- Page 1 Technical Data / Instruction Manual DA-04-VX Article no. 80027003 Analog module with 4 analog outputs 0-10V or 1-10V Seebacher GmbH www.seebacher.de Tel.: 08041 / 77776 Marktstraße 57, 83646 Bad Tölz info@seebacher.de Fax: 08041 / 77772...
-
Page 2: Notes On Documentation
These instructions are intended for qualified personnel who are 1. Notes on documentation familiar with the assembly, installation and operation of the ISYGLT system. It is essential that you read these operating instructions through before commissioning and keep them accessible for further 1.1. -
Page 3: Safety Instructions
Protect module from humidity • and configuration of the ISYGLT module may only be carried out by trained staff. In addition to these safety instructions, you must also observe the special safety instructions listed in the individual chapters for Observe the electrical installation regulations of the country in which the individual acts. -
Page 4: Warranty
These are limited to the intended use of the module and refer EU on waste electrical and electronic equipment at the local collec- to the repair or replacement of the ISYGLT module. Please send the tion points for waste electrical and electronic equipment! device with an attached error description to our company address given below. -
Page 5: Product Description
9. Product description The analog output module is equipped with 4 independent analog The outputs can be loaded as current source or current sink with outputs. The output voltage range, resolved with 8 bits, is 0-10V, 20mA per output. 0-10V and 1-10V control is easily possible with but can be reprogrammed within 0-10V via software (e.g. -
Page 6: 10. Technical Data
Special function DIP switch 1 • Reserve - Switch must be set to OFF Parameterisation In the ISYGLT ProgramDesigner there are various parameterisation options: • Minimum-maximum values per channel • Function of the feedback bit per channel • Definition of the curve calculation •... - Page 7 10.1. Pin assignment ≅ Ub Operating voltage Operating voltage Subnet (BUS A, RS-485) Subnet (BUS B, RS-485) Emergency operating input Reference potential (ground) for analog outputs (4x internally connected) Analog output channel 1 Analog output channel 2 Analog output channel 3 Analog output channel 4 View Seebacher GmbH...
- Page 8 If the emergency input "E" is connected to GND when the supply voltage (24V) is present, all outputs control to 10V! Address 1 2 3 4 5 6 7 8 ISYGLT-DA-04-VX Art.-Nr.: 80027003 4 analog outputs 0-10V (1-10V) Mains Mains...
