- Page 1 NQDR MEDIA DECODER User Manual ™ ®...
- Page 2 Contact and Support User Resources Further information to content outside support@harvest-tech.com.au the scope of the user guide. Harvest Technology Pty Ltd 7 Turner Avenue, Technology Park Extra pointers or suggestions in Bentley WA 6102, Australia executing instructions. www.harvest.technology...
- Page 3 Disclaimer and Copyright Whilst Harvest Technology will endeavor to keep the information in this user guide up to date, Harvest Technology makes no representations or warranties of any kind, express or implied about the completeness, accuracy, reliability, suitability or availability with respect to the user guide or the information, products, services or related graphics contained in the user guide, website or any other media for any purpose.
-
Page 4: Table Of Contents
Table of Contents Overview �������������������������������������������������������������������������������������������������������������������� 5 Front Panel ................................5 Rear Panel ................................6 Connections ................................6 RTP Video Output ..............................7 Serial Data ................................7 Configuration ������������������������������������������������������������������������������������������������������������� 7 Access ..................................8 Initial Login ................................8 Dashboard ................................9 Network Configuration ............................10 System Settings ..............................14 Diagnostics................................15 Deliverer ������������������������������������������������������������������������������������������������������������������ 16 Appendix �����������������������������������������������������������������������������������������������������������������... -
Page 5: Overview
NQDR ® Overview The Nodestream RiS Quad Decoder (NQDR) provides Decoding of up to four HD video sources and frame synchronous serial data, from an RiS Encoder at a remote location. Feature Summary • HD video and data over low- quality satellite networks •... -
Page 6: Rear Panel
NQDR ® Rear Panel Power Power Switch Port Ethernet USB-A Line In Line Out DO NOT USE Serial Port Mic In Serial PS/2 HDMI DisplayPort USB-A USB-A Port Monitor outputs Connections Power Monitor Outputs Serial Ethernet The NQDR is supplied with a Quick Start Guide for installation. See the User Resources on the last page for access. -
Page 7: Rtp Video Output
NQDR ® RTP Video Output RTP output enables viewing of the decoded video stream from a network connected device. • Ensure target machine is on the same network • See Deliverer user manual for further information regarding setup and configuration •... -
Page 8: Access
NQDR ® Access The Web UI can be accessed via a web browser or locally on the device. Web Browser Connect the NQDR device to your LAN via the Ethernet port and power the device Navigate to the device from a web browser by entering the IP in the address bar •... -
Page 9: Dashboard
NQDR ® Dashboard Following initial login, the user will be presented with the WebUI dashboard. The following information and configuration is provided Device • Uptime Information • Select interface from drop down • Current network status & information Testing • Network connection upload & download speed tests •... -
Page 10: Network Configuration
NQDR ® Network Configuration RiS devices communicate over a customers “closed” network, ensuring stable and secure transmission of sensitive data. Device network adapters require IPv4 configuration. Firewall Settings The following port numbers MUST be set to open on customer network devices where applicable Video &... - Page 11 NQDR ® Select the IP Settings tab, then manual from the drop down Enter network settings as provided by your Network Administrator and select Save Ethernet connections MUST be reset for settings to take effect by • Disconnecting and reconnecting the Ethernet cable •...
- Page 12 NQDR ® WiFi (with optional USB adapter) Select the WiFi adapter from the drop down list in the top right of the window Name the interface (optional) and select enabled then Save Changes Select the Wireless tab, then manual from the drop down Select from the available networks then Connect or manually enter details then Join Network HTG-TEC-GUI-017_0...
- Page 13 NQDR ® Select the IP Settings tab Enter network settings as provided by your Network Administrator and select Save For network issues, see “Troubleshooting” on page 18 HTG-TEC-GUI-017_0 page 13 of 20 Release Sep 2022...
-
Page 14: System Settings
NQDR ® System Settings Version Control • Software versions currently installed and resource usage Update Password • Enter details and select Update Factory Reset • Select to set the device to factory defaults (user and network settings) • Select Confirm or Cancel when prompted Support •... -
Page 15: Diagnostics
NQDR ® Diagnostics Network • Network connection information • Select interface from drop down Software • Software versions currently installed and resource usage • Current CPU usage and temperature Memory & Other • Information on other system resources HTG-TEC-GUI-017_0 page 15 of 20 Release Sep 2022... -
Page 16: Deliverer
NQDR ® Deliverer RiS device connection management and configuration is performed using the Deliverer application. Deliverer User Manual Refer to the Deliverer User Manual for additional information. HTG-TEC-GUI-017_0 page 16 of 20 Release Sep 2022... -
Page 17: Appendix
NQDR ® Appendix Technical Specifications Hardware Physical dimensions 440 (W) x 132 (H) x 380 (D) mm Weight 8.2 kg Power Power supply: 100-240VAC 47/63Hz Power consumption (operating): 150W Power consumption (idle): 100W Environmental Temperature Operating: 0 °C to 35 °C Storage: -20 °C to 65 °C Humidity... -
Page 18: Troubleshooting
NQDR ® Troubleshooting System Issue Cause Resolution Device not powering PSU switch in off position Confirm AC connected and switch is in the on position AC not connected Device overheating Blocked vents Ensure device ventilation is not blocked (refer quick start guide) Environmental conditions Ensure device is located in an environment where specified operating conditions are not exceeded... - Page 19 NQDR ® Video Issue Cause Resolution No output to monitor(s) Monitor(s) not connected or Ensure monitor(s) connected and powered powered Test monitor with an alternative input Incorrect output used Ensure monitor connected to Mini DisplayPort “No Signal” displayed Encoder Source(s) not Confirm video source(s) connected to Encoder connected or powered on and powered.
- Page 20 Bentley WA 6102, Australia www.harvest.technology All rights reserved. This document is the property of Harvest Technology Pty Ltd. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, photocopy, recording or otherwise without the written consent of ®...
