Thermal Network Bullet Camera
Quick Start Guide
COPYRIGHT © 2018 Hangzhou Hikvision Digital Technology Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2TD2336-75 and is the answer not in the manual?

Questions and answers

Related Manuals for HIKVISION DS-2TD2336-75

Summary of Contents for HIKVISION DS-2TD2336-75

  • Page 1 Thermal Network Bullet Camera Quick Start Guide COPYRIGHT © 2018 Hangzhou Hikvision Digital Technology Co., Ltd.
  • Page 2 Quick Start Guide COPYRIGHT © 2018 Hangzhou Hikvision Digital Technology Co., Ltd. ALL RIGHTS RESERVED. Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed,...
  • Page 3 INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for Class A device, pursuant to part 15 of the FCC Rules.
  • Page 5 harmonized European standards listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU. 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 6 Cautions: Injury or equipment damage may occur if any of the cautions are neglected. Warnings Follow these Cautions Follow these safeguards to prevent precautions to prevent serious injury or death. potential injury or material damage. Warnings ● Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.
  • Page 7 ● Please make sure that the plug is firmly connected to the power socket. When the product is mounted on wall or ceiling, the device shall be firmly fixed. ● If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then please contact the service center.
  • Page 8 ● To avoid heat accumulation, good ventilation is required for operating environment. ● Keep the camera away from liquid while in use. ● While in delivery, the camera shall be packed in its original packing, or packing of the same texture. ●...

  • Page 9: Table Of Contents

    Table of Contents 1 Appearance Description ............... 1 1.1 Type I Camera Appearance .......... 1 1.2 Type II Camera Appearance ......... 2 1.3 Cable Description ............3 2 Installation ..................6 2.1 Memory Card Installation ..........7 2.1.1 Type I Camera Memory Card Installation ..7 2.1.2 Type II Camera Memory Card Installation ..

  • Page 10: Appearance Description

    1 Appearance Description There are two kinds of thermal network bullet cameras: Type I bullet camera, and Type II bullet camera. The appearance description of two cameras are shown below. 1.1 Type I Camera Appearance The overview of Type I thermal network bullet camera and its components are shown below: Type I Camera Overview...

  • Page 11: Type Ii Camera Appearance

    Sun Shield Camera Memory Card Slot Bracket Holder Cable Outlet Bracket Hinge Bracket Arm Reset Button Junction Box Cover Junction Box Base Sealing Interface Type I Camera Components Overview 1.2 Type II Camera Appearance The overview of Type II thermal network bullet camera is shown in below:...

  • Page 12: Cable Description

    Type II Camera Overview Sun Shield Bracket Lens Reset Button Memory Card Slot Camera Components and Cables 1.3 Cable Description The bullet camera cables, including power cable, coaxial video cable, alarm cable, and audio cable are shown below. The Type I camera supports network cable and optical fiber.
  • Page 13 Cable Description Cable Description Name Description Power Interface 24V AC and 12V DC are supported. For 12V DC power supply, make sure that the positive/negative terminals are connected correctly. Network Interface Connect to the LAN interface. PoE+ is supported for type II camera. Use switch that supports PoE+ function.
  • Page 14 Name Description Audio Interface Audio In: Pickup Audio Out: Loudspeaker Video Interface Local video signal output The cables may vary according to different models. ● Here we list all types of cables for reference. Take the actual product for the cables Alarm cables can be classified as 2-ch alarm input and ●...

  • Page 15: Installation

    2 Installation Before you start: Make sure the device in the package is in good ● condition and all the assembly parts are included. The standard power supply is 12V DC or 24V AC, ● please make sure your power supply matches your camera.

  • Page 16: Memory Card Installation

    Memory Card Installation Make sure you install the memory card in the same way you disassemble the camera, so that the leak-free sealing performance will not be affected. 2.1.1 Type I Camera Memory Card Installation Steps: 1. Unscrew the memory card slot cover and remove it. Memory Card Cover Removing Card Slot Cover (Type I Camera) 2.

  • Page 17: Type Ii Camera Memory Card Installation

    Memory Card Inserting Memory Card (Type I Camera) 3. Cover the memory card slot and fix the screws on the memory card slot cover. 2.1.2 Type II Camera Memory Card Installation Steps: 1. Unscrew the memory card slot cover and remove it. Removing Card Slot Cover (Type II Camera)
  • Page 18 A rubber seal ring is on the top of the memory card slot cover. Do NOT lose the ring for the waterproof performance. 2. Insert the memory card into the memory card slot. Inserting Memory Card (Type II Camera) 3. Cover the memory card slot and fix the screws on the memory card slot cover.

