Summary of Contents for Mayones Viking
- Page 1 ELECTRIC BASS GUITAR USER’S MANUAL...
- Page 2 DEAR BASS PLAYER! Thank you for purchasing an electric bass of our production. We are convinced that you have made a good choice and that your new instrument will help you in developing your musical talent. We would like to help you in achieving this goal.
- Page 3 Main parts of the bass guitar headstock tuning mechanics (tuners) logo string retainer strings fingerboard frets position markers 10. front strap button 11. neck joint 12. screws and bushings 13. truss rod adjustment screw 14. pickguard 15. volume knob (push-pull) 16.
- Page 4 Another solution is using strings that are unwound next to the barrel. Quick string installation in the Mayones Big Foot bridge Winding the strings on tuning posts Next, stretch the string and cut it more or less 10cm behind the tuning key’s post. The headstock side of the string is often finished with loosened winding and a plastic thread, which ensures the string’s stability...
- Page 5 All the strings should be wound in the same way (on single-sided headstocks) which facilitates tuning the instrument. In the case of new tuners that do not have a slot with a hole, for safety reasons the free ends of the strings should be cut off at a distance of about 0.5 cm behind the tuning peg.
- Page 6 Neck relief Setting up a proper neck relief is achieved by loosening or tightening the truss rod which is built in the axis of the neck. The truss rod adjustment screw is placed either in an opening next to the nut or at the heel of the neck.
- Page 7 Adjusting the bridge - string action After installing the strings, tuning the instrument initially, and setting up the neck relief, we can adjust their strings’ height over the frets. The height of each saddle is usually set up by adjusting two, three or four screws at the sides of the saddle ( ).
- Page 8 Adjusting intonation Adjusting the intonation is crucial to eliminating the error in the string pitch on certain frets. It consists of tuning the string exactly to the desired pitch and then fine tuning its bridge saddle to make the pitch at the 12th fret exactly an octave higher.
- Page 9 For Mayones VFret bass guitars, as well as the Cali model, we recommend purchasing special sets of strings specially prepared for these instruments.
- Page 10 The height of the strings over the pickups The distance between the pickups and the strings is an important factor of the instrument’s sound. This distance last fret depends on the type of pickups and the type of strings used.
- Page 11 Electronics Apart from traditional bass guitar electronics system – passive pickups and tone knobs, Mayones bass guitars may be equipped with active pickups and/or a preamp with an active tone control. Depending on the solution used, active tone control enables the player to independently cut or boost low, mid and high frequencies of the sound.
- Page 12 AUX In - Stereo Line Input This 1/8-inch stereo jack is used to plug in a line-level stereo input, from an external source - a smartphone, tablet, CD player, metronome, and so on. This input does not have a separate volume control, so the appropriate signal level must be set on the external device.
- Page 13 Important: Detailed informa on about the Mayones Musashi bass preamplifier with a 3-band EQ, a dedicated stereo headphone amplifier with an addi onal Aux input - Mayones Nitōryū 2.0, and the power module with a built-in lithium-polymer ba ery can be found in the specially prepared user manuals for these products.
- Page 14 Maintenance In order to maintain full technical efficiency and high aesthetic value of the instrument, it should be cleaned and maintained regularly. Regardless of the type of finish and the components used, the basic recommendations presented below should be followed: 1.
- Page 15 Surfaces with satin and matte finishes There are not many products on the market specifically designed for cleaning this type of surface, so the most important thing in this case is to maintain high levels of hygiene when using the instrument.
- Page 16 Find more information on guitar operation and maintenance and solving basic problems on our website www.mayones.com. Mayones Guitars and Basses care constantly about the quality of their instruments and release their newer and upgraded versions, as well as search for the best possible building materials.
