About the user manuals
Product documentation is composed of the following documents.
• Installation Guide (accessory): Provides information about "Precautions", "Precautions for
installation" and the installation method.
• Basic Information (this document): Provides information about "Precautions for use", "Parts and
functions" and "Detail specifications".
• Operating Instructions (Refer to the link on the following product information website):
Explains how to perform the settings and how to operate this camera.
https://i-pro.com/global/en/surveillance/training-support/documentation-database-list
"<Control No.: C****>" used in these documents should be used to search for information on our
technical information website (https://i-pro.com/global/en/surveillance/training-support/support/
technical-information) and will guide you to the right information.
• microSDXC/ microSDHC/ microSD memory card is described as microSD
memory card.
• The external appearance and other parts shown in this manual may differ
from the actual product within the scope that will not interfere with normal
use due to improvement of the product.
Basic Information
WV-S65300-ZY
Model No.
WV-U65300-ZY
WV-S65300-ZY / WV-U65300-ZY
Network Camera
Advertisement
Table of Contents
Related Manuals for i-PRO WV-S65300-ZY
Summary of Contents for i-PRO WV-S65300-ZY
- Page 1 Basic Information Network Camera WV-S65300-ZY Model No. WV-U65300-ZY WV-S65300-ZY / WV-U65300-ZY About the user manuals Product documentation is composed of the following documents. • Installation Guide (accessory): Provides information about “Precautions”, “Precautions for installation” and the installation method. • Basic Information (this document): Provides information about “Precautions for use”, “Parts and functions”...
-
Page 2: Table Of Contents
Contents Limitation of liability ........................3 Disclaimer of warranty ........................3 About notations ..........................4 System requirements for a PC ...................... 4 Network security ........................... 5 Precautions for use ........................6 Parts and functions ........................9 Insert / remove a microSD memory card ..................14 Troubleshooting ........................... -
Page 3: Limitation Of Liability
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S). Disclaimer of warranty IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:... -
Page 4: About Notations
About notations Some functions are expressed with the following notations in this document. The functions with this notation are available when using the WV-S65300-ZY. S65300 The functions with this notation are available when using the WV-U65300-ZY. U65300 Clear dome cover... -
Page 5: Network Security
Network security As you will use this unit connected to a network, your attention is called to the following security risks. ① Leakage or theft of information through this unit ② Use of this unit for illegal operations by persons with malicious intent ③... -
Page 6: Precautions For Use
Precautions for use When the product is accessible from the When an error is detected, this product Internet will restart automatically. To prevent unauthorized access, note the fol- This product will be inoperable for around lowing. 2 minutes after the restart just as when the •... - Page 7 Cleaning this product body • The ventilation openings are located on the Be sure to turn off the power before cleaning. bottom of the camera. To maintain the Failure to observe this may cause injury. dehumidification function properly, do not Do not use benzine, thinner, alcohol, or any caulk (fill gaps with sealants or other mate- other types of solvents or detergents.
- Page 8 AVC Patent Portfolio License Product disposal/transfer Data saved on this product or a storage device THIS PRODUCT IS LICENSED UNDER THE used with this product may lead to personal AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF A CONSUMER OR information leakage.
-
Page 9: Parts And Functions
Parts and functions ■ Cables [1] RJ45 Ethernet cable(PoE) category 5e or better, straight, 4 pairs (8 pins) I/O Cable connection terminal <100 m {328 feet} < 1 m {3.28 feet} (Mic) [3] Audio in < 10 m {32.8 feet} (Line) (white) [4] Audio out <... - Page 10 [2] Power supply cable / 2P power cable (WV-QCA501A accessory) Connect the output cable of the DC power supply to the 2P power cable. IMPORTANT: • Be sure to use the 2P power cable provided with WV-QCA501A. • Be sure to fully insert the 2P power cable into the power supply cable. Otherwise, it may dam- age the camera or cause malfunction.
- Page 11 [5] EXT I/O cable / 4P alarm cable (WV-QCA501A accessory) Note: • Off, input, and output of the ALARM IN2 and 3 can be switched by configuring the setting. Refer to the Operating Instructions for further information about the ALARM IN2 and 3 settings (“Off”, “Alarm input”, “Alarm output”...
- Page 12 ■ Indicators and buttons ⑤ SD ON/OFF ① INITIAL SET button button ② LINK indicator (orange) microSD slot ④ SD MOUNT indicator (green) ③ ACT indicator (green) INITIAL SET button (Initializing / NTSC PAL switch button) Follow the steps below to initialize the network camera. (1) Turn off the power of the camera.
- Page 13 SD MOUNT indicator Lights off → Blinks green → • When a microSD memory card is inserted and could be recognized Lights off Lights off → Lights green • When data can be saved after the microSD memory card is inserted and the SD ON/OFF button is pressed (less than 1 second) •...
