AMF112 Instruction Manual
Milestone AV Technologies
6436 City West Parkway
Eden Prairie, MN 55344 USA
Customer Service
Americas: 800-359-5520 • 651-484-7988 • info@sanus.com
Europe, Middle East, and Africa: +31 (0) 495 580 852 • europe.sanus@milestone.com
Asia Pacifi c: 86 755 8996 9226 • sanus.ap@milestone.com
accents.sanus.com
©2012 Milestone AV Technologies, a Duchossois Group Company.
All rights reserved. Accents is a Milestone brand.
All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
(6904-002010 <01>)
Scan here to view
product demo and install
videos or visit san.us/103

Advertisement

loading
Need help?

Need help?

Do you have a question about the AMF112 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for sanus accents AMF112

Summary of Contents for sanus accents AMF112

  • Page 1 AMF112 Instruction Manual Scan here to view product demo and install videos or visit san.us/103 Milestone AV Technologies 6436 City West Parkway Eden Prairie, MN 55344 USA Customer Service Americas: 800-359-5520 • 651-484-7988 • info@sanus.com Europe, Middle East, and Africa: +31 (0) 495 580 852 • europe.sanus@milestone.com Asia Pacifi...

  • Page 2: Technical Specifications

    IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Specifi cations Weight capacity-DO NOT EXCEED: 27 kg (60 lb) includes TV and any accessories Tilt: ± 15° CAUTION: Avoid potential personal injuries and property damage! Do not use this product for any purpose not explicitly specifi ed by manufacturer.
  • Page 3 Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: M4, M6, or M8 describes the diameter, mm describes the length of screws that are labeled M# X ##mm.
  • Page 4 Install TV Brackets Before you begin, hand thread screws into the threaded inserts on the back of your TV to determine the correct screw diameter (M4, M6, or M8). Verify that there are adequate threads to secure the brackets to the monitor. If you encounter resistance, stop immediately and contact customer service.
  • Page 5 For TVs with a fl at/unobstructed back Ensure that the bracket is level on the back of the TV. If you need extra space to accommodate cables, recesses, or protrusions, see the installation option that uses spacers. [02] [03] [03] [02] [02] [02]...
  • Page 6 For TVs with an irregular/obstructed back Ensure that the brackets are level on the back of the TV. Standard confi gurations are shown. For special applications, or if you are uncertain about your hardware selection, contact Customer Service. [02] [03] [03] [02] [02]...
  • Page 7 Attach horizontal brackets Slide the horizontal brackets [04] and [05] onto the vertical brackets [02] and [03]. Make sure that they are evenly spaced left to right. Install screws [22] to lock horizontal brackets [04] and [05] in position. [04] [03] [02] [05]...
  • Page 8 Mount the Wall Plate 13 mm 5.5 mm Wood Stud (1/2 in.) (7/32 in.) Locate stud. Verify the center of the stud with an awl or Tighten the lag bolts [08] only until the washers [07] are thin nail or use an edge to edge stud fi nder. pulled fi rmly against the wall plate [01].
  • Page 9 Mount the Wall Plate 13mm 10mm Solid Concrete and Concrete Block (1/2 in.) (3/8 in.) Level wall plate and mark the hole locations. Insert lag bolt anchors [06]. Be sure the anchors [06] are seated fl ush with the concrete surface. CAUTION: To avoid potential injuries or property damage:...
  • Page 10 Hang the TV/Bracket Assembly onto the Swing Arm HEAVY! You will need assistance with this step. Level the TV/bracket assembly and install the washer [20] and retaining screw [21]. CAUTION: Avoid potential injuries or property damage! Be sure to install the washer [20] and retaining screw [21] securely.

  • Page 11: Manage Cables

    Manage Cables NOTE: Be sure to leave enough slack in the cables to allow the monitor to move freely. [01] [01] [01] 6904-002010 <01>...

  • Page 12: Adjust Tension

    Adjust Tension A. Adjust arm extension and swivel tension. Adjust up/down tilt tension. NOTE: For clarity TV is not shown. [23] [24] Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations.
