- Page 1 Installation and Operation Manual Thermo Scientific General Purpose and Flammable Storage Laboratory Refrigerators and Freezers...
- Page 2 © 2010 Thermo Fisher Scientific. All rights reserved. ® “Suva ” is a registered trademark of DuPont. All other trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries.
- Page 3 General Purpose and Flammable Materials Storage Refrigerators and Freezers Cool-Lab General Purpose: 3767A, 3767-1A, 3766A, 3766-1A Flammable Material Storage: 3552-10A, 3552-11A, 3552-11ACN, 3566-10A, 3566-11A, 3566-11ACN 3560-10A, 3560-11A 107774 Rev. A...
-
Page 4: Table Of Contents
Table of Contents Safety Information ..............................3 Alert Signals..............................3 Unpacking ................................4 Visible Loss or Damage..........................4 Concealed Loss or Damage ........................4 Performance Characteristics ..........................5 Temperature Ranges ............................5 Temperature Stability ............................5 Electrical Requirements..........................5 Installation ................................6 Selecting a Location ............................6 Leveling the Unit ............................6 Shelves ................................6 Electrical Connection ............................6 Operation ................................8... -
Page 5: Safety Information
Safety Information Alert Signals Your satisfaction and safety are important to us and a complete understanding of this unit is necessary to attain these objectives. Warning As the ultimate user of this apparatus, it is your responsi- Warnings alert you to a possibility of bility to understand its proper function and operational personal injury. -
Page 6: Unpacking
Unpacking Save all packing material if apparatus is received dam- aged. This merchandise was carefully packed and thor- oughly inspected before leaving our factory. Responsibility for its safe delivery was assumed by the carrier upon acceptance of the shipment; therefore, claims for loss or damage sustained in transit must be made upon the carrier by the recipient as follows: Visible Loss or Damage... -
Page 7: Performance Characteristics
Performance Characteristics Temperature Ranges Refrigerator: 3° to 13°C (37° to 55°F) Freezer: -20° to -10°C (-4° to 14°F) Temperature Stability @ 4 °C ±4 °C @ -20 °C ±4 °C Electrical Requirements See dataplate attached to unit. -
Page 8: Installation
Installation Selecting a Location Choose a location for the refrigerator that will provide at least four inches of clearance between the cabinet and any adjacent vertical surface at the sides and four inches at the rear. Twelve inches of clearance is required above the top surface of the refrigerated cabinet. - Page 9 NSTALLATION voltage is often the cause of service complaints. With the unit running, check that the line voltage is within ±10% of Warning that specified on the data plate. For personal safety this unit must be properly grounded. The power cord on this product is equipped with a three- prong (grounding) plug appropriate for the voltage, cur- rent, and location for which it was designed.
-
Page 10: Operation
Operation Initial Startup Warning Turn power on and verify that the condenser fan is run- ning. This model has a condenser fan located on the con- If the unit is tilted in excess of 30 densing unit on top of the cabinet. degrees, do not apply electrical power for a minimum of 12 hours. - Page 11 PERATION Aluminum Alloys are susceptible to corrosion when exposed to but not limited to most inorganic acids, bases and salts with a pH outside of their passive range of pH 4 to 9. It is also important to recognize that the compatibili- ty of aluminum alloys with mixtures of organic compounds cannot always be predicted from their compatibility with each of the compounds.
-
Page 12: Troubleshooting
Troubleshooting This table is intended to assist in resolving user-correctable refrigerator problems by relating symptoms to their likely causes. If service beyond the scope of this table is required, contact Customer Service at 1-800-438-4851. Symptom Probable Cause Action Does Not Run Unit Unplugged Plug in Unit Blown fuse or tripped circuit... -
Page 13: Maintenance
Maintenance Cabinet Cleaning Warning The cabinet interior should be cleaned frequently. Any When servicing the unit, disconnect spilled liquid should be wiped off immediately. Stains from the electrical power source. resulting from some spills can be permanent if not quickly removed. -
Page 14: Warranty
(ii) misuse (including use inconsistent with written operating instructions for the product), mishandling, contamination, overheating, modification or alteration of the product by any customer or third party or (iii) use of replacement parts that are obtained from a party who is not an authorized dealer of Thermo Scientific prod- ucts. - Page 15 Ulteriori informazioni sulla conformità di Thermo Fisher Scientific con queste Direttive, l’elenco delle ditte di riciclaggio nel Vostro paese e informazioni sui prodotti Thermo Scientific che possono essere utili alla rilevazione di sostanze soggette alla Direttiva RoHS sono disponibili sul sito www.thermo.com/ France Conformité...
- Page 16 Important For your future reference and when contacting the factory, please have the following information readily available: Model Number: Serial Number: Date Purchased: The above information can be found on the dataplate attached to the equipment. If available, please provide the date purchased, the source of purchase (manufacturer or specific agent/rep organization), and purchase order number.
- Page 17 Thermo Fisher Scientific Inc. 275 Aiken Road Asheville, NC 28804 United States www.thermofisher.com 107774 Rev. A...
