SUPPLEMENTAL INSTRUCTIONS

3062-36TL

Back-Mount Carabiner Lock

Complies with current ANSI Z359.14 and all applicable

OSHA regulations and requirements.

Reliance Industries

Phone: 281-930-8000

P.O. Box 2046

Toll Free: 888-362-2826

Deer Park, TX 77536

Fax: 281-930-8666

Need help?

Do you have a question about the 3062-36TL and is the answer not in the manual?

Page 1 SUPPLEMENTAL INSTRUCTIONS 3062-36TL Back-Mount Carabiner Lock Complies with current ANSI Z359.14 and all applicable OSHA regulations and requirements. Reliance Industries Phone: 281-930-8000 P.O. Box 2046 Toll Free: 888-362-2826 Deer Park, TX 77536 Fax: 281-930-8666...
Page 2 1. Pull both webbing shoulder 2. Lift the arms of the carabiner straps in the back D-ring into a lock up (a), unlock and open the loop away from the black back carabiner by pushing the gate plate. Create a loop large enough forward (b), rotating the gate (c) to allow insertion of the carabiner.
Page 3 6. Ensure that the carabiner gate is in the fully locked position and that the carabiner lock arms are fully snapped onto the carabiner. 5. Slide the open end of the carabiner onto the top swivel of the second SRL. Close the carabiner gate and snap the gate lock arms onto the carabiner, ensure that the webbing is...
Page 4 If any defects are found remove the Carabiner Lock from service immediately. Reliance Industries Phone : 281-930-8000 P.O. Box 2046 Toll Free : 888-362-2826 Deer Park, TX 77536 www.relsafe.com Copyright 2021 Reliance Fall Protection 3062-36T-100 Rev A...
