INSTRUCTIONS FOR USE
I-BEAM LOCK JAW TROLLEY
ANCHORAGE CONNECTOR
MODEL # 4810
This instruction manual is to be used for training and assistance to users, competent
persons and qualified persons in designing and installing a complete personal fall arrest
system (PFAS). This manual also meets the requirements outlined in ANSI Z359.1(07)
and is to be used as part of a training program as required by OSHA.
Advertisement
Table of Contents
Related Manuals for Reliance 4810
Summary of Contents for Reliance 4810
- Page 1 INSTRUCTIONS FOR USE I-BEAM LOCK JAW TROLLEY ANCHORAGE CONNECTOR MODEL # 4810 This instruction manual is to be used for training and assistance to users, competent persons and qualified persons in designing and installing a complete personal fall arrest system (PFAS). This manual also meets the requirements outlined in ANSI Z359.1(07)
- Page 2 Upon notice of product defect or fault, Reliance Industries LLC will promptly repair or replace all defective items. Reliance Indus- tries...
-
Page 3: Table Of Contents
Table of Contents Section Page Warranty Information Product Description Product Specifications Purpose Limitations Standard Compliance System Requirements Component Compatibility Connector Compatibility Making Connections Anchor Strength PFAS Installation and Use Before Each Use Planning Your Installation Installation Attaching PFAS to Trolley Training Requirements Inspection Inspection Frequency... - Page 4 Alterations or misuse of this equipment, or failure to follow these instructions, may result in serious injury or death. IMPORTANT: If you have questions on the use, care, or suitability of this equipment for your application, contact Reliance Industries. 1.0 DESCRIPTION: Wheels (4)
-
Page 5: Purpose
1.2 PURPOSE: The 4810 Lockjaw Trolley Anchorage Connector is designed to move along horizontal beams with an attached personal fall arrest system. This trolley is to be used only as a component of a personal fall arrest system. Do not hang, lift, or support tools or equipment from the trolley. -
Page 6: System Requirements
Do not use equipment that is not compatible. Ensure all connectors are fully closed and locked prior to each use. Reliance connectors (snap hooks and carabiners) are designed to be used only as specified in each product’s user’s instructions. The following connections must not be made. -
Page 7: Installation And Use
3.0 INSTALLATION AND USE: WARNING: Do not alter or intentionally misuse this equipment. Consult with Reliance if using this equipment with components or subsystems other than those described in this manual. Some subsystem and component combinations may interfere with the operation of this equipment. -
Page 8: Installation
If a swing fall situation exists in your application contact Reliance Industries before proceeding. D. SHARP EDGES: Avoid working where parts of the system will be in contact with, or abrade against, unprotected sharp edges. -
Page 9: Inspection
Step 4. Tighten the Threaded T-Handle lock nut tight against the trolley threaded boss and torque to 35 ft/lbs. Figure 2 Figure 3 Figure 4 3.4 ATTACHING PERSONAL FALL ARREST SYSTEM TO TROLLEY: Attach your personal fall arrest system to the D-Ring on the load bar. Self-locking snap hooks and carabiners are required by ANSI Z359.12 and OSHA. -
Page 10: Inspection Log
6.0 INSPECTION LOG Product Model #:_ Date Of MFG:_ Date First Used:... - Page 11 6.0 INSPECTION LOG Product Model #:_ Date Of MFG:_ Date First Used: Serial Number...
- Page 12 2101 S. Battleground Rd. Deer Park, Texas 77536 Phone: 281-930-8000 / Fax: 281-930-8666 www.relsafe.com ©Reliance Industries, LLC Rev: A_4-2022...
