- Page 1 AST16 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-800-359-5520. We’re ready to help! Scan for easy install video san.us/390...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Before getting started, let’s make sure this mount is perfect for you! Does your TV weigh more than 50 lb (22.7 kg) including accessories? No — Perfect! 50 lb (22.7 kg) Yes —...
- Page 3 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;...
- Page 4 STEP 1 Parts and Hardware Cont. Washers TV Screws M4 x 12mm M4 x 35mm M4/M5 M5 x 12mm M5 x 35mm Spacers M6 x 12mm M6 x 35mm...
- Page 5 STEP 2 Parts and Hardware Wall Plate Wall Plate Template Lag Bolts 1/4 x 2 ½ in.
- Page 6 STEP 1 Attach TV Bracket to TV 1-1 Measure Your TV Hole Pattern 1-2 Assemble Your TV Bracket Determine which TV bracket configuration to use, A or B based on Measure the width and height of your TV hole pattern in mm. your TV hole pattern measurements.
- Page 7 200 x 200 Assemble TV bracket extenders onto TV bracket as illustrated. Secure using the screws and nuts as shown.
- Page 8 1-3 Select TV Screw Diameter 1-4 Select TV Screw Length Hand thread screws into the threaded inserts If your TV has a flat back, use the shorter screws. on the back of your TV to determine which Spacers and longer screws are supplied to accommodate: screw diameter (M4, M5, or M6) to use.
- Page 9 1-5 Attach TV Bracket Position your TV bracket configuration over your TV hole pattern - making sure the brackets are vertically centered and level. Install using either the short screw and washer or spacer, long screw and washer combination you selected for your TV. NOTE: If the hole pattern on your TV is 75 x 75 mm the washers...
- Page 10 Wood Stud ONLY STEP 2 Attach Wall Plate CAUTION: Avoid potential personal injuries and property damage! ● Drywall covering the wall must not exceed 16 mm (5/8 in.) ● Minimum wood stud size: common 51 x 102 mm (2 x 4 in.) nominal 38 x 89 mm (1½ x 3½ in.) Locate your stud.
- Page 11 Drill pilot holes using a 3 mm (1/8 in.) diameter drill bit. Remove wall plate template IMPORTANT: Be sure to drill into the center of the stud. IMPORTANT: Pilot holes must be drilled to a depth of 63.5 mm (2½ in.). Install wall plate using lag bolts .
- Page 12 STEP 3 Attach TV to Wall HEAVY! You may need assistance with this step. IMPORTANT: The locking tab needs to be in the unlocked position before attaching the TV to the wall plate. Once the TV is on the wall plate, the locking tab needs to be in the locked position.
- Page 13 TV Adjustments ADJUSTING THE TILT: Loosen the knob on the TV bracket to adjust REMOVING THE TV: Place the locking tab into the unlocked the tilt of your TV. Tighten the knob when your TV is set to the desired position and lift the TV up and out away from the wall plate.
- Page 14 Dimensions [mm] 7.87 200.0 [45.75] 3.94 100.0 2.95 75.0 3.94 5.25 6.17 7.87 2.95 200.0 100.0 133.3 156.7 75.0...
- Page 16 ESPAÑOL INSTRUCCIONES DE SEGURIDAD IMPORTANTES. CONSÉRVELAS. LEA TODO EL MANUAL ANTES DE UTILIZAR ESTE PRODUCTO. Antes de comenzar, verifiquemos que este soporte sea perfecto para usted. ¿Su televisor pesa más de 22.7 kg (50 libras), incluidos los accesorios? No — ¡Perfecto! (22.7 kg) 50 libras Sí...
- Page 17 ESPAÑOL Piezas y accesorios suministrados ADVERTENCIA: Este producto contiene piezas pequeñas que, si fuesen tragadas, podrían producir asfixia. Antes de iniciar el ensamblaje, compruebe que todas las piezas estén incluidas y en buenas condiciones. Si faltan piezas o alguna está dañada, no devuelva el artículo al distribuidor;...
- Page 18 ESPAÑOL 1-4 Seleccione la longitud de los tornillos 1-3 Seleccione el diámetro de para el televisor los tornillos para el televisor Enrosque manualmente los tornillos en los Si el dorso del televisor es plano, utilice los PRECAUCIÓN: encastres roscados del dorso del televisor a tornillos cortos.
-
Page 19: Ajustes Del Televisor
ESPAÑOL Con una mecha de 3 mm (1/8'') de diámetro, realice los orificios guía. Retire la plantilla de placa mural IMPORTANTE: Asegúrese de perforar el centro del montante. IMPORTANTE: Los orificios guía deben realizarse hasta una profundidad de 63.5 mm (2½''). Instale la placa mural usando los tornillos tirafondo . - Page 20 Thank you for choosing Sanus Accents! Please take a moment to let us know how we did: Call us: 800-359-5520 Email us: info@sanus.com Leave a review: accents.sanus.com Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations.
