INSTALLATION
MANUAL
CONTENTS
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
RENEWAL PARTS . . . . . . . . . . . . . . . . . . . . . . . . .3
APPROVALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
PRODUCT NOMENCLATURE . . . . . . . . . . . . . . . .4
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . .17
See the following page for a complete Table of Contents.
NOTES, CAUTIONS AND WARNINGS
The installer should pay particular attention to the
words: NOTE, CAUTION and WARNING. Notes are
intended to clarify or make the installation easier.
Cautions are given to prevent equipment damage.
Warnings are given to alert installer that personal
injury and/or equipment damage may result if instal-
lation procedure is not handled properly.
CAUTION: READ ALL SAFETY GUIDES BEFORE
YOU START TO INSTALL YOUR FURNACE.
SAVE THIS MANUAL
SUNLINE ULTRA
ELECTRIC / ELECTRIC SINGLE
PACKAGE AIR CONDITIONERS
MODELS: D1HE 036, 048 and
D2HE 060
TM
035-13329-001-B-0504
Advertisement
Table of Contents
Related Manuals for York SUNLINE ULTRA D1HE 036
Summary of Contents for York SUNLINE ULTRA D1HE 036
- Page 1 INSTALLATION SUNLINE ULTRA ELECTRIC / ELECTRIC SINGLE MANUAL PACKAGE AIR CONDITIONERS CONTENTS GENERAL ....... .3 INSPECTION .
-
Page 2: Table Of Contents
035-13329-001-B-0504 TABLE OF CONTENTS GENERAL ....... . . 3 LIST OF FIGURES INSPECTION . -
Page 3: General
035-13329-001-B-0504 GENERAL APPROVALS YORK Model DHE units are single package air conditioners Design certified by CGA and UL listed as follows: designed for outdoor installation on a rooftop or a slab. Elec- tric heaters are available as field-installed accessories. For use as a cooling only unit or cooling unit with electric heat. -
Page 4: Product Nomenclature
035-13329-001-B-0504 PRODUCT NOMENCLATURE RODUCT NOMENCLATURE 0 4 8 RODUCT CATEGORY VOLTAGE CODE 25 = 208/230-3-60 D = Single ackage 46 = 460-3-60 Air Conditioner (Air Cooled) FACTORY INSTALLED RODUCT GENERATION HEAT 1 = New or Current A = Cooling Only 2 = Second Generation RODUCT IDENTIFIER NOMINAL COOLING... -
Page 5: Rigging And Handling
If a unit is to be installed on a roof curb or special frame other than a YORK roof curb, gasketing Refer to Table 4 for unit weights and to Figure 1 for approxi- must be applied to all surfaces that come in con- mate center of gravity. -
Page 6: Filters
035-13329-001-B-0504 NOT be sized to match the dimensions of the duct connec- Refer to Figure 5 for location of these access panels. tions on the unit. Make sure that all screws are replaced on the unit When fastening ductwork to the side duct flanges to maintain an air-tight seal. -
Page 7: Compressors
035-13329-001-B-0504 Refer to Figure 6 for typical field wiring and to the appropriate door and return air dampers, damper actuator, the linkage unit wiring diagram for control circuit and power wiring infor- and all the controls are factory mounted as part of the econo- mation. -
Page 8: Ecomonizer Rain Hood Assembly (Option)
035-13329-001-B-0504 FIGURE 3 - ECOMONIZER RAIN HOOD ASSEMBLY (OPTION) Install the two filters into the hood assembly, sliding The enthalpy set point for the dampers may now be set down along retainers on side plates, into fillpiece at bot- by selecting the desired set-point from graph in Figure 4. tom of hood. -
