Furniture Solutions NANTES 3s SOFA BED Assembly Instruction

ASSEMBLY INSTRUCTION MODEL: NANTES 3s SOFA BED

Step 1: With the help of another person place sofa upside down on a

soft clean surface. Unzip storage pocket remove parts.

Step 2: Take Front leg (A) line up holes in leg with threaded holes in

sofa, ensure you have leg point outwards. Take bolt (C) with washer

(D) insert thru hole into thread then by hand turn 2-3 times to seat

bolt properly, repeat for other bolt once seated properly, take Allen

key (E) and tighten till firm do not over tighten. To fit back leg place

threaded end into hole as indicated in diagram seat thread properly

before tighten. Once all legs fitted correctly with help of another

person lift sofa and rotate till feet on floor. Ready for use.

Parts stored in Zipper at base of sofa

Front leg x 2

Back leg x 2

Bolt x 4

Washer x 4

Allen Key x 1

Table of Contents

Need help?

Do you have a question about the NANTES 3s SOFA BED and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTION MODEL: NANTES 3s SOFA BED Front leg x 2 Back leg x 2 Bolt x 4 Washer x 4 Allen Key x 1 Parts stored in Zipper at base of sofa Step 1: With the help of another person place sofa upside down on a soft clean surface.
