ResMed AirTouch N20 Fittings Manual

Fitting guide for AirTouch N20
1 2
• Twist and pull both magnetic clips away • With both lower headgear straps released,
from the frame. hold the mask against the patient's face.
• Pull the headgear over the patient's head,
ensuring that the ResMed logo on the
headgear is facing up.
4 5
• Undo the fastening tabs on the upper • Undo the fastening tabs on the lower
headgear straps. headgear straps.
• Adjust the straps evenly until the mask sits • Adjust the straps evenly until the mask
comfortably just over the nose. is stable.
• Reattach the fastening tabs.
Incorrect Correct
position position
1 ResMed guided external clinical study of 29 evaluable CPAP users from Sept. 11, 2017 to Feb. 19, 2018 in San Diego, CA, who trialed AirTouch F20 at home for 30 nights each in place of their
prescribed mask.
2 CPAP users rated mask criteria on a Likert Scale of 1-5. Scores were 4 (Good) to 5 (Very good)
AirFit, AirTouch, InfinitySeal and UltraSoft are trademarks and/or registered trademarks of the ResMed family of companies. Specifications may change without notice. For patent and other
intellectual property information, see ResMed.com/ip. © 2020 ResMed. 10112274 2020-11
3
• Bring the lower straps below the
patient's ears, and attach the magnetic
clip to the frame.
6
• Connect the air tube on the device to the
short tube.
• Attach the elbow to the mask. First, press
the elbow's side buttons, and then push the
elbow into the mask, ensuring it clicks in on
both sides.
• Start the device.
Refer to the user guide for further instructions
and complete labeling information including
indications, contraindications, warnings
and precautions.
ResMed.com/AirTouchN20
Our softest nasal
mask ever
Specifically designed for extra comfort, ResMed AirTouch™ N20
is our gentlest type of mask that users can put on their skin. But
its unique UltraSoft™ memory foam cushion isn't just soft; it's
also extremely good at moulding itself to the contours of the
face for a personalised fit. Users seem to agree, with 90% of
them rating the memory foam cushion to be very comfortable.¹ ²
,
ResMed.com/AirTouchN20