Page 9: Disconnect Switch Bracket
035-13329-001-B-0504 DISCONNECT SWITCH BRACKET Electric heaters are available as field-installed accessories. Refer to Form 530.18-N7.1V for installation instruction. These A special bracket for mounting a field-supplied disconnect UL approved heaters are located within the central compart- switch is provided in each unit. The bracket is shipped inside ment of the unit (see Figure 5 for access panel) with the heat- the blower compartment taped to the top of the blower ing elements extending into the supply air chamber. -
Page 10: Dimensions & Clearances - 3, 4 & 5 Tons
035-13329-001-B-0504 FIGURE 5 - DIMENSIONS & CLEARANCES - 3, 4 & 5 TONS Unitary Products Group... -
Page 11: Typical Field Wiring
035-13329-001-B-0504 OWER WIRING ONTA TOR FIELD SUPPLIED DIS ONNE T THREE PHASE POWER GROUND SUPPLY EFER TO THE APPROPRIATE ELE TRI AL DATA TABLE TO SIZE THE DIS ONNE T SWIT H, OVR URRENT PROTE TION AND WIRING CONTROL WIRING COOLING ONLY (24 VOLT THERMOSTAT) L I N E A T I N... -
Page 12: Supply Air Performance - 3-Ton
035-13329-001-B-0504 TABLE 2: SUPPLY AIR PERFORMANCE - 3-TON 3 TON GAS HEAT VALUES SHOWN @ 230/460 VOLTS - SIDE DUCT CONNECTIONS Avail able External Static Pres sure - IWG UNIT AIR FLOW SIZE 0.20 0.30 0.40 0.50 0.60 0.70 0.80 (MBH) Watts Watts... -
Page 13: Supply Air Performance - 5 Ton
035-13329-001-B-0504 TABLE 4: SUPPLY AIR PERFORMANCE - 5 TON 5 TON GAS HEAT MODELS SHOWN AT 230/460 VOLTS - SIDE DUCT CONNECTIONS Available External Static Pressure - IWG UNIT AIR FLOW SIZE 0.20 0.30 0.40 0.50 0.60 0.70 0.80 (MBH) Watts Watts Watts... -
Page 14: Static Resistances
035-13329-001-B-0504 TABLE 5: STATIC RESISTANCES EXTERNAL STATIC PRESSURE DROP RESISTANCE, IWG DESCRIPTION 1000 1200 1400 1600 1800 2000 2200 2400 2600 2800 3000 * † 0.07 0.08 0.09 0.11 0.13 0.15 0.17 0.20 0.23 0.26 0.30 Economizer 5 - 15 KW 0.04 0.05 0.06... -
Page 15: Operation
035-13329-001-B-0504 OPERATION SAFETY CONTROLS The refrigerant system is equipped with the following safety COOLING SYSTEM controls: The cooling section is a complete factory package utilizing an A Suction Line Freezestat to protect against low evapo- air-cooled condenser. The system is factory-charged with rator temperatures due to a low air flow or a low return Refrigerant-22. -
Page 16: Two-Stage Heating
035-13329-001-B-0504 TWO-STAGE HEATING: TABLE 9: BELT DRIVE SUPPLY AIR ADJUSTMENT MOTOR PULLEY ADJUSTMENT If the fan switch is in the “ON” position, the evapora- tor blower motor relay (BR) will be energized TURNS BLOWER DRIVE RANGE (RPM) through terminal G to provide continuous blower OPEN 3 TONS 4 TON... -
Page 17: Secure Owner's Approval
035-13329-001-B-0504 Remove the (two) 5/16" dot plugs from the holes located After readings have been obtained, remove the tubes on the filter access panel side of the unit. and seal the holes with the 5/16” dot plugs removed in Step 1. Insert at least 8"... - Page 18 035-13329-001-B-0504 Unitary Products Group...
- Page 19 035-13329-001-B-0504 Unitary Products Group...
- Page 20 ® Subject to change without notice. Printed in U.S.A. 035-13329-001-B-0504 Copyright © 2004 by Unitary Products Group. All rights reserved. Supersedes: 035-13329-001-A-0204 Unitary 5005 Norman Products York Group Drive 73069...
