- Page 1 A405 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call: 1-800-359-5520 we’re ready to help!
-
Page 2: Before You Begin
IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Before You Begin Please check the following items: Your TV and any accessories you plan to use do not exceed the specifi ed weight limit of your TV mount. ... - Page 3 WARNING: • This product is only designed to be used with Sanus Accents television mounts and mounted BELOW the television. • This soundbar mount was designed to be installed and utilized ONLY as specifi ed in this manual. The manufacturer is not responsible for improper assembly, use, or handling of this product.
-
Page 4: Items Needed
Weight Limit for the A405 Items Needed Phillips Screwdriver 15 lb (6.8 kg) DO NOT EXCEED! Level CAUTION: Avoid potential personal injuries and property damage! You must verify that the weight of the TV plus the soundbar mount, soundbar, and any accessories is lower than the maximum weight rating of the TV mount. - Page 5 Arm Position NOTE: TV/bracket arms should be positioned as vertically as possible.
- Page 6 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
- Page 7 Parts and Hardware for STEP 3 Hardware for TV Bracket TV Screw Washers TV Bracket Arm M4/M5 M6/M8 Mount Spacer Large M4/M5 Large M6/M8...
- Page 8 Hardware for TV Bracket Screws for TVs with a Flat/Unobstructed Back M4 x 16mm M6 x 16mm M5 x 16mm M6 x 25mm M8 x 20mm...
- Page 9 Hardware for TV Bracket Screws for TVs with Irregular/Obstructed Backs M4 x 40mm M5 x 40mm M6 x 40mm M6 x 50mm Spacer for TVs with Irregular/ Obstructed Backs M8 x 40mm...
- Page 10 STEP 1 Mount Bracket Arms to Soundbar - Option 1 Check the compatibility of the soundbar bracket with your soundbar. Assemble knobs and screws Attach the soundbar arms to soundbar. Do not fully tighten the knobs NOTE: When planning on the position of the soundbar, make sure you will be able to access the control buttons.
- Page 12 STEP 1 Mount Bracket Arms to Soundbar - Option 2 Check the compatibility of the soundbar bracket with your soundbar. Assemble knobs and screws Some connections to the soundbar may require a “C” washer to ensure that the soundbar arms lay fl...
- Page 14 STEP 1 Mount Bracket Arms to Hanger - Option 3 Some soundbars will come with a manufacturer supplied hanger. Attach the soundbar arms to the soundbar hanger with knobs and screws Do not fully tighten the knobs...
- Page 15 SOUNDBAR MANUFACTURER SUPPLIED HANGER...
- Page 16 Prepare TV STEP 2 If your TV is already mounted: Remove any cables attached to the TV. Remove the TV/bracket assembly from the wall plate, arm assembly, or pillar. Please see your TV wall mount installation manual for guidance. HEAVY! You may need assistance with this step! Remove the TV bracket from the TV.
- Page 18 Install TV Bracket with the TV/Bracket Arms STEP 3 Determine the bolt diameter for your monitor Step 3-1 Step 3-2 and your TV type - M4, M5, M6, or M8. • For TVs with a fl at/unobstructed back, see Step 3-1 •...
- Page 19 STEP 3-1 11 12 13 14 15 07 08 09 10 WARNING: must use the larger washers unless they do not fi t your tv bracket. NOTE: Soundbar must be mounted below the TV as shown.
- Page 20 STEP 3-2 16 17 18 19 20 07 08 09 10 WARNING: must use the larger washers unless they do not fi t your tv bracket. NOTE: Soundbar must be mounted below the TV as shown.
- Page 21 CAUTION: The end of the TV/bracket arms must not extend beyond the edge of the TV.
- Page 22 Attach Soundbar Assembly to TV STEP 4 Attach the soundbar/bracket arm assembly to the TV/bracket arms using knobs . Do not completely tighten the connections. NOTE: You may need to use trial and error to get the soundbar TV brackets set to the right confi...
- Page 23 Options 1 and 2 Option 3...
- Page 24 Adjust Arms STEP 5 Adjust the soundbar/bracket arms and the TV/bracket arms until soundbar or hanger is the in desired position. NOTE: Final position of soundbar must be within 51 mm (2 in.) of the TV.
- Page 25 ≤51 mm (2 in.)
- Page 26 Tighten Connections STEP 6 When soundbar or hanger is in the desired position, tighten all connections.
- Page 27 Hang Assembly STEP 7 Follow your TV wall mount installation manual to re-hang the assembly. Options 1 and 2 Option 3...
-
Page 28: Antes De Comenzar
ESPAÑOL INSTRUCCIONES DE SEGURIDAD IMPORTANTES. CONSÉRVELAS. LEA TODO EL MANUAL ANTES DE UTILIZAR ESTE PRODUCTO. Antes de comenzar Revise los siguientes puntos: Que su televisor y cualquier accesorio que vaya a utilizar no excedan el límite de peso especificado del soporte del televisor. ... - Page 29 ADVERTENCIA: • Este producto fue diseñado para usarse únicamente con soportes para televisores Sanus Accents y deben colocarse DEBAJO del televisor. • Este soporte para barra de sonido fue diseñado para instalarse y utilizarse SOLO como se especifica en este manual. El fabricante no se hace responsable por el armado, manipulación o uso incorrectos de este producto.
-
Page 30: Piezas Necesarias
ESPAÑOL Límite de peso para el A405 Posición del brazo 6,8 kg (15 libras) NOTA: Los brazos del módulo televisor-placas deben colocarse lo más verticales posible. ¡NO LO EXCEDA! Piezas y accesorios suministrados PRECAUCIÓN: Evite lesiones y daños materiales. ADVERTENCIA:... - Page 31 ESPAÑOL PASO 1 Instalar los brazos de la placa de sujeción a la barra de sonido (Opción 1) Verifique la compatibilidad de la placa de sujeción para barra de sonido con su barra de sonido. Ensamble las perillas y tornillos Acople los brazos de la barra de sonido a la barra de sonido.
- Page 32 ESPAÑOL PASO 1 Instalar los brazos de la placa de sujeción al soporte (Opción 3) Algunas barras de sonido vienen con un soporte proporcionado por el fabricante. Acople los brazos de la barra de sonido al soporte de la misma con las perillas los tornillos No ajuste completamente las perillas PASO 2...
- Page 33 ESPAÑOL ! Guarde los elementos de sujeción del televisor en caso de desear utilizar en el futuro el televisor sin la barra de sonido. ! Debe utilizar los elementos de sujeción proporcionados con este producto en lugar de aquellos que vinieron con el soporte. PASO 3 Instale la placa de sujeción del televisor con el módulo televisor-placas Determine el diámetro de los pernos para su monitor y su tipo de televisor: M4, M5, M6, o M8.
- Page 34 ESPAÑOL PASO 3-1 PASO 3-2 ADVERTENCIA: Debe usar las arandelas más grandes , a menos que no sean adecuadas para el soporte del televisor. NOTA: La barra de sonido debe colocarse debajo del televisor, tal como se muestra. PRECAUCIÓN: Los extremos de los brazos del televisor/placa de sujeción no deben sobrepasar el borde del televisor.
- Page 35 ESPAÑOL PASO 5 Ajuste los brazos Acomode los brazos de la barra de sonido/placa de sujeción y los brazos del televisor/ placa de sujeción hasta que la barra de sonido o el soporte de la misma se encuentre en la posición deseada. NOTA: La barra de sonido debe colocarse a una distancia máxima de 51 mm (2'') del televisor.
-
Page 36: Customer Service