  • Page 19: Wide Range Coverage For Different Specifications

    Wide Range Coverage for Different Specifications For fixed lens camera, the auto-focus function, and remote manual focus function are not supported. Select the proper installation site, and proper lens focal length according to the Wide Range Coverage list below: Wide Range Coverage Lens (focal length) 10mm 15mm 25mm 35mm 50mm 75mm Detection range (Vehicles)

  • Page 20: Installing Camera

    2.3 Installing Camera 2.3.1 Installing Type I Camera Before you start: There are three methods of Type I camera installation: wall mounting, ceiling mounting, and stand mounting. Type I Camera Installation Methods Steps: 1. Loosen the screws on the junction box cover. 2.
  • Page 21 Take Apart Junction Box 3. Attach the drill template (supplied) to the place where you want to fix the camera, and then drill four screw holes (recommended depth: 40mm) in the ceiling/wall according to the drill template. 4. Drill a cable hole according to the A mark of the drill template. Drill Template (Type I Camera) 5.
  • Page 22 Sealing Ring Screw Installing Junction Box Base 7. Route the cables through the cable hole. 8. Insert the latches into the latch holes to fix the bracket and camera with the junction box. Wall Mounting Ceiling Mounting Stand Mounting Installing Junction Box Cover 9.

  • Page 23: Installing Type Ii Camera

    11. Adjust the camera according to the figure below. P-Direction Screw T-Direction Screw Tilt Range [-90° to 55° ] Pan Range Rotation Range [-90° to 90° ] [-180° to 180° ] R-Direction Screw 3-Axis Adjustment 2.3.2 Installing Type II Camera Steps: 1.
  • Page 24 Drill Template (Type II Camera) 3. (Optional) Fix the camera to the junction box. 1) Attach the drill template (supplied) to the place where you want to fix the junction box, and then drill four holes in the ceiling/wall according to the drill template. 2) (Optional) If you want to route cables through the installation surface, drill a cable hole according to the drill template.
  • Page 25 Drill Template 3) Make sure the Top are on the top and the bottom are at the bottom. Fix the junction box to the installation surface with the supplied screws. 4) Fix the bullet camera to the junction box with the supplied screws, as shown in Figure 2-14.
  • Page 26 5. Adjust the camera to the optimal surveillance angle. 1) Loosen the pan adjusting screw to adjust panning position [0° to 360°]. Tighten the screw. 2) Loosen the tile adjusting screw to adjust the tilting position [0° to 100°]. Tighten the screw. 3) Loosen the rotation adjusting screw to adjust the rotation position [0°...

  • Page 27: Installation Of Network Cable Water-Proof Jacket

    Installation of Network Cable Water-proof Jacket Purpose: If the camera is installed outdoor, you can adapt the water-proof accessory for the network cable after the camera is secured on the installation surface. ① ② ③ ④ ⑤ ⑥ ⑦ Water-proof Accessory Components Table 2-1 Components Components Camera’s Network Interface Socket...
  • Page 28 Components Network Cable from Router/Switch Align the snap and notch. i. Insert into ii. Secure with Camera Switch/ Router Water-proof Accessory Installation Steps: 1. Feed the plugless network cable ⑦ through the lock nut ⑥, waterproof rubber gasket ⑤ (rubber gasket inset ridge must [19]...
  • Page 29 face waterproof endcap), and the water-proof endcap ④ in order. 2. Crimp an RJ-45 network plug ③onto the end of the cable, taking care to insert the twisted pairs of wires in correct order. 3. Place the O-type gasket ② onto the end of the camera’s network interface socket ①.

  • Page 30: Setting The Network Camera Over The Lan

    3 Setting the Network Camera over the LAN Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection. If the product does not work properly, please contact with your dealer or the nearest service center.

  • Page 31: Activating The Camera

    3.2 Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.

  • Page 32: Activation Via Sadp Software

    Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 33 Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera, please refer to the User Manual of Network Camera for other two activation methods. Steps: 1.

  • Page 34: Modifying The Ip Address

    STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product. And we recommend you reset your password regularly, especially in the high security system, resetting the password monthly or weekly can better protect...
  • Page 35 Note: Please refer to Chapter 3.2 to activate the camera if the camera is inactive. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Modify the IP Address [26]...
  • Page 36 4. Input the password to activate your IP address modification. The batch IP address modification is supported by the SADP; please refer to the User Manual of SADP for details. [27]...

  • Page 37: Accessing Via Web Browser

    4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps: 1.
  • Page 38 The device IP address gets locked if the admin user performs 7 failed password attempts (5 attempts for the user/operator). Click Login. Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in.
  • Page 39 Download Plug-in 6. Reopen the web browser after the installation of the plug-in and repeat steps 2~4 to login. For detailed instructions of further configuration, please refer to the user manual of network camera. [30]...

  • Page 40: Appendix

    Appendix Frequently Asked Questions (FAQ) Device Running Error Question: The device fails to start up or reboots repeatedly.  Answer: Examine the power supply of the positioning  system and see whether it meets the requirements. Select the power supply as close as possible. ...
  • Page 41 Examine if the lens is dirty or not.  Examine if any obstruction is nearby, e.g. spider  web. Question: Live view fails with good network connection. Answer: Examine if the IE plug-in is well installed. Change  the Website Blocker settings if necessary. For cross-domain routing, enable the UPnP of ...

  • Page 42: Common Material Emissivity Reference

    Common Material Emissivity Reference Material Emissivity Human Skin 0.98 0.91 Cement Concrete 0.95 Ceramics 0.92 Rubber 0.95 Paint 0.93 Wood 0.85 Asphalt 0.96 Brick 0.95 Sand 0.90 Soil 0.92 Cotton 0.98 Cardboard 0.90 White Paper 0.90 Water 0.96 [33]...
  • Page 43 UD10260B...
