- Page 1 Thermal Network Bullet Camera Quick Start Guide COPYRIGHT © 2019 Hangzhou Hikvision Digital Technology Co., Ltd.
- Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
- Page 3 LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
- Page 4 FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for Class A device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 5 upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information.
- Page 6 Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. ●...
- Page 7 ● Make sure the power supply voltage is correct before using the camera. ● Do not drop the camera or subject it to physical shock. ● Do not touch sensor modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently.
- Page 8 and using history, so regular checking is recommended for all the users. Please contact with your dealer for more details. ● Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or equivalent type only.
-
Page 9: Table Of Contents
Table of Contents 1 Appearance Description ..............1 1.1 Type I Camera Appearance ..........1 1.2 Type II Camera Appearance ..........2 1.3 Cable Description ............3 2 Installation ..................6 2.1 Memory Card Installation ..........7 2.1.1 Type I Camera Memory Card Installation ....7 2.1.2 Type II Camera Memory Card Installation ..... -
Page 10: Appearance Description
1 Appearance Description There are two kinds of thermal network bullet cameras: Type I bullet camera, and Type II bullet camera. The appearance description of two cameras are shown below. 1.1 Type I Camera Appearance The overview of Type I thermal network bullet camera and its components are shown below: Type I Camera Overview... -
Page 11: Type Ii Camera Appearance
Sun Shield Camera Memory Card Slot Bracket Holder Cable Outlet Bracket Hinge Bracket Arm Reset Button Junction Box Cover Junction Box Base Sealing Interface Type I Camera Components Overview 1.2 Type II Camera Appearance The overview of Type II thermal network bullet camera is shown in below: Type II Camera Overview... -
Page 12: Cable Description
Sun Shield Bracket Lens Reset Button Memory Card Slot Camera Components and Cables 1.3 Cable Description The bullet camera cables, including power cable, coaxial video cable, alarm cable, and audio cable are shown below. The Type I camera supports network cable and optical fiber. The Type II camera supports network cable. - Page 13 Cable Description Name Description Power Interface 24V AC and 12V DC are supported. For 12V DC power supply, make sure that the positive/negative terminals are connected correctly. Network Interface Connect to the LAN interface. PoE+ is supported for type II camera. Use switch that supports PoE+ function.
- Page 14 After the power on of the camera, you must still press and hold the Reset button for about 10 seconds.
-
Page 15: Installation
2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12V DC or 24V AC, please make sure your power supply matches your camera. ●... -
Page 16: Memory Card Installation
Memory Card Installation Make sure you install the memory card in the same way you disassemble the camera, so that the leak-free sealing performance will not be affected. 2.1.1 Type I Camera Memory Card Installation Steps: 1. Unscrew the memory card slot cover and remove it. Removing Card Slot Cover (Type I Camera) 2. -
Page 17: Type Ii Camera Memory Card Installation
Inserting Memory Card (Type I Camera) 3. Cover the memory card slot and fix the screws on the memory card slot cover. 2.1.2 Type II Camera Memory Card Installation Steps: 1. Unscrew the memory card slot cover and remove it. Removing Card Slot Cover (Type II Camera) A rubber seal ring is on the top of the memory card slot cover. - Page 18 2. Insert the memory card into the memory card slot. Inserting Memory Card (Type II Camera) 3. Cover the memory card slot and fix the screws on the memory card slot cover. Fixing Memory Card Slot Cover (Type II Camera)
-
Page 19: Wide Range Coverage For Different Specifications
Wide Range Coverage for Different Specifications For fixed lens camera, the auto-focus function, and remote manual focus function are not supported. Select the proper installation site, and proper lens focal length according to the Wide Range Coverage list below: Wide Range Coverage Lens (focal length) 10mm 15mm... -
Page 20: Installing Camera
2.3 Installing Camera 2.3.1 Installing Type I Camera Before you start: There are three methods of Type I camera installation: wall mounting, ceiling mounting, and stand mounting. Type I Camera Installation Methods Steps: 1. Loosen the screws on the junction box cover. 2. - Page 21 3. Attach the drill template (supplied) to the place where you want to fix the camera, and then drill four screw holes (recommended depth: 40mm) in the ceiling/wall according to the drill template. 4. Drill a cable hole according to the A mark of the drill template. Drill Template (Type I Camera) 5.
