HRE-454 Remote Enclosure

Part Number

150-1122-11

150-1122-21

150-1122-12

150-1122-22

150-1122-03

150-1122-04

150-1122-05

150-1122-06

SER

ANUAL

CLEI Code

T1RHM2W4

T1RHMCV4

T1RHMCW4

N/A

Table of Contents

Need help?

Do you have a question about the HRE-454 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADC HRE-454

Page 1 ANUAL HRE-454 Remote Enclosure Model List Number Part Number CLEI Code HRE-454 150-1122-11 HRE-454 150-1122-21 T1RHM2W4 HRE-454 150-1122-12 T1RHMCV4 HRE-454 150-1122-22 T1RHMCW4 HRE-454 150-1122-03 HRE-454 150-1122-04 HRE-454 150-1122-05 HRE-454 150-1122-06...
Page 2 Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits, and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
Page 3 Unpack each container and inspect the contents for signs of damage. If the equipment has been damaged in transit, immediately report the extent of damage to the transportation company and to ADC DSL Systems, Inc. Order replacement equipment, if necessary.
Page 4 Inspecting Shipment 150-454-111-06 February 25, 2000 HRE-454...
Page 5: Table Of Contents
Table of Contents ABLE OF ONTENTS Overview ____________________________________________________________________________ 1 Features ..............................1 Applications ............................1 HRE-454 List 3 and List 4....................2 HRE-454 List 5 and List 6....................2 Doubler, Line, and Remote Unit ..................3 Doubler Applications......................4 Functional Description ........................4 Gel-filled Stub Units......................4 Air-filled Stub Units ......................5 Pressurized Applications........................6...
Page 6 Cable Stub and Pressurization................... 27 Vented-to-Pressurized Conversion Procedure ..............28 Spare Connections......................29 Order Wire Connections ....................29 General Deployment Rules ....................29 HRE-454 Wiring ..........................33 Pinout Information ......................35 Wire List Information ....................... 44 HRE-454 Maintenance ........................53 Splicing ..........................53 Pre-splicing Procedure ......................
Page 7 18. HRU-512 Pin Assignments...........................37 19. HRU-612 Pin Assignments...........................38 20. HDU-451, HDU-404, and EDU-451 Pin Assignments ................39 21. HLU-431 and HLU-432 Pin Assignments Supported by HRE-454 List 5 and List 6........40 22. HRU-402 Pin Assignments...........................41 23. H2TU-R-402 Pin Assignments ........................42 24. HRE-454 Wiring Interfaces ..........................43 25.
Page 8 5. HRE-454 Deployment Rules for Doublers and Remote Units..............30 6. HRE-454 Deployment Rules for HLU-431/ 432 Applications vs. Type of Doubler Used......31 7. HRE-454 28-pair Cable Stub Wire Pair Assignment for Doubler and Remote Units ......... 33 8. HRE-454, HRU-412, and HRU-402 Wire List .................... 44 9.
Page 9: Overview
5 (gel-filled), and the HRE-454 List 2A, List 2B, List 4, and List 6 (air-filled). Information on installing these enclosures is also included. The HRE-454 is part of a HiGain system and used to house the HiGain remote line or doubler units.
Page 10: Hre-454 List 3 And List 4
HDSL pairs, like doubler and remote units, the HLU-431 or HLU-432 is powered from -48 Vdc at its edge connector on pins 17 (+) and 35 (-). The HRE-454 List 5 and List 6 are located adjacent to the hub and gain access to the T1 payloads and -48 Vdc power over the cable stub that connects the two units.
Page 11: Doubler, Line, And Remote Unit
Figure 23 on page 42 Remote unit for 1 pair (HDSL2), T1 (1.544 Mbps) service. Table 10 on page 47 Only the HRE-454 List 5 and List 6 units are wired to provide -48 Vdc power to their four slots. HRE-454 February 25, 2000...
Page 12: Doubler Applications
The following section discusses the function of each component on the HRE-454. The HRE-454 consists of a metal alloy card cage with space for up to four remote or doubler units, a stainless steel composite baseplate, and a stainless steel cover which maintains weather-tight integrity.
Page 13: Air-Filled Stub Units
Schrader air stem valve, and a pressure relief valve. The air cutoff valve is used to shut off the inlet air supply that is pumped from the main feeder cable through the 30-foot (9.144 M) stub into the HRE-454 enclosure. The cable stub is intended for buried, aerial, and duct applications.
