- Page 1 Robot PROMOBOT v.2.0 Serial number:...
- Page 2 Dear user! We express our gratitude to you for the choice and purchase of our innovative product, characterized by high reliability and efficiency in the work. We are confident that our product will serve you for many years. Please note that the effective and safe operation and proper maintenance is possible only after a careful examination of the given to you "Operating Instructions".
-
Page 3: Table Of Contents
Table of contents Main Options......................4 Specifications....................4 Package......................7 Application.....................7 Description of the legend................8 General safety rules..................9 Place of storage of robot................9 Visual inspection..................10 Safety......................10 Electrical safety....................10 1.10 Safe movement...................11 Structure and components................12 Head......................12 Interactive LCD touch-screen display............13 Hands-manipulators...................14 Movement platform..................15 Ultrasonic sensors' system.................16 Operating ports...................17 Operation......................18 Safety measures before start of operation..........18... -
Page 4: Main Options
BASIC PARAMETERS Specifications Robot-consultant PROMOBOT v.2.0 1. BASIC PARAMETERS... - Page 5 Robot-consultant PROMOBOT v.2.0 Head, equipped with a video camera, speaker and microphone array; Interactive LCD display with touch controls for displaying information; Hands-manipulators; Movement platform; The sensor system to overcome obstacles while driving. Robot PROMOBOT v.2.0...
- Page 6 Specifications Option Characteristic Size 145h76h76 (HxWxL) Battery life Up to 8 hours Movement speed 0.5 km Drive 2-wheel roller 2 with a thruster Arms 2 arms, move on 1 plane Rotation of the head In two directions (left - right, up - down) Camera 1280x720 resolution 25 frames per second...
-
Page 7: Package
Power cable 1 pc. Joystick (gamepad) with charging cable 1 pcs. Datasheet 1 pcs. Application The main application of the robot consultant Promobot: Attracting customers flow; џ Automation of consultation process for products; џ Increase of the customers' loyalty. џ... -
Page 8: Description Of The Legend
Description of the legend Attention, important information! This condition is necessary to be fulfilled! Watch out for electricity network voltage. Electricity network must comply with the required parameters. In case of the damage or break of the power cord immediately remove the plug from the socket. -
Page 9: General Safety Rules
For safety reasons, children under 18 and people not familiar with these rules must џ not be allowed to control the robot; Use Promobot only for its intended purpose specified in the owner's manual; џ If you do not have the skills to work with electronics, it is strongly recommended to џ... -
Page 10: Visual Inspection
If damage is found, contact the service center. џ Safety Observe all safety regulations. џ When using the robot Promobot, observe the general rules for the џ safe use of electrical appliances. Rotating wheels can cause injury. Avoid touching wheels with your џ... -
Page 11: Safe Movement
Before starting the robot, make sure that the location has no steps џ or thresholds slopes. Promobot is not able to move around on them and can fall. In case of thresholds, slopes or steps, contact the service center of џ... -
Page 12: Structure And Components
Active Microphone array neck Head of the robot PROMOBOT v.2.0 During operation, the robot with a video camera detects a person and saves information about him in the database. RGB matrix performs the function of eyes, and, depending on the information obtained, changes the emotions. -
Page 13: Interactive Lcd Touch-Screen Display
Interactive LCD touch-screen display Interactive LCD touch-screen display of the robot PROMOBOT v.2.0 The interactive display is used to display information about the operation of the robot. It includes a touch-screen sensor, allowing the communication with the robot via touch. -
Page 14: Hands-Manipulators
Arms-manipulators Shoulder joint Hand Arms-manipulators of the robot PROMOBOT v.2.0 Robotic arms are designed for robotic gestures during intercourse. They produce motion in the shoulder joint. Do not attempt to move arms џ Avoid moisture inside of the arms џ... -
Page 15: Movement Platform
Platform movement Platform movement of the robot PROMOBOT v.2.0 Platform movement is equipped with two-wheel drives and the steering roller and a sensor system for avoiding collisions with obstacles. Do not touch the wheels in motion џ Avoid contact with the wheels of items that could hamper their џ... -
Page 16: Ultrasonic Sensors' System
Ultrasonic sensor system Ultrasonic sensors Along the perimeter of Promobot ultrasonic sensors are mounted, they detect obstacles and help to avoid them. Do not touch the sensors џ Do not obstruct the sensor by foreign objects and stickers џ Avoid moisture on sensors џ... -
Page 17: Operating Ports
Operational ports Charging Port The USB-port to download promotional materials Do not allow moisture to get into the ports џ In case of malfunction, contact the service center џ Robot PROMOBOT v.2.0... -
Page 18: Operation
Port 4444 - input and output TCP and UDP traffic. џ To start Promobot, you need to press the power button (the same button switches the robot off), which is located at the bottom of the robot at the right side of the body. - Page 19 The power button of the robot Button breaking the circuit The power button of the robot Button gap chain After starting the start screen appears: Robot PROMOBOT v.2.0...
