- Page 1 U S E R M A N U A L...
-
Page 2: Important Safety Notice
D e a r B a s s P l a y e r ! Mayones Cali is a very functional instrument. Apart from its incredible acoustic properties and playability, it also offers professional tone - both when used with a typical bass amp, as well as in practice situations, thanks to its internal headphone amp (Cali HS model). - Page 3 18. Passive tone knob 19. Mini switch, setting the mode 20. 1/8" Headphones output jack 21. 1/4" Instrument output jack 22. Status and headphone amp charging LEDs 23. Micro-USB charging port - 3 - Mayones Cali Bass – User Manual...
- Page 4 The above stems from the use of full-size components, identical to the ones used in other Mayones basses. This provides you with the very same Mayones signature sound that comes together with top quality, perfect playability, a broad range of set-up adjustments, reliability, and longevity of both the instruments, as well as of its components.
- Page 5 For safety and comfort reasons, the headphones (or other audio devices) should be plugged into the instrument only after the headphone amp is switched on, with the volume knob set to minimum (extreme left position). - 5 - Mayones Cali Bass – User Manual...
-
Page 6: Switch Positions
When the switch is set in this position, the 1/8" jack is also active. Instrument 1/4 " Headphone 1/8" Mini-switch Position output jack output jack Lower ON, passive mode Middle ON, passive mode Upper ON, active mode - 6 - Mayones Cali Bass – User Manual... -
Page 7: Battery Charging
You may also leave it plugged in. However, this entails a risk of damaging the charger socket and the plug if we forget that the instrument is plugged in. - 7 - Mayones Cali Bass – User Manual... - Page 8 Do not leave the mini-switch in the middle or top position - when the switch is in these positions, power is supplied to the headphone amp. This may lead to a rapid discharge of the battery. - 8 - Mayones Cali Bass – User Manual...
- Page 9 - a sound recorder, effects, monitors, or extra stereo amp. Make sure that the coupled device can safely receive the headphone output signal. Should a need emerge, the output level can be adjusted with the bass’s volume knob. - 9 - Mayones Cali Bass – User Manual...
- Page 10 If you plan not to use the instrument over a longer period, please remove the battery cell. ź In extreme cases it may explode, the electrolyte may leak out, fire or damage may occur, or stains may be formed by the leak. - 10 - Mayones Cali Bass – User Manual...
-
Page 11: Battery Disposal
18650 Li-Ion battery, 3.7 V, 3400 mAh Battery charging socket: micro USB Charging voltage: Charging current: 1 A (minimum) Charging time: around 6 hours (5 V, 1 A) Battery protection: overcharging and deep discharging - 11 - Mayones Cali Bass – User Manual... - Page 12 Find more information on guitar operation and maintenance and solving basic problems on our website www.mayones.com. Mayones Guitars and Basses care constantly about the quality of their instruments and release their newer and upgraded versions, as well as search for the best possible building materials.