Page 14: Pressurized Applications
PPLICATIONS For pressurized applications on the HRE-454, the Schrader air stem valve is used. A pressure gauge is attached to the valve for the purpose of measuring the internal pressure of the enclosure. This valve is also used to relieve the internal pressure prior to opening and removing the dome cover.
Page 15: Metal Valves
Schrader air stem valve. The air-filled unit pressure cutoff valve can only control the air source that is applied to the enclosure through the air core stub. Figure 4. Metal Valves HRE-454 February 25, 2000...
Page 16: Installation
One HTC-400 test card • HiGain Remote Enclosure HRE-454 List 1A, List 2A, List 1B, List 2B, List 3, List 4, List 5, and List 6 Technical Practice Before installing the HRE-454, unpack and inspect it for missing components and physical damage that may have occurred during shipping.
Page 17: Mounting
150-454-111-06 Installation OUNTING The HRE-454 may be mounted on a pole, a pedestal, a flat surface, or in a rack (Figure 5). Various methods for mounting the HRE-454 are detailed in the following sections. The mounting details for the various methods are as follows: Table 2.
Page 18: Large Pole Or Pedestal Mounting
Have the following equipment ready before you begin: • Four -inch (0.952 cm) lug bolts, 4 inches (10.16 cm) long (minimum) • Four -inch (0.952 cm) washers • One wrench • One pencil • One drill with a -inch (0.635 cm) bit February 25, 2000 HRE-454...
Page 19: Flat Surface Mounting
The desiccant bags shipped with the List 2A, List 2B, List 4, and List 6 units must be activated prior to closing the lid. Do this by removing the bags from their plastic container and placing them inside the enclosure. While mounting the enclosure, hold it securely to prevent personal injury or damage. HRE-454 February 25, 2000...
Page 20: Rack Mounting
-inch nonmetallic washers. Nonmetallic washers are required to avoid a ground loop that may result if both the rack and the enclosure are grounded. ADC does not recommend using the rack ground for the enclosure ground since its integrity is not one-hundred percent reliable.
Page 21: Grounding
“Grounding a Pole Mounted Enclosure” on page 13 or use existing local Ω grounding practices to ground the enclosure. The HRE-454 requires a resistance of 25 or less to ground as measured with a megger-type Ohmmeter. The 8 MIL aluminum shield on the stub is connected to the card cage mounting brackets by a...
Page 22 (or an accepted local grounding method) must be in effect at all times to safeguard personnel. If the HRE-454 is improperly grounded, the LPU surge arrestors will not work and the enclosure will be unprotected. Using a megger-type Ohmmeter, measure the resistance between enclosure ground and the ground rod. The Ω...
Page 23: Grounding A Flat Surface Mounted Enclosure
Step 2, then proceed to Step 4. Using 6 AWG cable, connect the ground lug on the HRE-454 to the ground connection in the manhole. Torque the grounding lug between 18 and 22 inch-pounds.
Page 24: Slot Chassis Ground Connections
Using a megger-type Ohmmeter, measure the main cable shield resistance to manhole ground. The resistance Ω must be 5 or less. If the Ohm requirement is not met, ground the main cable shield every 2,000 ft. HRE-454 Grounding No. 6 gauge wire Stub Splice case...
Page 25: Detaching The Dome From The Baseplate
Perform the following steps to detach the dome from the enclosure baseplate (Figure Release the internal pressure. Unclamp the dome from the baseplate. Lift the dome up and away from the baseplate. Figure 8. HRE-454 Enclosure HRE-454 February 25, 2000...
Page 26: Opening The Hre-454 Enclosure
LOSING THE NCLOSURE To close the HRE-454 enclosure, do the following: Inspect the enclosure cover for dirt, moisture, or mechanical damage especially around the baseplate flange and O-ring. Remove any accumulation of dirt or moisture from the cover and replace any damaged components.
Page 27: Pivoting The Enclosure
9). The test card provides access to all assigned cable pairs of the HRE-454. The card is used to test cable pairs and to check Central Office (CO) and field circuits by performing loopback, loop-through, short, and open testing of all cable pairs. A four-position slide switch on the test card enables technicians to select the type of test to perform.
Page 28: Circuit Testing
