  • Page 1 GUT-6600A Handy Digital IC Tester USER MANUAL...
  • Page 2 CONTENTS I.GENERAL SPECIFICATION ........2 II.FUNCTION KEYS ........... .3 III.OPERATION............4 IV.SUPPORTED DEVICES .......... 6...
  • Page 3 10 °C to 50 °C Storage Temperature: -20 °C to 80 °C *Getting Started The GUT-6600A can be powered in two ways: 1.Insert TWO 9V batteries (in the bottom of the GUT-6600A, polarity as indicated). 2.Connect a 9 Volt 500 mA DC adapter to the power connector on the back. Use a 2.1 mm plug with the positive pole outside.
  • Page 4 II. FUNCTION KEYS Power on: Press POWER-ON / TEST key to switch on the GUT-6600A Simultaneously press TYPE and DOWN keys to switch off. Power off: TYPE key: Select IC family. UP [ ] key: Back to the previous IC number within the selected series.
  • Page 5 If you hold down the key, the device numbers will automatically increment [ ] Then, select the IC VCC. The GUT-6600A provides 5.0V, 3.3V,3.0V,2.5V 4 kinds of or decrement [▲]. voltage. We can press "AUTO" and "UP" or "DOWN" for selection. The default is 5.0V.
  • Page 6 6.Now you can test another IC or you can switch off the GUT-6600A By pressing the TYPE and DOWN [ ] keys simultaneously. The GUT-6600A will be automatically turn off after idle 90 seconds by the default. We can adjust the automatically turn off time to 30s, 1m30s, 3m or Never. After...
  • Page 7 IV. SUPPORTED DEVICES 74 Series 7400 7401 7402 7403 7404 7405 7406 7407 7408 7409 7410 7411 7412 7413 7414 7415 7416 7417 7418 7419 7420 7421 7422 7423 7424 7425 7426 7427 7428 7430 7432 7433 7434 7435 7436 7437 7438 7439...
  • Page 8 74 Series (continued) 7463974640 74641 74642 74643 74644 74645 7464674647 74652 74654 74668 74669 74670 7468274683 74684 74685 74688 74689 74795 7479674797 74798 74804 74805 74808 74810 7481174821 74827 74832 74841 74874 741000 741002741003 741004 741005 741008 741010 741011 741020741034 741035 741036 741244...
