5.2 Connecting a PC to the VP-200NA 1:2 XGA / Audio DA

The example in Figure 4 illustrates how to use the VP-200NA to output the
XGA and audio signals from a PC's digital graphics card to two video and
four audio acceptors:
1. Connect an XGA source (for example, a PC's digital graphics card) to the
INPUT HD15F connector, and connect the sound to the Unbalanced
Audio INPUT mini plug connector.
2. Connect the OUTPUT HD15F connectors to up to 2 XGA acceptors
follows:
Connect the OUTPUT 1 connector to Analog Monitor 1
Connect the OUTPUT 2 connector to Analog Monitor 2
3. Connect the Unbalanced Audio OUTPUT mini plug connectors to up to 2
unbalanced audio acceptors
Connect the OUT 1 connector to Tape Recorder 1
Connect the OUT 2 connector to Tape Recorder 2
4. Connect the Balanced Audio OUTPUT terminal block connectors to up to
2 balanced audio acceptors
Connect the first terminal block connector to Power Amplifier 1
Connect the second terminal block connector to Power Amplifier 2
5. On the underside of the VP-200NA, set both the Hs and Vs switches to
75 (ANALOG).
6. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity.
2
7. Adjust the right and left audio signal levels, if required (not illustrated in
3
Figure 3 ).
1 When only one output is required, use either of the outputs, and leave the other output unconnected
2 Insert a screwdriver into the small hole and carefully rotate it, trimming the OUTPUT level
3 See the illustration in Figure 2