Pin numbers correspond to edge connector pins for each circuit. Perform the selected test. Monitor the circuits at the corresponding test points on the card. Repeat Steps 2 and 3 as required. February 25, 2000 HRE-454...
Page 29: Test Connections
LOOP THRU - This switch position connects the following circuits: CO Tip Pin # 7 Field Tip Pin # 5 CO Ring Pin # 13 Field Ring Pin # 15 CO Tip Pin # 41 Field Tip Pin # 55 HRE-454 February 25, 2000...
Page 30 However, this limited extension is such that the HTC-400 could be inserted into the HRE-454 outdoor enclosure with the card cage retaining/locking bar in place. This allows the HTC-400 to be permanently installed in any slot where it provides loop-through of the cable pairs. This allows end-to-end metallic cut-through access to Sides 1 and 2 cable pairs without the need to rewire the shelf slots.
Page 31: Appendix A - Specifications
Volume: 0.75 ft. (.021 m Weight HRE-454, List 1A, List 3, and List 5 (GF): 38 lb. (17.2 kg) HRE-454, List 2A, List 4, and List 6 (AF): 36 lb. (16.3 kg) HRE-454, List 1B (GF) 51 lb. (23.1 kg) HRE-454, List 2B (AF) 49 lb.
Page 32: Appendix B - Technical Reference
Appendix B contains additional technical information about the HRE-454. CLEI C P1 L ODE AND ABELS Figure 11 shows the location on the HRE-454 for the bar code and warranty control number. Table 4 gives a brief description of each label. Front view (HRE-454 shown with cover removed)
Page 33: Hre-454 Enclosure Information
Appendix B - Technical Reference HRE-454 E NCLOSURE NFORMATION All HRE-454 units have access to an order wire pair shown in Figure 2 on page 5 Figure 3 on page 6. The enclosure mounting plate allows the unit to be tilted 31° from its vertical position (see Figure 8 on page 17).
Page 34: Lightning Protection Unit (Lpu)
HDSL loops and customer T1 circuits. All HRE-454 units come equipped with four LPUs. Each LPU contains four gas tubes which provide the surge protection to each of the four parts. These tubes also have three leads which provide protection from Tip and Ring to ground.
Page 35: Cable Stub And Pressurization
500 volts. The tube can withstand at least 400, 10/1000, or 500 amp discharges. (Amp discharges are quantities of discharges that occur before system degradation.) Cable Stub and Pressurization Every HRE-454 is equipped with a single-screened cable stub. Refer to Table 7 on page 33 for a complete description of the cable stub.
Page 36: Vented-To-Pressurized Conversion Procedure
Figure 2 on page 5 Figure 4 on page 7. A desiccant bag is also included in the HRE-454 along with the pressure relief valve. Remove this bag and place it in the HRE-454 prior to pressurization. Attach a plastic tube, -inch (.64 cm) inner diameter (ID) by...
Page 37: Spare Connections
Spare Connections Each HRE-454 stub (with the exception of the List 3 and List 4 models) has 11 spare pairs. The HRE-454 List 3 and List 4 models provide access only to four spare pairs. On the List 3 and List 4 units, the 28 pairs have been grouped into seven, 4-pair groups.
Page 38: Hre-454 Deployment Rules For Doublers And Remote Units
Appendix B - Technical Reference 150-454-111-06 Table 5. HRE-454 Deployment Rules for Doublers and Remote Units EDU-451, HDU-451 List 1 & List 2 HDU-404 Occupied Solar HDU-451 List 3 & List 4 All HRU Units All list numbers Orientation Slots Load Max.
Page 39: Hre-454 Deployment Rules For Hlu-431/ 432 Applications Vs. Type Of Doubler Used
Appendix B - Technical Reference Table 6 lists the deployment rules for the HRE-454 List 5 and List 6 enclosures for HLU-431 and HLU-432 applications. These rules are shown as a function of the type of doubler that is used in HLU-431 circuits. The HDU-409 mini-doubler requires less power and thus reduces the heat dissipated by the HLU-431 when the doublers (listed in column four) are used.
Page 40: Hre-454 Vertical And Horizontal Mounting Orientation
Figure 14. HRE-454 Vertical And Horizontal Mounting Orientation Deployment considerations determine the physical location of the HRE-454 doubler enclosures, which are: The first and most important rule is to place each enclosure span to the electrical limits of 35 dB. This will place the first doubler at the 35 dB location and the second at 70 dB.
Page 41: Hre-454 Wiring
White/Orange codes. Each group also has two pairs identified as Spare (SP)1 (White/Red) and SP2 (White/Black). Group 1 is identified by a Blue group thread. Group 2 is identified by an Orange group thread. Table 7. HRE-454 28-pair Cable Stub Wire Pair Assignment for Doubler and Remote Units HRE 454 Slot No. Direction...
