PER-T481
Intel® GbE LAN PCI-E [x4] Frame Grabber Card
User's Manual 1
st
Ed
Last Updated: April 24, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PER-T481 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aaeon PER-T481

Summary of Contents for Aaeon PER-T481

  • Page 1 PER-T481 Intel® GbE LAN PCI-E [x4] Frame Grabber Card User’s Manual 1 Last Updated: April 24, 2018...
  • Page 2 AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
  • Page 3 Acknowledgement All other products’ name or trademarks are properties of their respective owners. Microsoft Windows ® is a registered trademark of Microsoft Corp.  Intel , Platium , Celeron , and Xeon are registered trademarks of Intel ® ® ® ®...
  • Page 4 Before setting up your product, please make sure the following items have been shipped: Item Quantity PER-T481  Utility DVD for QIG (in PDF format) and Driver  If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
  • Page 5 (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the AAEON.com for the latest version of this document. Preface...
  • Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
  • Page 7 Do NOT disassemble the motherboard so as not to damage the system or void your warranty. If the thermal pad had been damaged, please contact AAEON's salesperson to purchase a new one. Do NOT use those of other brands. The Hex Cylinder Coppers on the front panel are not removable.
  • Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. Caution: There is a danger of explosion if the battery is incorrectly replaced.
  • Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON Embedded Box PC/ Industrial System 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 ○ ○ ○ ○ ○ ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○...
  • Page 10 China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products AAEON Embedded Box PC/ Industrial System Poisonous or Hazardous Substances or Elements Hexavalent Polybrominated Polybrominated Component Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &...

  • Page 11: Table Of Contents

    Table of Contents Chapter 1 - Product Specifications ..................1 PER-T481-A10 Specifications ................2 PER-T481-A20 Specifications ................4 Chapter 2 – Hardware Information ..................6 PER-T481-A10 ......................7 2.1.1 Dimensions ....................7 2.1.2 Jumpers and Connectors ..............8 2.1.3 List of Connectors ................... 9 2.1.3.1 LAN Connector (CN3) ..............

  • Page 12: Chapter 1 - Product Specifications

    Chapter 1 Chapter 1 - Product Specifications...

  • Page 13: Per-T481-A10 Specifications

    PER-T481-A10 Specifications System PCI-Express [x4], Gen 2 Bus Interface  PCI Express Specification Revision 2.1 at 5GT/s Intel® i211AT Ethernet Controller x 4 Ethernet  Bandwidth 1Gb/s for each port Fully compliant with IEEE 802.3 and IEEE 802.3u Support IEEE 1588 precision time synchronization Windows®...
  • Page 14 5 ~ 95% @ 40°C, non-condensing Storage Humidity  Chapter 1 – Product Specifications...

  • Page 15: Per-T481-A20 Specifications

    PER-T481-A20 Specifications System PCI-Express [x4], Gen 2 Bus Interface  PCI Express Specification Revision 2.1 at 5GT/s Intel® i211AT Ethernet Controller x 2 Ethernet  Bandwidth 1Gb/s for each port Fully compliant with IEEE 802.3 and IEEE 802.3u Support IEEE 1588 precision time synchronization Windows®...
  • Page 16 5 ~ 95% @ 40°C, non-condensing Storage Humidity  Chapter 1 – Product Specifications...

  • Page 17: Chapter 2 - Hardware Information

    Chapter 2 Chapter 2 – Hardware Information...

  • Page 18: Per-T481-A10

    PER-T481-A10 2.1.1 Dimensions Chapter 2 – Hardware Information...

  • Page 19: Jumpers And Connectors

    2.1.2 Jumpers and Connectors Chapter 2 – Hardware Information...

  • Page 20: List Of Connectors

    2.1.3 List of Connectors Please refer to the table below for all of the system’s connectors that you can configure for your application Label Function Connector Type RJ45.12P .90D(F).Notch Connector down.W/LED(L-G:R-O/G).DIP .UDE.RC1-1Q00000D RJ45.12P .90D(F).Notch Connector down.W/LED(L-G:R-O/G).DIP .UDE.RC1-1Q00000D RJ45.12P .90D(F).Notch Connector down.W/LED(L-G:R-O/G).DIP .UDE.RC1-1Q00000D RJ45.12P .90D(F).Notch Connector...

  • Page 21: Lan Connector (Cn3)

    2.1.3.1 LAN Connector (CN3) Pin Name MID0+ MID0- MID1+ MID1- MID2+ MID2- MID3+ MID3- 2.1.3.2 LAN Connector (CN4) Function MID0+ MID0- MID1+ MID1- MID2+ MID2- MID3+ MID3- Chapter 2 – Hardware Information...

  • Page 22: Lan Connector (Cn5)

    2.1.3.3 LAN Connector (CN5) Pin Name MID0+ MID0- MID1+ MID1- MID2+ MID2- MID3+ MID3- 2.1.3.4 LAN Connector (CN6) Function MID0+ MID0- MID1+ MID1- MID2+ MID2- MID3+ MID3- Chapter 2 – Hardware Information...

  • Page 23: Per-T481-A20

    PER-T481-A20 2.2.1 Dimensions Chapter 2 – Hardware Information...

  • Page 24: Jumpers And Connectors

    2.2.2 Jumpers and Connectors Chapter 2 – Hardware Information...

  • Page 25: List Of Connectors

    2.2.3 List of Connectors Please refer to the table below for all of the system’s connectors that you can configure for your application Label Function Connector Type RJ45.12P .90D(F).Notch Connector down.W/LED(L-G:R-O/G).DIP .UDE.RC1-1Q00000D RJ45.12P .90D(F).Notch Connector down.W/LED(L-G:R-O/G).DIP .UDE.RC1-1Q00000D Chapter 2 – Hardware Information...

  • Page 26: Lan Connector (Cn3)

    2.2.3.1 LAN Connector (CN3) Pin Name MID0+ MID0- MID1+ MID1- MID2+ MID2- MID3+ MID3- 2.2.3.2 LAN Connector (CN4) Function MID0+ MID0- MID1+ MID1- MID2+ MID2- MID3+ MID3- Chapter 2 – Hardware Information...

  • Page 27: Chapter 3 - Driver Installation

    Chapter 3 Chapter 3 – Driver Installation...

  • Page 28: Product Cd

    Product CD The PER-T481 comes with a product DVD that contains all the drivers and utilities you need to set up your product. Insert the DVD and follow the steps in the autorun program to install the drivers. In case the program does not start, follow the sequence below to install the drivers.
