Page 1: Quick Installation Guide
Mini PC I Module P E R - C 3 0 F PER-C30F Quick Installation Guide Part No. 2007C30F12 Printed in Taiwan Apr. 2007 PER-C30F Quick Installation Guide... -
Page 2: Table Of Contents
Product Warranty ................5 Ordering Information................. 7 Packing List ..................7 1.1 Features..................8 1.2 Specifications................8 1.3 Mechanical Drawing and Connector Locations ......9 1.4 PER-C30F Connector List ............11 1.5 PER-T010 Daughter Board Connector List ......13 PER-C30F Quick Installation Guide... -
Page 3: Safety Precautions
Use a grounding wrist strap at all times. Place all electronic components on a static-dissipative surface or in a static-shielded bag when they are not in the chassis PER-C30F Quick Installation Guide... -
Page 4: A Message To The Customer
P E R - C 3 0 F A Message to the Customer Fist of all, thank you for purchasing PER-C30F Mini PCI module. This Quick Installation Guide will help you on the process of the installation. Please read it thoroughly before you start to install it. -
Page 5: Product Warranty
Whether your purchase from AAEON is made for use in the laboratory or the factory facility, you can be assured that every purchase in AAEON will provide reliability and stability of operation. - Page 6 Mini PC I Module P E R - C 3 0 F over the phone. In addition, free technical support is available from AAEON engineers during office hours. We are always pleased to give advice regarding any installation and operation for AAEON products.
-
Page 7: Ordering Information
Mini PC I Module P E R - C 3 0 F Ordering Information PER-C30F-A10 Mini PCI 3-Port IEEE1394a Module Packing List PER-C30F PER-T010 daughter board Quick Installation Guide PER-C30F Quick Installation Guide... -
Page 8: Features
• TI single chip for IEEE1394a solution 1.2 Specifications • Form factor Mini PCI Type IIIA ( 50.8mm x 59.6mm ) • IEEE1394a Chipset TI TSB43AB23 • Power Request +3.3V, +5V, +12V • Operation Temp. 0°C ~ 60°C PER-C30F Quick Installation Guide... -
Page 9: Mechanical Drawing And Connector Locations
Mini PC I Module P E R - C 3 0 F 1.3 Mechanical Drawing and Connector Locations MPCI1 For model of PER-C30F PER-C30F Quick Installation Guide... - Page 10 Mini PC I Module P E R - C 3 0 F 10.60 35.00 29.46 29.00 29.00 14.55 6.00 6.00 0.00 16.50 18.00 18.00 For model of PER-T010 PER-C30F Quick Installation Guide...
-
Page 11: Per-C30F Connector List
+12V TPB- TPB+ TPA- TPA+ CHASSIS_GND CHASSIS_GND CHASSIS_GND Note: When using CN1 on PER-C30F to connect any IEEE1394 device, please don't connect PER-T010 daughter board to PER-C30F. CN1 on PER-C30F and PER-T010 cannot be used simultaneously. PER-C30F Quick Installation Guide... - Page 12 +12V +12V TPA3+ TPA3- Small 4P Power Connectors (CN3) – this connector is just for device power supply. It’s no need to connect it when your device has its own power supply Signal Signal +12V N.C. PER-C30F Quick Installation Guide...
-
Page 13: Per-T010 Daughter Board Connector List
IEEE1394 Connector Small 4P Power Connector (Optional) IEEE1394 Connectors (CN1, CN2, CN4) Signal Signal +12V TPB- TPB+ TPA- TPA+ CHASSIS_GND CHASSIS_GND HOLE1 HOLE2 Small 4P Connector (CN5)- this connector is not soldered on standard model Signal Signal PER-C30F Quick Installation Guide... - Page 14 Mini PC I Module P E R - C 3 0 F IEEE1394 BOX 3 ports HEADER (CN3) Signal Signal TPB1+ TPB1- +12V +12V TPA1+ TPA1- TPB2+ TPB2- +12V +12V TPA2+ TPA2- TPB3+ TPB3- +12V +12V TPA3+ TPA3- PER-C30F Quick Installation Guide...
- Page 15 Mini PC I Module P E R - C 3 0 F Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板...