Page 42: Hre-454 Interface Wiring Diagram And Cable Assignment Drawing
Table 12 on page 51 shows how the two spare red and white pairs in both groups are used in the HRE-454 List 5 and List 6 enclosures to power the four slots for HLU-431 List 1B applications. The four spare pairs used to access the HLU-431 system relay alarm controls are also shown.
Page 43: Pinout Information
Pinout Information To use a specific shelf slot on the HRE-454, a remote, line, or doubler unit must be inserted. Insert the units into the desired shelf slot by lining up the gold fingers on each unit with the slot connector. Active pins are highlighted in black.
Page 44: Eru-412 List 2 Pin Assignments
Appendix B - Technical Reference 150-454-111-06 Figure 17. ERU-412 List 2 Pin Assignments February 25, 2000 HRE-454...
Page 45: Hru-512 Pin Assignments
150-454-111-06 Appendix B - Technical Reference Figure 18. HRU-512 Pin Assignments HRE-454 February 25, 2000...
Page 46: Hru-612 Pin Assignments
Appendix B - Technical Reference 150-454-111-06 Figure 19. HRU-612 Pin Assignments February 25, 2000 HRE-454...
Page 47: Hdu-451, Hdu-404, And Edu-451 Pin Assignments
150-454-111-06 Appendix B - Technical Reference Figure 20. HDU-451, HDU-404, and EDU-451 Pin Assignments HRE-454 February 25, 2000...
Page 48: Hlu-431 And Hlu-432 Pin Assignments Supported By Hre-454 List 5 And List 6
Appendix B - Technical Reference 150-454-111-06 Figure 21. HLU-431 and HLU-432 Pin Assignments Supported by HRE-454 List 5 and List 6 February 25, 2000 HRE-454...
Page 49: Hru-402 Pin Assignments
150-454-111-06 Appendix B - Technical Reference Figure 22. HRU-402 Pin Assignments HRE-454 February 25, 2000...
Page 50: H2Tu-R-402 Pin Assignments
Appendix B - Technical Reference 150-454-111-06 Figure 23. H2TU-R-402 Pin Assignments February 25, 2000 HRE-454...
Page 51: Hre-454 Wiring Interfaces
150-454-111-06 Appendix B - Technical Reference Figure 24. HRE-454 Wiring Interfaces HRE-454 February 25, 2000...
Page 52: Wire List Information
This list shows the interface between the HRU-412 pairs and the HRE-454 slots. Connectors J1, J2, J3, and J4 are the card-edge connectors at the rear of each HRE-454 slot. The slots are numbered 1 through 4, from left to right, facing the front of the card cage.
Page 53 The HRE-454 Slots are numbered 1 through 4 from left to right as viewed from the front. The red and brown order wire access pair terminates on order wire protector terminals. Protector connects to order wire terminals via the black and white jumper pair.
Page 54: Hre-454 And Eru-412 List 2 Wire List
Appendix B - Technical Reference 150-454-111-06 Table 9. HRE-454 and ERU-412 List 2 Wire List HRE 454 Signal Side Group* Color Connector Pair # Slot No. HDSL 1 Tip White J1 Pin 7 HDSL 1 Ring Blue J1 Pin 13...
Page 55: Hre-454 (Hru-512, Hru-612, And H2Tu-R-402) Wire List
150-454-111-06 Appendix B - Technical Reference Table 9. HRE-454 and ERU-412 List 2 Wire List (Cont.) HRE 454 Signal Side Group* Color Connector Pair # Slot No. Spare Blue Spare Black Spare Blue Spare Black Spare Orange Spare Black Spare...
Page 56 White Spare Spare White Spare Spare White Spare Black Spare White Spare Black *Group #1 = Blue Thread, Group #2 = Orange Thread Table 11 is the wire list for HRE-454 (HDU-451, HDU-404, and EDU-451) applications. February 25, 2000 HRE-454...
Page 57: Hre-454 (Hdu-451, Hdu-404, And Edu-451) Wire List
150-454-111-06 Appendix B - Technical Reference Table 11. HRE-454 (HDU-451, HDU-404, and EDU-451) Wire List HRE 454 Signal Side Group* Color Connector Pair # Slot No. HDSL 1 In Tip White J1 Pin 7 HDSL 1 In Ring Blue J1 Pin 13...
Page 58 Appendix B - Technical Reference 150-454-111-06 Table 11. HRE-454 (HDU-451, HDU-404, and EDU-451) Wire List (Cont.) HRE 454 Signal Side Group* Color Connector Pair # Slot No. Spare Black Spare Blue Spare Black Spare Blue Spare Black Spare Orange Spare...
Page 59: Hre-454 List 5 And List 6 (Hlu-431 And Hlu-432) Wire List
Appendix B - Technical Reference Table 12 is the wire list for HRE-454 List 5 and List 6 units in the HLU-431 and HLU-432 applications. Table 12. HRE-454 List 5 and List 6 (HLU-431 and HLU-432) Wire List HRE 454...
