IBASE Technology 15923 Instruction Manual

Item code: 15923
IBase is a wireless alarm system with pre-determined ID and remote reporting function. The ID
will be shown on 15901R, Remote Receiver. The ID number can also be shown on the side, front
or at the back of the IBase as desired.
There are three sensors: (1) micro-switch, (2) motion and (3) optical.
Operation
The IBase must lie on a flat surface.
The micro-switch at the back of the IBase is the master key. The battery will come to live when
the micro-switch is depressed but is not activated. See figure 1
The IBase will activate when an item is put on the motion plate (black area after the protective
sheet is peeled off). See figure 2
Two beeps indicate that only the motion sensor is activated.
Three beeps mean both motion and optical sensors are activated.
If optical sensor is not required, simply put a black tape over the optical sensor.
The accessory is used for attaching the base of a transparent or light colour item so that the
optical sensor will not activate accidentally, for example, on a bottle of whisky. See figure 3
Factory label with
manufacturing
date
Product name: IBase
Instruction Manual
Figure 1: Base
Quarterly
Inspection
table
Micro-
switch
