. 13). At least 3 openings are required for each 1m of length of the cassette. ...
  • Page 47 Fig. 13. Scheme of preparation of the installation holes in the under-plaster cassette. * - variable dimension, usually 30 mm. Fig. 14. Scheme of preparation of the installation holes in the guide rail profiles. Installation Unscrew the screws from cassette revision, then de- install the revision.
  • Page 48 Measure and mark places for installation holes in the cassette according to Fig. 13. Img. 3 Drill installation holes in the cassette in marked places. Img. 4 Put the cassette on facade and mark places for drilling installation holes in the facade. NOTE: Cassette has to be aligned and prevented from misplacement during marking of the installation spots.
  • Page 49 Install the under-plaster cassette to the facade with appropriate fixing product. Img. 7 Install head rail brackets in the under-plaster cassette. Img. 8 Lossen screws of the bracket so that it is easy to open. Img. 9 Slide head rail with bundle into the bracket, so that the label „strona do okna”...
  • Page 50 10. Position the head rail in reference to the cassette and tighten the bracket screws. Img. 11 11. Install guide rail to the underplaster cassette and fasten it to base or subconstruction with appropriate fixing product as on imgs. 12 and 13. Img.
  • Page 51 13. Place guiding profile into the guide rail according to imgs. 15 and 16 and fig. 15. Img. 15 NOTE: Special attention has to be paid during placement of guiding profile so that no damage is done to the guiding profile by slat pins. Img.

  • Page 52: Electric Drive

    Electrical connection and setup of the motors must be done in accordance with the manual of motor manufacturer. Manuals are added to the product as well as are available on motor manufacturer’s website and: www.selt.com → PRODUCTS → AUTOMATION Environmental conditions of increased threat: bathrooms and showers, kitchens, garages, cellars, saunas, rooms for domestic animals, operating theatres in hospitals, pump rooms, heat exchange rooms, spaces limited by conducing areas, campsites, open spaces, etc.

  • Page 53: Start-Up And Adjustment

    In rooms and spaces where there are increased threat conditions, automatic devices for switching off power supply to the damaged product should be used, e.g. residual current devices. They are recommended to be used in bathrooms, kitchens, garages and cellars. Are obligatory to be used at swimming and shower pools, saunas, construction sites, while supplying appliances in open spaces, on agricultural and horticultural farms, on campsites and in camper vans, as well as in rooms where there is fire hazard.

  • Page 54: System Operation And Product Safety

    SYSTEM OPERATION AND PRODUCT SAFETY 5.1. GENERAL SAFETY REQUI REMENTS  During product transport, assembly and disassembly, operation, care and maintenance, suitable regulations of industrial safety and environmental protection should be observed,  The product should be maintained and repaired solely by the trained and suitably qualified personnel, ...

  • Page 55: Operation Safety

    Centrally controlled products can activate automatically. Make sure no dangerous situation arises. SELT Sp. z o. o. shall not be responsible for damage due to improper use. Operating the system out of one’s sight can result in heavy injuries as well as system damage.

  • Page 56: Supervision Of Safe Product Use

    Do not use the product in case of strong winds, during snow falls, freezing rain. The product might be destroyed or damaged and create danger to people nearby (refers to products installed externally). LAUNCHUNG THE PRODUCT IN TEMPERATURES BELOW ZERO MAY CAUSE ITS DAMAGE In case any irregularities in product operation are found, the Supplier should be informed immediately.

  • Page 57: Technical Inspections, Maintenance And Repairs

    Possibly adjusting and improving the mounting of the changed sub-assembly. Products manufactured by SELT Sp. z o. o. do not require special maintenance treatment. Using the product in accordance with the manufacturer’s recommendations assures the user log-term and fault-free operation. Routine maintenance activities should be carried out on a maximally opened system.

  • Page 58: General Warranty Conditions

    GENERAL WARRANTY CON DITIONS General warranty conditions are available on www.selt.com. In case of no access to the SELT website, the warranty conditions can be obtained from the sales representative of SELT Sp. z o. o. 7.1. EXCLUSIONS FOR WARRA NTY Warranty does not cover: ...

  • Page 59: Complaints/ Technical Faults

     notifications can be sent to the email address reklamacje@selt.com or directly to the sales representative Complaints / faults should be made on the ‘complaint notification form’ which can be found on the website: www.selt.com,...

  • Page 60: Product Disassembly / Utilisation / Disposal

    PRODUCT DISASSEMBLY / UTILISATION / DISP OSAL Improper system disassembly can result in severe injuries and system damage. System disassembly should be commissioned to a properly qualified assembly team or to a person suitably trained within industrial safety and with the knowledge concerning recovery. Disposal of worn electrical and electronic equipment After the end of product lifetime it must be disassembled and separate material must be segregated according to Regulation of the Minister of Environment of 9 December 2014 on waste catalogue –...

  • Page 61: Marking And Labelling The Product With The Ce Mark

    10.1. PRODUCT COMPLIANCE W ITH THE CE STANDARD Products manufactured by SELT company meet the essential requirements of the standard introduced by the Polish Committee for Standardization as PN-EN 13659, which is confirmed by the manufacturer’s declaration of performance and marking the product with the CE mark.
  • Page 62 EN 14501:2005; detailed data depending manufacturer’s website on the fabric type are given in a table on manufacturer’s website SELT Sp. z o. o. SELT Sp. z o. o. Opole, ul. Wschodnia 23A Opole, ul. Wschodnia 23A POLAND...
