Overview

The Kramer high performance VP-200NA 1:2 XGA / Audio DA is a 1:2
distribution amplifier for VGA/SVGA/XGA/UXGA balanced and unbalanced
stereo audio signals.
The VP-200NA 1:2 XGA / Audio DA:
Accepts an XGA input, provides correct buffering and isolation, and then
distributes the signal to 2 identical outputs on high-density 15 pin HD
connectors
Accepts an unbalanced stereo audio input, and simultaneously outputs 2
unbalanced stereo audio outputs on mini plug connectors, and 2 balanced
stereo audio outputs on terminal block connectors
With its video bandwidth exceeding 400MHz, ensures transparent
operation at the highest resolutions
Accepts analog or digital syncs
separate controls for audio output level and XGA equalization
Achieving the best performance means:
Connecting only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables)
Avoiding interference from neighboring electrical appliances and
positioning your VP-200NA away from moisture, excessive sunlight and dust
1 Via a pair of underside switches. Note that both the Hs (horizontal sync) switch and the Vs (vertical sync) switch MUST be
set identically
2 Via an underside switch. Sometimes notebook computers refuse to output a VGA signal to an external VGA monitor. By
setting the ID BIT to ON, the notebook will output to an external VGA monitor
3 For example: model number AD2512C, part number 2535-000251
Overview
1
Caution
– No operator-serviceable parts inside unit.
Warning
– Use only the Kramer Electronics input power
wall adapter that is provided with this unit
Warning
– Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
and provides ID Bit control
2
as well as
3
.
3