- Page 20 By clicking on the gear, you can go in Promobot settings: «Settings» - the settings menu, the microphone sensitivity is set in this menu, the speaker volume, name of Promobot, the site address to be opened in the default browser, selection of the language, as well as many other settings intended for highly skilled professionals (they are not recommended to change).
- Page 21 In case of a fault of the sensor value will be "1", as shown in the figure above. In case of correct operation when approaching or getting away from the sensor, the numerical value must change to a smaller or larger respectively. «Network selection» - to connect to the Wi-Fi network. Robot PROMOBOT v.2.0...
- Page 22 Wi-Fi network signal in the lower right corner. For correct operation of Promobot the ping should be above 0 and below 50. Ping value of 0 means that the Internet access is not available. The robot cannot connect to a hidden network.
- Page 23 Timeout – this is the time of displaying each file, given in seconds. Robot PROMOBOT v.2.0...
- Page 24 MODE indicator Joystick to control the robot PROMOBOT v.2.0 4. One need to hold B, and use the left stick, to make transportation to and from work. 5. On completion of the transportation, it is necessary to transfer the robot to autonomous mode by briefly pressing the MODE key.
-
Page 25: Controlling The Robot With A Joystick (Gamepad)
To simplify the control of robot a control joystick is used. Joystick works on batteries charged when connected to the robot (or any computer) by the USB cable (supplied). MODE Left stick Cross LED MODE Right stick Left Bumper Right Bumper Right Trigger Left Trigger Robot PROMOBOT v.2.0... - Page 26 Combinations for robot control Combinations Description Left bumper + Left + Reboot + Right trigger bumper + Right Trigger Mode (long press) Switch on the gamepad B + left stick Movement in quiet mode A + left stick Movement in the accelerated mode B + cross Robot head control (in accordance with the cross keys)
-
Page 27: End Of Work. Charging
For safe transportation of the robot you must unplug its power supply by switching off (the switch is inside of the robot). This switch is located under the chassis in front of the robot, on the right side of the bottom. Robot PROMOBOT v.2.0... -
Page 28: Periodic Maintenance
PERIODIC MAINTENANCE Routine maintenance for the normal operation of the robot Work Periodicity System log analysis Every month Software update Every 4 months Works on inspection and general maintenance of Every 4 months the robot condition, preparation of defective statements, conclusions about the need for repair, preparation of technical tasks on the solving of the identified defects Every 4 months... -
Page 29: Warranty Conditions
Warranty repair is made by the robot manufacturer service centers. All products are made in Russia, and do not require certification. Robot PROMOBOT v.2.0... - Page 30 Contact Information LLC «PROMOBOT» 614087, Perm, 77а, Lunacharskogo st. e-mail: info@promo-bot.ru Phone: +7 (342) 257 80 85 Technical Director ___________________________ / Eremeyev IM /...
