Page 2: Installation
1.0 Installation 1.1 Product description Lindab’s Active chilled beam Architect provides great freedom of choice in design. A large number of predefined design solutions can be easily applied, in terms of technology, to create customized design solutions with great flexibility, but without affecting the function and performance. - Page 3 Notice! The connection pipes are internally soft-welded, therefore it is not allowed to solder the beam to the pipes. For other than Lindab fittings and valves, please consult the installation guide for the specific fitting for further details on proper installation.Both inlet- and return pipes are covered by a plastic or rubber protection cover, which must be removed before installation.
- Page 4 Please refer to the suppliers manual. = 70 mm (to ensure you can open the couplings again). Lindab flexible hoses are available with straight end (male) for direct connection to Lindab valves also. Lindab reserves the right to make changes without prior notice...
- Page 5 2.2.1 Measure the static nozzle pressure. – To measure the air pressure, a manometer, analog or digital (such as the Lindab PC410) will be needed. – Insert the measuring tube onto the specialized measuring nozzle.
- Page 6 7 8 9 [l/s] Diagram 1 Premum/Premax Inregulation Diagram 2011-09-30 Lenhgt 2,4m -3,0m Architect 2.0m < L ≤ 3.0m Position of JetCone adjustment pins Position [Pa] [l/s] Diagram 2 2011-09-30 Lindab reserves the right to make changes without prior notice 2022-10-18...
-
Page 7: Maintenance
Demount the inspection hatch in the opposite end of the air connection, in a turn and pull motion. – Clean the inside of the beam with a vacuum cleaner and a piece of wet cloth. – Only use lukewarm water and a mild detergent. Lindab reserves the right to make changes without prior notice 2022-10-18... -
Page 8: Material Data
4.3 Pressure class – The waterborne products in Lindab, active chilled beams (battery products), passive chilled beams (battery and strips products), façade units (battery) and radiant panels (strips and panels) are produced according to pressure class PN 10 according to EN 1333: 2006. - Page 9 | f o r a be tte r cli mat e Architect Service & Maintenance 4.4 Water quality Lindab recommend water treatment and quality to be according to VDI 2035-2. – The water preparation and maintenance for the chilled beam water circuit should be handled by a specialist –...
