Summary of Contents for Mayones Hydra Elite Series
- Page 1 OWNER MANUAL...
- Page 2 Most of the adjustment operations, including truss-rod, intonation or pick-up height adjustments, is done in a way identical to conventional instruments. Note: The present instruction manual constitutes an extension and complement to the basic version of the Mayones Electric Guitars Manual, within the scope pertaining to headless designs. Mayones Hydra | Hydra PRO — User Manual...
- Page 3 (Hydra and Hydra VF model - ABM 3801) 9 Sophia 2:92 tremolo bridge with saddle barrels integrated with the tuners (Hydra Pro) bl Volume knob bm U-REST bn Output jack Figure 1 Mayones Hydra | Hydra PRO — User Manual ...
- Page 4 Before you tune the new string you need to place it in the Fig. 5 headpiece and then tune it up and lock it. These steps have been outlined in detail in the further part of the manual. Mayones Hydra | Hydra PRO — User Manual ...
- Page 5 3 mm Allen wrench (fig. 7B). After the adjustment is done, a 1.5 mm Allen wrench shall be used to tighten the M3 counterscrews (fig. 7C). 3 mm 1,5 mm 1,5 mm Fig. 7 Mayones Hydra | Hydra PRO — User Manual ...
- Page 6 Note: In case of the Sophia 2:92 bridge no objects should be placed under the bridge base. You absolutely must not place objects under the saddle modules, as this may lead to a permanent damage of those. Mayones Hydra | Hydra PRO — User Manual ...
- Page 7 (fig. 12). Tip: Any work related to string replacement could be easier - you Fig. 12 should use small pliers with long tips and a string cutting tool. Mayones Hydra | Hydra PRO — User Manual ...
- Page 8 Fig. 15 locking force is too weak. In case of the free-floating bridges this would translate into detuning of the guitar as a whole (all strings would be detuned). Mayones Hydra | Hydra PRO — User Manual ...
- Page 9 Cutting the strings directly behind the lock should only take place when Fig. 20 the set-up is completed. Mayones Hydra | Hydra PRO — User Manual ...
- Page 10 Note: You shall not forget to lock the bridge saddles. If your string breaks, the saddle may fall out and you may lose it, which would render the instrument useless afterwards. Fig. 24 Mayones Hydra | Hydra PRO — User Manual ...
- Page 11 Allen wrench needs to be inserted into the S-CLAMP element hole (fig. 28). The adjustment screw is placed deep in the hole, thus we recommend using the factory-provided Allen wrench to adjust the truss-rod. Fig. 28 Mayones Hydra | Hydra PRO — User Manual ...
- Page 12 Find more information on guitar operation and maintenance and solving basic problems on our website www.mayones.com. Mayones Guitars and Basses care constantly about the quality of their instruments and release their newer and upgraded versions, as well as search for the best possible building materials.
