Kramer WAV-6YC User Manual

Congratulations on purchasing your Kramer Wall Plate Inserts (each is supplied with the
required screws)! They are ideal for the following applications: board, conference and training
rooms, presentation systems, and home theater. Each insert can be used with the Kramer
WP Frame or with one of our TBUS products.
W-COM1
The W-COM1 is a single-insert COM
port on a DB9 connector (for use with
RS-232, RS-422, and RS-485) with a
terminal block at the rear.
The terminal block PINOUT is as follows:
PIN 2
PIN 3
PIN 5
WAV-6YC
The WAV-6YC is a one-gang wall plate insert
Computer graphics video on an HD15 connector and unbalanced stereo audio
on a 3.5mm mini plug connector
s-Video on a 4p connector
Composite video on a yellow RCA connector
Unbalanced stereo audio on RCA connectors (white for L and red for R)
Version for Belgium and Germany
PIN 8
PIN 7
1 Available in three versions: one for Belgium and Germany, one for England and Europe (except Belgium and Germany), and one for the
United States
with pass through connectors for:
1
Version for the UK and Europe
Version for the United States
