Assembly Instuction
Dracula Home Office Chair
1. Fit Wheels: Line up shaft of wheel (1) with
2. Fit Gas Lift: Have gas lift (3) upright as
1. Fit Release Mechanism: Place seat (7) upside
hole in Star base (2) If you have at a slight
angle with split washer flat on one side it
will slide in easier.
indicated in drawing slide into hole, no need
to apply excessive force, Place dust cover
(4) over gas lift as indicated in diagram.
down on a clean surface, identify front from
back of seat, place release mechanism with
arrow pointing to front of seat. Then take bolt
(9) and by hand insert into holes as indicated
in diagram only tighten 2-3 turns till all blots
fitted, once all seated tighten with allen key
(11) till firm DO NOT OVERTIGHTEN.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dracula Home Office Chair and is the answer not in the manual?

Questions and answers

Related Manuals for Furniture Solutions Dracula Home Office Chair

Summary of Contents for Furniture Solutions Dracula Home Office Chair

  • Page 1 Assembly Instuction Dracula Home Office Chair 1. Fit Wheels: Line up shaft of wheel (1) with hole in Star base (2) If you have at a slight angle with split washer flat on one side it will slide in easier.
  • Page 2 With use bolts may loosen please ensure you check bolts on a regular bases, this will ensure safety & longer life for chair Please see base of chair for fabric care instruction Made In China Imported By Furniture Solutions (Aust) Pty Ltd...