-
Page 14: Insert / Remove A Microsd Memory Card
Insert / remove a microSD memory card Note: • Use a microSD memory card dedicated to i-PRO cameras. • Refer to the Operating Instructions on our product information website for further information about the microSD memory card settings. ■ Insert a microSD memory card Open the microSD cover by using the bit (accessory) Insert the microSD memory card until it makes a clicking sound. - Page 15 ■ Remove a microSD memory card When removing a microSD memory card, reverse the procedure. • Before removing the microSD memory card, make sure to select “Not use” for “SD memory card” on the [SD memory card] tab of “Basic” page on the setup menu first. (☞ Operating Instructions) Note: •...
-
Page 16: Troubleshooting
Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Reference Symptom Cause/solution pages When using a PoE device for power supply... - Page 17 Reference Symptom Cause/solution pages • Is the Ethernet cable connected appropriately? Connect the Ethernet cable appropriately. The LINK indicator • Is the hub or router connected to the camera operating does not light in appropriately? orange even when the Ethernet cable is con- Check if the hub or router in use is operating appropriately.
-
Page 18: Detail Specifications
{ø6-3/32 inches × 5-9/32 inches (H)} Dome radius 42 mm {1-21/32 inches} Mass: Approx. 1.6 kg {3.53 lbs.} Finish: Main body: Aluminum die cast, i-PRO white Outer fixing screws: Stainless steel (Corrosion-resistant treatment) Dome cover: PC resin, (Transmittance: 45 %) Others:... - Page 19 *4 Component that has a structure on which the screws that are accessible after installation cannot be screwed or unscrewed using an ordinary screwdriver. *5 When using a 12 V DC power supply of this product, EXT I/O terminal, audio input, and audio output, I/O cable (option: WV-QCA501A) is required.
- Page 20 Light control mode setting: Outdoor scene/ Indoor scene (50 Hz)/ Indoor scene (60 Hz)/ Fix shutter Shutter speed: [60 fps mode] 1/60 Fix, 1/100 Fix, 1/120 Fix, 1/250 Fix, 1/500 Fix, 1/1000 Fix, 1/2000 Fix, 1/4000 Fix, 1/10000 Fix [30 fps/ 15 fps mode] 1/30 Fix, 3/120 Fix, 2/100 Fix, 2/120 Fix, 1/100 Fix, 1/120 Fix, 1/250 Fix, 1/500 Fix, 1/1000 Fix, 1/2000 Fix, 1/4000 Fix, 1/10000 Fix [50 fps mode] 1/50 Fix, 1/100 Fix, 1/250 Fix, 1/500 Fix, 1/1000 Fix, 1/2000 Fix, 1/4000 Fix, 1/10000 Fix...
- Page 21 • Lens Zoom ratio: Optical zoom 3.1x (Motorized zoom / Motorized focus) Extra optical zoom max 4.6x (3.1x – 4.6x when resolution is 1280x720) Focal length: 2.9 mm – 9 mm {1/8 inches – 11/32 inches} Maximum aperture ratio: 1:1.3 (WIDE) – 1:2.5 (TELE) Focus range: 0.3 m {11-13/16 inches} –...
- Page 22 • Network Network: 10BASE-T/100BASE-TX, RJ45 connector Resolution: [16:9 mode(60 fps mode)][16:9 mode(30 fps mode)] H.265/ H.264* [16:9 mode(50 fps mode)][16:9 mode(25 fps mode)] JPEG (MJPEG) 1920×1080/ 1280×720/ 640×360/ 320×180 [4:3 mode(30 fps mode)] [4:3 mode(25 fps mode)] 1280×960/ VGA/ QVGA [4:3 mode(15 fps mode)] [4:3 mode(12.5 fps mode)] 2048×1536 * / 1280×960/ VGA/ QVG Image compression method*...
- Page 23 JPEG (MJPEG) Image quality: 0 SUPER FINE/ 1 FINE/ 2/ 3/ 4/ 5 NORMAL/ 6/ 7/ 8/ 9 LOW (10 steps: 0-9) Transmission type: Pull (Refresh interval)/ Push (MJPEG) Refresh interval: [60 fps mode] 0.1 fps/ 0.2 fps/ 0.33 fps/ 0.5 fps/ 1 fps/ 2 fps/ 3 fps/ 5 fps/ 6 fps/ 10 fps/ 12 fps/ 15 fps/ 30 fps/ 60 fps [30 fps mode] 0.1 fps/ 0.2 fps/ 0.33 fps/ 0.5 fps/ 1 fps/ 2 fps/ 3 fps/ 5 fps/ 6 fps/...
- Page 24 <Control No.: C0132>. *6 When using MJPEG/JPEG (Refresh interval) only. *7 Use a microSD memory card dedicated to i-PRO cameras. *8 For possible number of images and duration (an indication) that can be saved on the microSD memory card, refer to our technical information website below.
- Page 25 Authorised Representative in EU: i-PRO EMEA B.V. Laarderhoogtweg 25, 1101 EB i-PRO Co., Ltd. Amsterdam, Netherlands Tokyo, Japan i-PRO EMEA B.V. UK Branch 1010 Cambourne Business Park, https://www.i-pro.com/ Cambridgeshire CB23 6DP © i-PRO Co., Ltd. 2022 N0822-1102 PGQP3514YA...
