Summary of Contents for Mayones Cali
- Page 1 U S E R M A N U A L...
-
Page 2: Important Safety Notice
- both when used with a typical bass amp, as well as in practice situations, thanks to its internal headphone amp. Cali mini bass is a pro- fessional instrument that can be placed on par with a regular bass. It may also be a highlight at live shows, during some brilliant solos, or in case of arrangements written specifically for its short scale. - Page 3 19. 2 knobs for adjusting trebles (upper), and bass (lower) 20. 1/4" Instrument output jack 21. 1/8" Headphones output jack 22. Electronics compartment cover 23. Status and headphone amp charging LEDs 24. Micro-USB charging port - 3 - Mayones Cali Bass – User Manual...
- Page 4 To maintain an optimal level of playability and for the bass to remain stable throughout its scale, a truss rod has been used in the Cali bass that is applied to set the neck relief. The truss rod adjustment nut is located beyond the neck nut and it is protected by a decorative cover.
- Page 5 OMTP, CTIA, or similar TRRS jack plugs are also not usable with this bass. One shall note that the Cali mini bass is not a stereophonic instrument. For that reason, both channels of the headphones (left and right) transmit the very same, monophonic pick-up signal that is only split between the two channels of the headphone amp.
- Page 6 After one finishes playing, one should always leave the mini toggle switch in the lower setting, and remove the instrumental cable, to conserve the battery power. When not using the Cali bass, the blue LED (PREAMP ON), should always be off. Push-Pull Volume Knob...
-
Page 7: Battery Charging
At any moment of the charging process. You may also leave it plugged in. However, this entails a risk of damaging the charger socket and the plug if we forget that the instrument is plugged in. - 7 - Mayones Cali Bass – User Manual... - Page 8 Alternatively, you could also use another compatible charger. Note: It is not recommended to plug Cali into the PC USB port, as most of these ports do not provide current that has proper charging parameters for the battery applied.
-
Page 9: Battery Disposal
Should a noticeable performance and capacity drop occur, the battery should be replaced, or the user should get in touch with Mayones. The battery is placed on the inner side of the electronics cover. To replace the battery, unscrew the cover, disconnect the preamp PCB connector, disconnect the battery and carefully remove it, taking care of gently separating the adhesive. - Page 10 If you plan not to use the instrument over a longer period, please remove the battery cell. In extreme cases it may explode, the electrolyte may leak out, fire or damage may occur, or stains may be formed by the leak. - 10 - Mayones Cali Bass – User Manual...
- Page 11 Mayones Guitars and Basses care constantly about the quality of their instruments and release their newer and upgraded versions, as well as search for the best possible building materials. The company reserves the right to make changes without prior notice.
- Page 12 Find more information on guitar operation and maintenance and solving basic problems on our website www.mayones.com. Mayones Guitars and Basses care constantly about the quality of their instruments and release their newer and upgraded versions, as well as search for the best possible building materials.
