M i n i P C I T T L t o D V I M o d u l e
Notice
This guide is designed for experienced users to setup the system in
the shortest time.
Safety Precautions
Part No. 2007V02B11
Always completely disconnect the power cord
from your board whenever you are working
on it. Do not make connections while the
power is on, because a sudden rush of power
can damage sensitive electronic
components.
Always ground yourself to remove any static
charge before touching the board. Modern
electronic devices are very sensitive to static
electric charges. Use a grounding wrist strap
at all times. Place all electronic components
on a static-dissipative surface or in a
static-shielded bag when they are not in the
chassis
P E R - V 0 2 B
Printed in Taiwan
PER-V02B Quick Installation Guide 1
Jan. 2007
Advertisement
Table of Contents
Related Manuals for Aaeon PER-V02B
Summary of Contents for Aaeon PER-V02B
-
Page 1: Safety Precautions
Use a grounding wrist strap at all times. Place all electronic components on a static-dissipative surface or in a static-shielded bag when they are not in the chassis Part No. 2007V02B11 Printed in Taiwan Jan. 2007 PER-V02B Quick Installation Guide 1... -
Page 2: A Message To The Customer
P E R - V 0 2 B A Message to the Customer Fist of all, thank you for purchasing PER-V02B Mini PCI TTL to DVI Module. This Quick Installation Guide will help you on the process of the installation. Please read it thoroughly before you start to install it. -
Page 3: Product Warranty
Whether your purchase from AAEON is made to the purpose of the laboratory or the factory facility, you can be assured that every purchase in AAEON will provide the reliability and stability of operation. - Page 4 P E R - V 0 2 B easily solved over the phone. In addition, free-charged technical support is available from AAEON engineers in the office time. We are always pleased to give advice regarding to any installation and operation for AAEON products.
-
Page 5: Ordering Information
P E R - V 0 2 B Ordering Information • PER-V02B-A10 Mini PCI TTL to DVI LCD Signal Conversion Module Packing List • TTL LCD Cable • Quick Installation Guide • PER-V02B Optional Accessories • 1700200200 DVI Cable • 1703400207 TTL Cable PER-V02B Quick Installation Guide... -
Page 6: Table Of Contents
1.8 DVI Internal Connector (DVI1) ........10 1.9 DVI External Connector (CN2) ..11 1.10 TTL_LCD DF13-10P Connector (CN1) (Optional) ...... 11 1.11 TTL_LCD DF13-40P Connector (CN3) ...... 12 1.12 TTL_LCD DF13-20P Connector (CN4) .......... 13 1.13 Power Connector (CN5) PER-V02B Quick Installation Guide... -
Page 7: Features
Resolution Supports up to 1600 x 1200 1.2 Specifications • Form Factor: Mini PCI Type III A (50.8mm x 59.6mm) • Signal Conversion Chipset: Silicon Image Sil1160CTU • Power Request: +3.3V • Operating Temperature: 32˚F~140˚F (0˚C~60˚C) PER-V02B Quick Installation Guide... -
Page 8: Location Of Jumpers And Connectors
M i n i P C I T T L t o D V I M o d u l e P E R - V 0 2 B 1.3 Location of Jumpers and Connectors 1.4 Mechanical Drawing (10.86) (10.00) (5.40) (0.80) 53.40 47.36 46.86 46.86 18.37 14.03 7.59 6.47 0.00 0.00 0.31 6.35 (5.40) PER-V02B Quick Installation Guide... -
Page 9: List Of Jumpers
1.7 List of Connector Label Function DVI1 DVI Internal Connector TTL_LCD DF13-10P Connector DVI External Connector TTL_LCD DF13-40P Connector TTL_LCD DF13-20P Connector POWER Connector 1.8 DVI Internal Connector (DVI1) Pin Signal Signal DVI_TX2- DVI_TX2+ DDC_CLK DDC_DATA PER-V02B Quick Installation Guide... -
Page 10: Dvi External Connector (Cn2)
M i n i P C I T T L t o D V I M o d u l e P E R - V 0 2 B DVI_TX1- DVI_TX1+ HPDET DVI_TX0- DVI_TX0+ DVI_TXC+ DVI_TXC- 1.9 DVI External Connector (CN2) Signal Signal DVI_TX1+ DVI_TX1- DVI_TXC+ DVI_TXC- HPDET DVI_TX2+ DVI_TX2- DVI_TX0+ DVI_TX0- DDC_DATA DDC_CLK PER-V02B Quick Installation Guide... -
Page 11: Ttl_Lcd Df13-10P Connector (Cn1) (Optional)
1.10 TTL_LCD DF13-10P Connector (CN1) (Optional) Signal Signal O_BLUE0 O_BLUE1 O_GREEN0 O_GREEN1 O_RED0 O_RED1 1.11 TTL_LCD DF13-40P Connector (CN3) Signal Signal +3.3V +3.3V E_BLUE0 E_BLUE1 E_BLUE2 E_BLUE3 E_BLUE4 E_BLUE5 E_BLUE6 E_BLUE7 E_GREEN0 E_GREEN1 E_GREEN2 E_GREEN3 E_GREEN4 E_GREEN5 E_GREEN6 E_GREEN7 E_RED0 E_RED1 PER-V02B Quick Installation Guide... -
Page 12: Ttl_Lcd Df13-20P Connector (Cn4)
P E R - V 0 2 B E_RED2 E_RED3 E_RED4 E_RED5 E_RED6 E_RED7 ODCK VSYNC HSYNC 1.12 TTL_LCD DF13-20P Connector (CN4) Signal Signal O_BLUE2 O_BLUE3 O_BLUE4 O_BLUE5 O_BLUE6 O_BLUE7 O_GREEN2 O_GREEN3 O_GREEN4 O_GREEN5 O_GREEN6 O_GREEN7 O_RED2 O_RED3 O_RED4 O_RED5 O_RED6 O_RED7 PER-V02B Quick Installation Guide... -
Page 13: Power Connector (Cn5)
3. Connecting CN3 & CN4 & CN1 for 18-bit, 24-bit, 36-bit, 48-bit LCD. 4. CN5 is not needed if plugging in Mini PCI slot. 5. Please use either DVI1 or CN2 for DVI output. DVI1 and CN2 cannot be used simultaneously. PER-V02B Quick Installation Guide...