Page 60 Appendix B - Technical Reference 150-454-111-06 Table 12. HRE-454 List 5 and List 6 (HLU-431 and HLU-432) Wire List (Cont.) HRE 454 Signal Side Group Color Connector Pair # Slot No. System Alarm Relay Black J4 Pin 30 (Normally open)
Page 61: Hre-454 Maintenance
AINTENANCE This section covers various maintenance procedures for the HRE-454. Splicing Splicing consists of connecting the wire pairs of the HRE-454 cable stub to the main cable within the splice case. “Pre-splicing Procedure” on page “Splicing Procedure” on page 55, and “Post-splicing Procedure”...
Page 62: Dress Splice In Splice Case
Keep cable pairs dry. Cover the exposed splice to protect it from the elements if it is left unattended prior to completion. HRE-454 Field side of cable stub CO splice...
Page 63: Splicing Procedure
Table 11, “HRE-454 (HDU-451, HDU-404, and EDU-451) Wire List,” on page 49 – Table 12, “HRE-454 List 5 and List 6 (HLU-431 and HLU-432) Wire List,” on page 51 Visually inspect each splice for split pairs, opens, and shorts. Maintenance personnel sometimes cross-splice defective pairs between units. These pairs are referred to as wandering pairs and may cause problems.
Page 64: Post-Splicing Procedure
Appendix B - Technical Reference 150-454-111-06 HRE-454 CO cable stub Cable stub butt (other side of screen) Cable stub butt (one side of screen) Field cable stub Figure 27. Post-splicing Procedure Post-splicing Procedure The post-splice procedure involves the following steps:...
Page 65: Replacement Parts
Seal and close the splice case according to the splice case instructions. EPLACEMENT ARTS There are seven replacement or accessory kits that are available for the HRE-454 enclosures. Table 13 on page 59 lists these kits. Following are the topics regarding replacement parts: •...
Page 66: Replacing The Stainless Steel Dome Cover
Proteck-Sorb-121 or equivalent desiccant. Replacing LPU Arrestor Boards If any of the enclosure plugs experience severe lightning stress, ADC recommends replacing the LPU board for that plug. To replace LPU arrestor boards, perform the following steps: Clean the dome cover and clamp of dust and debris.
Page 67: Replacement Part Kits
3/8-16 x 1-inch Stainless Steel Hex Nut Bolts Qty 4 3/8-16 x 1-inch Stainless Steel Split Lock Washers Qty 4 3/8-10x4-inch Stainless Steel Lug Bolts Qty 2 Desiccant (2-unit bag) 132-1030-01 Protector Tube Kit Qty 25 47BT Gas Tube Protectors or equivalent HRE-454 February 25, 2000...
Page 68: Valve Replacement Procedures
Check that the new BVV came equipped with its O-ring. Thread the new BVV into the brass fitting. Do not crossthread. Again grip the BVV with a -inch wrench and tighten to 60 inch-pounds of torque. February 25, 2000 HRE-454...
Page 69: Air Stem Valve
Some resistance will be noticed as the stem’s O-rings rub against the walls of the body housing as the stem is withdrawn. Check that the O-ring remains attached to the threaded tip of the body housing. HRE-454 February 25, 2000...
Page 70 Pressurize the chamber and check the entire assembly for leaks. Rotate the adjustment knob back and forth and determine that it does turn the airflow OFF when fully clockwise and back ON when backed off one turn counterclockwise. February 25, 2000 HRE-454...
Page 71: Appendix C - Product Support
UPPORT ADC Customer Service Group provides expert pre-sales and post-sales support and training for all its products. Technical support is available 24 hours a day, 7 days a week by contacting the ADC Technical Assistance Center (TAC). • Quotation Proposals Sales Assistance •...
Page 72: Appendixd - Glossary
HiGain Doubler Unit HiGain Line Unit HiGain Remote Enclosure HiGain Test Card ICEA Insulated Cable Engineers Association Inner Statial ISDN Integrated Services Digital Network Kilohertz k Ω Kilohm Lightning Protection Unit 1/1000 of an inch millimeter February 25, 2000 HRE-454...
Page 73 150-454-111-06 Appendix D - Glossary Ohms Measures of resistance Pressure Cutoff Valve Processing Element Pressure Relief Valve Pounds per Square Inch Rural Electrification Administration Return Material Authorization HRE-454 February 25, 2000...
Page 74 Appendix D - Glossary 150-454-111-06 February 25, 2000 HRE-454...
Page 75: Certification And Warranty
90-day warranty period is, at ADC’s option, either (a) return of the price paid or (b) repair or replace of the software. ADC also warrants that, for a period of thirty (30) days from the date of purchase, the media on which software is stored will be free from material defects under normal use.
