- Page 1 FPA405 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call: 1-888-333-9952 (UK: 0800-056-2853) we’re ready to help!
-
Page 2: Before You Begin
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Before You Begin Please check the following items: Your TV and any accessories you plan to use do not exceed the specifi ed weight limit of your TV mount. ... - Page 3 WARNING: • This product is only designed to be used with Sanus VuePoint television mounts and mounted BELOW the television. • This soundbar mount was designed to be installed and utilized ONLY as specifi ed in this manual. The manufacturer is not responsible for improper assembly, use, or handling of this product.
-
Page 4: Items Needed
Weight Limit for the FPA405 Items Needed Phillips Screwdriver 15 lb (6.8 kg) DO NOT EXCEED! Level CAUTION: Avoid potential personal injuries and property damage! You must verify that the weight of the TV plus the soundbar mount, soundbar, and any accessories is lower than the maximum weight rating of the TV mount. -
Page 5: Arm Position
Arm Position NOTE: TV/bracket arms should be positioned as vertically as possible. - Page 6 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
- Page 7 Parts and Hardware for STEP 3 Hardware for TV Bracket TV Screw Washers TV Bracket Arm M4/M5 M6/M8 Mount Spacer Large M4/M5 Large M6/M8...
- Page 8 Hardware for TV Bracket Screws for TVs with a Flat/Unobstructed Back M4 x 16mm M6 x 16mm M5 x 16mm M6 x 25mm M8 x 20mm...
- Page 9 Hardware for TV Bracket Screws for TVs with Irregular/Obstructed Backs M4 x 40mm M5 x 40mm M6 x 40mm M6 x 50mm Spacer for TVs with Irregular/ Obstructed Backs M8 x 40mm...
- Page 10 STEP 1 Mount Bracket Arms to Soundbar - Option 1 Check the compatibility of the soundbar bracket with your soundbar. Assemble knobs and screws Attach the soundbar arms to soundbar. Do not fully tighten the knobs NOTE: When planning on the position of the soundbar, make sure you will be able to access the control buttons.
- Page 12 STEP 1 Mount Bracket Arms to Soundbar - Option 2 Check the compatibility of the soundbar bracket with your soundbar. Assemble knobs and screws Some connections to the soundbar may require a “C” washer to ensure that the soundbar arms lay fl...
- Page 14 STEP 1 Mount Bracket Arms to Hanger - Option 3 Some soundbars will come with a manufacturer supplied hanger. Attach the soundbar arms to the soundbar hanger with knobs and screws Do not fully tighten the knobs...
- Page 15 SOUNDBAR MANUFACTURER SUPPLIED HANGER...
- Page 16 Prepare TV STEP 2 If your TV is already mounted: Remove any cables attached to the TV. Remove the TV/bracket assembly from the wall plate, arm assembly, or pillar. Please see your TV wall mount installation manual for guidance. HEAVY! You may need assistance with this step! Remove the TV bracket from the TV.
- Page 18 Install TV Bracket with the TV/Bracket Arms STEP 3 Determine the bolt diameter for your monitor Step 3-1 Step 3-2 and your TV type - M4, M5, M6, or M8. • For TVs with a fl at/unobstructed back, see Step 3-1 •...
- Page 19 STEP 3-1 11 12 13 14 15 07 08 09 10 WARNING: must use the larger washers unless they do not fi t your tv bracket. NOTE: Soundbar must be mounted below the TV as shown.
- Page 20 STEP 3-2 16 17 18 19 20 07 08 09 10 WARNING: must use the larger washers unless they do not fi t your tv bracket. NOTE: Soundbar must be mounted below the TV as shown.
