- Page 1 WORKPRO LIGHT MOUNT (ABOVE CROSSBAR) PRIME DESIGN, A SAFE FLEET BRAND Address: 580 Opperman Drive, Eagan, MN 55123 ▪ Toll Free: 1.8.PRIME.RACK Fax: 651-552-1799 ▪ Email: info@primedesign.net ▪ Website: www.primedesign.net...
- Page 2 CONTENTS OVERVIEW NOTE: The Gen4 HBR Rack and WorkPro LED Light shown in this Manual are for illustrative purposes only, and are not included in this Kit. ASH-8035 WorkPro Light Mount, Below Crossbar Top Connector (1X) Clamp Connector Pair (1X) M8 x 70MM (2X) M8 x 25 MM (1X) M8 Lock Nut (3X)
- Page 3 WORKPRO LIGHT MOUNT INSTALLATION SEQUENCE 1–3 NOTE: The Gen4 HBR Rack and WorkPro LED Light shown in this Manual are for illustrative purposes only, and are not included in this Kit. This Light Mount Kit contains only the parts needed to repair, replace, or retrofit one Light Mount.
- Page 4 MOUNTING LIGHT TO CROSSBAR ADJUSTMENTS Install the WorkPro Light with the attached Adjust to desired positioning. Top Connector onto the Crossbar and Clamp Connectors using the hardware shown. NOTE: If installing more that one WorkPro Light and Mount, repeat Steps 1-2 and Finger-tighten only until step 3.2.
