- Page 1 PER-T514 2 Port Intel® 10GbE LAN PCI-E [x4] Frame Grabber Card User’s Manual 1 Last Updated: November 30, 2018...
- Page 2 AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
- Page 3 Acknowledgement All other products’ name or trademarks are properties of their respective owners. Microsoft Windows ® is a registered trademark of Microsoft Corp. Intel , Platium , Celeron , and Xeon are registered trademarks of Intel ® ® ® ®...
- Page 4 Before setting up your product, please make sure the following items have been shipped: Item Quantity PER-T514 Utility DVD for QIG (in PDF format) and Driver If any of these items are missing or damaged, please contact your distributor or sales representative immediately.
- Page 5 (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the AAEON.com for the latest version of this document. Preface...
- Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
- Page 7 Do NOT disassemble the motherboard so as not to damage the system or void your warranty. If the thermal pad had been damaged, please contact AAEON's salesperson to purchase a new one. Do NOT use those of other brands. The Hex Cylinder Coppers on the front panel are not removable.
- Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. Caution: There is a danger of explosion if the battery is incorrectly replaced.
- Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON Embedded Box PC/ Industrial System 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 ○ ○ ○ ○ ○ ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○...
- Page 10 China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products AAEON Embedded Box PC/ Industrial System Poisonous or Hazardous Substances or Elements Hexavalent Polybrominated Polybrominated Component Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &...
-
Page 11: Table Of Contents
Table of Contents Chapter 1 - Product Specifications ..................1 PER-T514-A10 Specifications ................2 Chapter 2 – Hardware Information ..................4 Dimensions ......................5 Jumpers and Connectors ..................6 2.3 List of Jumpers ......................7 2.3.1 Debug Jumper (JP2) ................7 List of Connectors .................... -
Page 12: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications... -
Page 13: Per-T514-A10 Specifications
PER-T514-A10 Specifications System PCI-Express [x4], Gen 2 Bus Interface PCI Express Specification Revision 2.1 at 5GT/s 2 Port independent 10GbE Ethernet w/ Intel Ethernet X550 Controller Fully compliant with IEEE 802.3 and IEEE 802.3u Support IEEE 1588 precision time synchronization Support 15.5 KB Jumbo Frame, teaming... - Page 14 Environmental 0°F ~ 140°F(0°C ~ 60°C) (according to Operating Temperature IEC68-2-14 with 0.5 m/s AirFlow; with industrial devices) Storage Temperature -49°F ~ 185°F(-45°C ~ 80°C) 5 ~ 95% @ 40°C, non-condensing Storage Humidity Chapter 1 – Product Specifications...
-
Page 15: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information... -
Page 16: Dimensions
Dimensions Chapter 2 – Hardware Information... -
Page 17: Jumpers And Connectors
Jumpers and Connectors 1 3 6 . 0 J P1 C1 2 3 C1 2 9 C1 1 6 C1 1 5 C1 1 7 C1 1 3 C1 1 9 C1 1 8 CN4 4 C4 6 C1 4 8 CN4 4 R6 9 R7 0... -
Page 18: 2.3 List Of Jumpers
2.3 List of Jumpers Please refer to the table below for all of the system’s jumpers that you can configure for your application Label Function Debug mode jumper 2.3.1 Debug Jumper (JP2) 1 2 3 1 2 3 Debug Mode (1-2) Normal (2-3) (Default) Chapter 2 –... -
Page 19: List Of Connectors
List of Connectors Please refer to the table below for all of the system’s connectors that you can configure for your application Label Function RJ-45 connector RJ-45 connector CN44 FAN connector Chapter 2 – Hardware Information... -
Page 20: Connector (U4/U5)
2.4.1 RJ-45 Connector (U4/U5) Signal MDI0_P MDI0_N MDI1_P MDI1_N MDI2_P MDI2_N MDI3_P MDI4_N 2.4.2 FAN Connector (CN44) Signal Chapter 2 – Hardware Information... -
Page 21: Chapter 3 - Driver Installation
Chapter 3 Chapter 3 – Driver Installation... -
Page 22: Product Dvd
Product DVD The PER-T514 comes with a product DVD that contains all the drivers and utilities you need to set up your product. Insert the DVD and follow the steps in the autorun program to install the drivers. In case the program does not start, follow the sequence below to install the drivers.
