Model# 63173
USE AND CARE GUIDE
ADELINE 52 IN. LED CEILING FAN
THANK YOU
We appreciate the trust and con dence you have placed in Good Housekeeping through the purchase of this ceiling fan. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your
home improvement needs. Thank you for choosing Good Housekeeping!
Advertisement
Table of Contents
Related Manuals for GOOD HOUSEKEEPING ADELINE
Summary of Contents for GOOD HOUSEKEEPING ADELINE
- Page 1 THANK YOU We appreciate the trust and con dence you have placed in Good Housekeeping through the purchase of this ceiling fan. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your...
-
Page 2: Table Of Contents
Table of Contents ................Table of Contents Hardware Included . -
Page 3: Warranty
The manufacturer warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for the lifetime of the fan motor for the original purchaser. This warranty is voided if the ceiling fan is not purchased and used in the contiguous USA. -
Page 4: Package Contents
Pre-installation (continued) PACKAGE CONTENTS NOTE Unpack your fan and check the contents. You should have the following items listed below. Part Description Quantity Mounting bracket Ceiling canop Set of blade holders Fan motor with switch housing (with blade holder screws pre-installed) Set of blades Light kit with 25W integrated LED Lamp shade... -
Page 5: Installation
Installation Determining mounting method Installing the fan body Remove the mounting bracket (A) from the canopy (B) by WARNING: To reduce the risk of fire, electric shock, or loosening the two canopy screws and star washers located personal injury, mount to outlet box marked acceptable for in the L-shaped slots. - Page 6 Installation (continued) Installing the mounting bracket Installing the receiver WARNING: NOTE: You may need a longer downrod to maintain proper remember to disconnect power. The electrical wiring must blade clearance when installing on a steep, sloped ceiling. meet all local and national electrical code requirements. The maximum angle allowable is 18°...
- Page 7 Installation (continued) Wiring the receiver to the household IMPORTANT: If after this step, you decide to check that the wiring and the fan electrical connections have been successful, it is critical to attach the light kit using the quick connector prior to testing. The fan will WARNING: To avoid possible electrical shock, turn not operate unless the light kit is connected to the fan.
- Page 8 Installation (continued) Attaching the fan blades Finishing the installation NOTE: Your fan blades are reversible. Select the blade side WARNING: When using the standard ball/downrod mounting, finish which best accentuates your decor. Failure to follow the tab in the ring at the bottom of the mounting bracket must rest in the groove of the hanger ball.
- Page 9 Installation (continued) Installing the light kit Balancing the blades All blades are grouped by weight. Because natural wood varies in WARNING: To reduce the risk of electric shock, disconnect the electrical supply circuit to the fan before density, the fan may wobble even though the blades match in weight. installing light kit.
-
Page 10: Operation
Operation Operating Using the remote control NOTE: Follow the instruction manual of the remote control to *NOTE: Wait for the fan to stop before changing the setting change the transmitter code of this fan's remote control and of the reverse switch. receiver if you have interference with other fans or appliances. -
Page 11: Troubleshooting
Ensure wire connector in switch housing is connected. Technical Support If you need any assistance with setup, operation, or parts for your new GOOD HOUSEKEEPING Ceiling Fan, please call us. Our technical support staff is ready to help! We are open 24 hours, 7 days a week. - Page 12 GOOD HOUSEKEEPING is a trademark of Hearst Communications, Inc. © 2022 Hearst Communications, Inc. All Rights Reserved. Retain this manual for future use.