-
Page 22: Installing Type Ii Camera
7. Route the cables through the cable hole. 8. Insert the latches into the latch holes to fix the bracket and camera with the junction box. Wall Mounting Ceiling Mounting Stand Mounting Installing Junction Box Cover 9. Fix the delivered screws to secure the junction box. 10. - Page 23 1. Attach the drill template (supplied) to the place where you want to fix the camera, and then drill the screw holes in the ceiling/wall according to the drill template. 2. (Optional) If you want to route cables through the installation surface, drill a cable hole according to the drill template.
- Page 24 Drill Template 3) Make sure the Top are on the top and the bottom are at the bottom. Fix the junction box to the installation surface with the supplied screws. 4) Fix the bullet camera to the junction box with the supplied screws, as shown in Figure 2-14.
- Page 25 4. Fix the bullet camera to the installation surface with the supplied screws, as shown in Figure 2-15. Wall Mounting Ceilling Mounting Install the Bracket onto the Wall 5. Adjust the camera to the optimal surveillance angle. Bracket type I: 1) Loosen the pan adjusting screw to adjust panning position [0°...
- Page 26 Bracket type II: 1) Loosen the screw to adjust the tilting position [0° to 90°]. Tighten the screw. 2) Loosen the screw to adjust the rotation position [0° to 360°]. Tighten the screw. Screw 2-axis Adjustment Please loosen the screws slightly until you can adjust the camera. Do NOT remove the screws from the bracket.
-
Page 27: Installation Of Network Cable Water-Proof Jacket
Installation of Network Cable Water-proof Jacket Purpose: If the camera is installed outdoor, you can adapt the water-proof accessory for the network cable after the camera is secured on the installation surface. Water-proof Accessory Components Table 2-1 Components Components Camera’s Network Interface Socket O-Type Gasket Network Plug Waterproof Endcap... - Page 28 Align the snap and notch. i. Insert into ii. Secure with Camera Switch/ Router Water-proof Accessory Installation Steps: 1. Feed the plugless network cable ⑦ through the lock nut ⑥, waterproof rubber gasket ⑤ (rubber gasket inset ridge must face waterproof endcap), and the water-proof endcap ④...
- Page 29 3. Place the O-type gasket ② onto the end of the camera’s network interface socket ①. 4. Insert the network plug ③ into the camera’s network interface socket ①. 5. Insert the water-proof rubber gasket ⑤ into the waterproof endcap ④, and secure lock nut ⑥ with the water-proof endcap ④.
-
Page 30: Setting The Network Camera Over The Lan
3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, please contact with your dealer or the nearest service center. -
Page 31: Activating The Camera
3.2 Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation. -
Page 32: Activation Via Sadp Software
Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. - Page 33 Select inactive device. Input and confirm password. SADP Interface Note: The SADP software supports activating the camera in batch. Please refer to the user manual of SADP software for details. 3. Create a password and input the password in the password field, and confirm the password.
-
Page 34: Modifying The Ip Address
STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect your... - Page 35 Note: Please refer to Chapter 3.2 to activate the camera if the camera is inactive. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Modify the IP Address [26]...
- Page 36 4. Input the password to activate your IP address modification. The batch IP address modification is supported by the SADP; please refer to the User Manual of SADP for details. [27]...
-
Page 37: Accessing Via Web Browser
4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:... - Page 38 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. You may have to close the web browser to finish the installation of the plug-in. Download Plug-in 6.
- Page 39 For detailed instructions of further configuration, please refer to the user manual of network camera. [30]...
-
Page 40: Appendix
Appendix Frequently Asked Questions (FAQ) Device Running Error Question: The device fails to start up or reboots repeatedly. Answer: Examine the power supply of the positioning system and see whether it meets the requirements. Select the power supply as close as possible. ... - Page 41 Examine if the lens is dirty or not. Examine if any obstruction is nearby, e.g. spider web. Question: Live view fails with good network connection. Answer: Examine if the IE plug-in is well installed. Change the Website Blocker settings if necessary. ...
-
Page 42: Common Material Emissivity Reference
Common Material Emissivity Reference Material Emissivity Human Skin 0.98 0.91 Cement Concrete 0.95 Ceramics 0.92 Rubber 0.95 Paint 0.93 Wood 0.85 Asphalt 0.96 Brick 0.95 Sand 0.90 Soil 0.92 Cotton 0.98 Cardboard 0.90 White Paper 0.90 Water 0.96 [33]... - Page 43 UD13140B...
